| DC voltage measurement: |
600 mV ± (0.5% + 5) @ 0.1 mV ,
6 V ± (0.5% + 5) @ 0.001 V ,
60 V ± (0.5% + 5) @ 0.01 V ,
600 V ± (0.5% + 5) @ 0.1 V ,
1000 V ± (0.7% + 5) @ 1 V |
| AC voltage measurement: |
6 V ± (1% + 3) @ 1 mV ,
60 V ± (0.8% + 3) @ 10 mV ,
600 V ± (0.8% + 3) @ 0.1 V ,
750 V ± (1% + 10) @ 1 V |
| DC current measurement: |
60 µA ± (0.8% + 8) @ 0.01 µA ,
600 µA ± (0.8% + 8) @ 0.1 µA ,
6 mA ± (0.8% + 8) @ 0.001 mA ,
60 mA ± (0.8% + 8) @ 0.01 mA ,
600 mA ± (1.2% + 5) @ 0.1 mA ,
20 A ± (2% + 5) @ 0.01 A |
| AC current measurement: |
60 µA ± (1% + 12) @ 0.01 µA ,
600 µA ± (1% + 12) @ 0.1 µA ,
6 mA ± (1% + 12) @ 0.001 mA ,
60 mA ± (1% + 12) @ 0.01 mA ,
600 mA ± (2% + 3) @ 0.1 mA ,
20 A ± (2% + 3) @ 0.01 A |
| Resistance measurement: |
600 Ω ± (0.8% + 5) @ 0.1 Ω ,
6 kΩ ± (0.8% + 3) @ 1 Ω ,
60 kΩ ± (0.8% + 3) @ 10 Ω ,
600 kΩ ± (0.8% + 3) @ 100 Ω ,
6 MΩ ± (0.8% + 3) @ 1 kΩ ,
60 MΩ ± (3% + 10) @ 10 kΩ |
| Capacitance measurement: |
6 nF ± (4% + 10) @ 0.001 nF ,
60 nF ± (4% + 10) @ 0.01 nF ,
600 nF ± (4% + 10) @ 0.1 nF ,
6 µF ± (3% + 10) @ 0.001 µF ,
60 µF ± (3% + 10) @ 0.01 µF ,
600 µF ± (3% + 10) @ 0.1 µF ,
6 mF ± (5% + 10) @ 0.001 mF ,
60 mF ± 10 % @ 0.01 mF ,
100 mF ± 10 % @ 0.1 mF |
| Inductance measurement: |
 |
| Frequency measurement: |
9.999 Hz ... 9.999 MHz ± (0.1% + 5) @ 0.001 Hz ... 0.001 MHz |
| Temperature measurement: |
°C
-40 ... 40 °C ± 3 °C @ 1 °C
>40 ... 500 °C ± (1% + 3) @ 1 °C
>500 ... 1000 °C ± (2% + 3) @ 1 °C, °F
-40 ... 104 °F ± 5 °F @ 1 °F
>104 ... 932 °F ± (1.5% + 5) @ 1 °F
>932 ... 1832 °F ± (2.5% + 5) @ 1 °F |
| Automatic change of measuring ranges: |
|
| hFE: |
 |
| Diode test: |
|
| Sound signal of the continuity test: |
|
| Checking TTL logic states: |
|
| RS-232: |
|
| USB: |
|
| Main features: |
True RMS - accurate measurement of the RMS current and voltage for any waveform, NCV - electric field detection function, Freezing the last reading, Freezing the highest or lowest measurement, Automatic shutdown after 15 minutes of inactivity, Large, readable LCD display with backlight, Low battery level alarm, Aesthetic and solid construction |
| Power supply: |
2 x 1.5V, type AAA/LR03 battery |
| Weight: |
0.34 kg |
| Dimensions: |
183 x 88 x 56 mm |
| Manufacturer / Brand: |
UNI-T |
| Guarantee: |
2 years |
