| DC voltage measurement: |
200 mV ± (0.7% + 3) @ 0.1 mV ,
2000 mV ± (0.5% + 2) @ 1 mV ,
20 V ± (0.7% + 3) @ 0.01 V ,
200 V ± (0.7% + 3) @ 0.1 V ,
250 V ± (0.7% + 3) @ 1 V |
| AC voltage measurement: |
200 V ± (1.2% + 3) @ 0.1 V ,
250 V ± (1.2% + 3) @ 1 V |
| DC current measurement: |
2000 µA ± (1.0% + 2) @ 1 µA ,
20 mA ± (1.0% + 2) @ 0.01 mA ,
200 mA ± (1.0% + 2) @ 0.1 mA ,
10 A ± (1.2% + 5) @ 0.01 A |
| AC current measurement: |
 |
| Resistance measurement: |
200 Ω ± (1.0% + 2) @ 0.1 Ω ,
2 kΩ ± (0.8% + 2) @ 0.001 kΩ ,
20 kΩ ± (0.8% + 2) @ 0.01 kΩ ,
200 kΩ ± (0.8% + 2) @ 0.1 kΩ ,
20 MΩ ± (1.2% + 3) @ 0.01 MΩ , |
| Capacitance measurement: |
|
| Inductance measurement: |
|
| Frequency measurement: |
|
| Temperature measurement: |
°C :
-40 ... 40 °C ± 4 @ 1 °C ,
>40 ... 500 °C ± (1.0% + 4) @ 1 °C ,
>500 ... 1000 °C ± (2.0% + 4) @ 1 °C ,
°F :
-40 ... 104 °F ± 5 @ 1 °F ,
>104 ... 932 °F ± (1.5% + 5) @ 1 °F ,
>932 ... 1832 °F ± (2.5% + 5) @ 1 °F |
| Automatic change of measuring ranges: |
|
| hFE: |
|
| Diode test: |
 |
| Sound signal of the continuity test: |
|
| Checking TTL logic states: |
|
| RS-232: |
|
| Main features: |
Large, readable LCD display with backlight Hold - stopping the meter reading Low battery indicator Aesthetic and solid construction |
| Power supply: |
2 x 1.5V, type AAA/LR03 battery - included |
| Weight: |
0.21 kg |
| Dimensions: |
134 x 77 x 47 mm |
| Manufacturer / Brand: |
UNI-T |
| Guarantee: |
2 years |
