IP camera with efficient H.265 / H.264 image compression algorithm for clear and smooth video streaming at maximal resolution of 5 MpxVery easy operation via mobile devices (Android / iOS), allows the users for comfortable and remote operation, and also management of the cameraThe used Wi-Fi module allows to remote communication with camera for max....
2688 x 1512 - 4 Mpx , 2560 x 1440 - 3.7 Mpx , 1920 x 1080 - 1080p , 1280 x 720 - 720p
Lens:
3.6 mm
View angle:
77 ° (manufacturer data) 73 ° (our tests result)
Range of IR illumination:
30 m
Audio:
Microphone built-in, Audio transmission via network
RS-485 interface:
Alarm inputs / outputs:
Image compression method:
H.265+ / H.265 / H.264+ / H.264 / MJPEG
Main stream frame rate:
25 fps @ 4 Mpx
ONVIF:
19.12
Network interface:
10/100 Base-T(RJ-45), Wi-Fi IEEE 802.11 b/g/n
Mobile phones support:
Port no.: 80 or access by a cloud (P2P) Android: Free application BitVision iOS (iPhone): Free application BitVision
Default IP address:
192.168.1.168
Default admin user / password:
admin / admin
Web browser access ports:
80
PC client access ports:
80
Web browser access ports:
80
Mobile client access ports:
80
Port ONVIF:
80
RTSP URL:
rtsp://user:password@ip_address:80/0 - Main stream rtsp://user:password@ip_address:80/1 - Sub stream rtsp://user:password@ip_address:80/2 - Sub stream 2
Memory card slot:
Main features:
Wi-Fi module - IEEE 802.11 b/g/n, Range : 50 m (open area) D-WDR - Wide Dynamic Range3D-DNR - Digital Noise ReductionROI - improve the quality of selected parts of imageF-DNR (Defog) - Reduction of image noise caused by precipitation Flicker Control - The technology eliminates the tiring eyes flickering image effect BLC - Back Light Compensation HLC - High Light Compensation (spot) Built-in Infra-Red illuminator enables night monitoring ICR - Movable InfraRed filterMotion DetectionConfigurable Privacy Zones Possibility to change the resolution, quality and bit rate Sharpness - sharper image outlines
