| DC voltage measurement: |
200 mV ± (0.5% + 2) @ 0.1 mV ,
2 V ± (0.5% + 2) @ 1 mV ,
20 V ± (0.5% + 2) @ 10 mV ,
200 V ± (0.5% + 2) @ 100 mV ,
1000 V ± (0.8% + 2) @ 1 V |
| AC voltage measurement: |
2 V ± (0.8% + 5) @ 1 mV ,
20 V ± (0.8% + 5) @ 10 mV ,
200 V ± (0.8% + 5) @ 0.1 V ,
750 V ± (1% + 5) @ 1 V |
| DC current measurement: |
200 mA ± (0.8% + 5) @ 0.1 mA ,
10 A ± (1.2% + 5) @ 10 mA |
| AC current measurement: |
 |
| Resistance measurement: |
200 Ω ± (0.8% + 5) (not included) @ 0.1 Ω ,
2 kΩ ± (0.8% + 5) @ 1 Ω ,
20 kΩ ± (0.8% + 5) @ 10 Ω ,
200 kΩ ± (0.8% + 5) @ 100 Ω ,
2 MΩ ± (0.8% + 5) @ 1 kΩ ,
20 MΩ ± (1.5% + 5) @ 10 kΩ |
| Capacitance measurement: |
|
| Inductance measurement: |
|
| Frequency measurement: |
|
| Square-wave signal duty ratio measurement: |
|
| Temperature measurement: |
|
| Automatic change of measuring ranges: |
|
| hFE: |
|
| Diode test: |
 |
| Sound signal of the continuity test: |
|
| Checking TTL logic states: |
|
| RS-232: |
|
| Main features: |
12V battery voltage test, Measurement of the closing angle of the DWELL circuit breaker : 4Cyl, 6Cyl, 8Cyl, RPM x 10 rotational speed measurement : 4Cyl, 6Cyl, 8Cyl, The following items can be checked: : the ignition coil, high voltage wires, Hall sensor, magnetoresistive sensor, Lambda probe, temperature sensor, position sensor, MAP pressure sensor, MAF air flow sensor, Hold - stopping the meter reading, Large, readable LCD display, Aesthetic and solid construction, Low battery level alarm |
| Power supply: |
9V, type 6LR61 battery - included |
| Weight: |
0.35 kg |
| Dimensions: |
179 x 87 x 39 mm |
| Manufacturer / Brand: |
UNI-T |
| Guarantee: |
2 years |
