| DC voltage measurement: |
200 mV ± (0.5% + 1) @ 0.1 mV ,
2 V ± (0.5% + 1) @ 0.001 V ,
20 V ± (0.5% + 1) @ 0.01 V ,
200 V ± (0.5% + 1) @ 0.1 V ,
1000 V ± (0.8% + 2) @ 1 V |
| AC voltage measurement: |
200 mV ± (1.2% + 3) @ 0.1 mV ,
2 V ± (0.8% + 3) @ 0.001 V ,
20 V ± (0.8% + 3) @ 0.01 V ,
200 V ± (0.8% + 3) @ 0.1 V ,
750 V ± (1.2% + 3) @ 1 V |
| DC current measurement: |
2 mA ± (0.8% + 1) @ 0.001 mA ,
20 mA ± (0.8% + 1) @ 0.01 mA ,
200 mA ± (1.5% + 1) @ 0.1 mA ,
20 A ± (2.0% + 5) @ 0.01 A |
| AC current measurement: |
2 mA ± (1.0% + 3) @ 0.001 mA ,
20 mA ± (1.0% + 3) @ 0.01 mA ,
200 mA ± (1.8% + 3) @ 0.1 mA ,
20 A ± (3.0% + 7) @ 0.01 A |
| Resistance measurement: |
200 Ω ± (0.8% + 3) @ 0.1 Ω ,
2 kΩ ± (0.8% + 1) @ 0.001 kΩ ,
20 kΩ ± (0.8% + 1) @ 0.01 kΩ ,
200 kΩ ± (0.8% + 1) @ 0.1 kΩ ,
2 MΩ ± (0.8% + 1) @ 0.001 MΩ
20 MΩ ± (1.0% + 2) @ 0.01 MΩ ,
200 MΩ ± (5%(RD-10) + 10) @ 0.1 MΩ *
*RD - reading value |
| Capacitance measurement: |
2 nF ± (4% + 3) @ 0.001 nF ,
20 nF ± (4% + 3) @ 0.01 nF ,
200 nF ± (4% + 3) @ 0.1 nF ,
2 µF ± (4% + 3) @ 0.001 µF ,
20 µF ± (4% + 3) @ 0.01 µF |
| Inductance measurement: |
 |
| Frequency measurement: |
|
| Temperature measurement: |
|
| Automatic change of measuring ranges: |
|
| hFE: |
 |
| Diode test: |
|
| Sound signal of the continuity test: |
|
| Checking TTL logic states: |
|
| RS-232: |
|
| Main features: |
Large, readable LCD display Low battery level alarm Aesthetic and solid construction |
| Power supply: |
9V, type 6F22 battery - included |
| Weight: |
0.5 kg |
| Dimensions: |
203 x 98 x 56 mm |
| Manufacturer / Brand: |
UNI-T |
| Guarantee: |
2 years |
