| DC voltage measurement: |
400 mV ± (1% + 8) @ 0.1 mV ,
4 V ± (0.5% + 5) @ 0.001 V ,
40 V ± (0.5% + 5) @ 0.01 V ,
400 V ± (0.5% + 5) @ 0.1 V ,
600 V ± 0.8% + 5) @ 1 V |
| AC voltage measurement: |
4 V ± (1.2% + 5) @ 0.001 V ,
40 V ± (1.2% + 5) @ 0.01 V ,
400 V ± (2.0% + 10) @ 0.1 V ,
600 V ± (2.0% + 10) @ 1 V |
| DC current measurement: |
400 µA ± (1.8% + 5) @ 0.1 µA ,
4 µA ± (1.8% + 5) @ 0.001 mA ,
40 mA ± (1.8% + 5) @ 0.01 mA ,
400 mA ± (1.8% + 5) @ 0.1 mA |
| AC current measurement: |
400 µA ± (2.0% + 8) @ 0.1 µA ,
4 mA ± (2.0% + 8) @ 0.001 mA ,
40 mA ± (2.0% + 8) @ 0.01 mA ,
400 mA ± (2.0% + 8) @ 0.1 mA , |
| Resistance measurement: |
400 Ω ± (1% + 5) @ 0.1 Ω ,
4 kΩ ± (1% + 5) @ 0.001 kΩ ,
40 kΩ ± (1% + 5) @ 0.01 kΩ ,
400 kΩ ± (1% + 5) @ 0.1 kΩ ,
4 MΩ ± (1.2% + 10) @ 0.001 MΩ ,
40 MΩ ± (2.0% + 10) @ 0.01 MΩ |
| Capacitance measurement: |
50 nF ± (4.0% + 30) @ 0.01 nF ,
500 nF ± (3% + 15) @ 0.1 nF ,
5 µF ± (4.0% + 10) @ 1 nF ,
50 µF ± (4.0% + 10) @ 10 nF ,
100 µF ± (4.0% + 10) @ 100 nF |
| Inductance measurement: |
 |
| Frequency measurement: |
9.999 Hz ~ 60 kHz ± (0.1% + 5) @ 0.001 Hz ~ 0.01 MHz |
| Square-wave signal duty ratio measurement: |
|
| Temperature measurement: |
|
| Automatic change of measuring ranges: |
 |
| hFE: |
|
| Diode test: |
|
| Sound signal of the continuity test: |
|
| Checking TTL logic states: |
|
| RS-232: |
|
| Main features: |
Large, readable LCD display Freezing the last reading Low battery level alarm Aesthetic and solid construction Length of the cables - 75 cm |
| Power supply: |
2 x 1.5V, type AAA/LR03 battery - included |
| Weight: |
0.164 kg |
| Dimensions: |
110 x 58 x 35 mm |
| Manufacturer / Brand: |
UNI-T |
| Guarantee: |
2 years |
