| DC voltage measurement: |
600 mV ± (0.7% + 3) @ 0.1 mV ,
6 V ± (0.5% + 3) @ 0.001 V ,
60 V ± (0.7% + 3) @ 0.01 V ,
600 V ± (0.7% + 3) @ 0.1 V |
| AC voltage measurement: |
600 mV ± (1.0% + 4) @ 0.1 mV ,
6 V ± (0.7% + 3) @ 0.001 V ,
60 V ± (1.0% + 3) @ 0.01 V ,
600 V ± (1.0% + 3) @ 0.1 V
LPF mode :
600 V ± (2.0% + 5) @ 0.1 V
LoZ mode :
600 V ± (2.0% + 5) @ 0.1 V |
| DC current measurement: |
600 µA ± (0.8% + 3) @ 0.1 µA ,
6000 µA ± (0.8% + 3) @ 1 µA ,
60 mA ± (0.8% + 3) @ 0.01 mA ,
600 mA ± (0.8% + 3) @ 0.1 mA ,
6 A ± (1.0% + 3) @ 0.001 A ,
20 A ± (1.2% + 5) @ 0.01 A |
| AC current measurement: |
600 µA ± (1.0% + 3) @ 0.1 µA ,
6000 µA ± (1.0% + 3) @ 1 µA ,
60 mA ± (1.0% + 3) @ 0.01 mA ,
600 mA ± (1.0% + 3) @ 0.1 mA ,
6 A ± (1.2% + 3) @ 0.001 A ,
20 A ± (1.5% + 5) @ 0.01 A |
| Resistance measurement: |
600 Ω ± (1.0% + 2) @ 0.1 Ω ,
6 kΩ ± (0.8% + 2) @ 0.001 kΩ ,
60 kΩ ± (0.8% + 2) @ 0.01 kΩ ,
600 kΩ ± (0.8% + 2) @ 0.1 kΩ ,
6 MΩ ± (1.2% + 3) @ 0.001 MΩ ,
60 MΩ ± (2.5% + 5) @ 0.01 MΩ |
| Capacitance measurement: |
6 nF ± (4% + 8) + capacity of test leads @ 1 pF ,
60 nF ... 600 µF ± (3% + 5) @ 10 pF ... 100 nF ,
6 mF ... 60 mF ± 10% @ 1 µF ... 10 µF |
| Inductance measurement: |
 |
| Frequency measurement: |
10 Hz ... 1 MHz ± (0.1% + 4) @ 0.01 Hz ... 0.001 MHz |
| Square-wave signal duty ratio measurement: |
0.1 % ... 99.9 % ± (2% + 5) @ 0.1 % |
| Temperature measurement: |
°C
-40 ... 400 °C ± (1% + 2°C) @ 0.1 °C ... 1 °C ,
°F
-40 ... 752 °F ± (1% + 4°F) @ 0.2 °F ... 2 °F |
| Automatic change of measuring ranges: |
 |
| hFE: |
|
| Diode test: |
|
| Sound signal of the continuity test: |
|
| Checking TTL logic states: |
|
| RS-232: |
|
| USB: |
|
| Main features: |
True RMS - accurate measurement of the RMS current and voltage for any waveform, Possibility to measure AC voltage using low measuring impedance (LoZ mode), LPF function - allows to measure the AC voltage values using low-pass filter with a frequency limit of 200 Hz, Robust housing that meets the requirements of the IP65 "Index of Protection" class, Freezing the last reading, Flashlight built-in, Freezing the highest or lowest measurement, REL - relative measurement mode, Analog bargraph, Large, readable LCD display with backlight, Low battery level alarm, Aesthetic and solid construction, The set includes a practical case |
| Power supply: |
9V, type 6LR61 battery |
| Weight: |
0.4 kg |
| Dimensions: |
180 x 87 x 66 mm |
| Manufacturer / Brand: |
UNI-T |
| Guarantee: |
2 years |
