| Standard: |
TCP/IP |
| Sensor: |
1/3 " Progressive Scan CMOS |
| Matrix size: |
4 Mpx |
| Resolution: |
2688 x 1512 - 4 Mpx ,
2560 x 1440 - 3.7 Mpx ,
1920 x 1080 - 1080p ,
1280 x 720 - 720p |
| Lens: |
3.6 mm |
| View angle: |
77 ° (manufacturer data) 73 ° (our tests result) |
| Range of IR illumination: |
30 m |
| Audio: |
Microphone built-in, Audio transmission via network |
| RS-485 interface: |
 |
| Alarm inputs / outputs: |
|
| Image compression method: |
H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| Main stream frame rate: |
25 fps @ 4 Mpx |
| ONVIF: |
19.12 |
| Network interface: |
10/100 Base-T (RJ-45), Wi-Fi IEEE 802.11 b/g/n |
| Mobile phones support: |
Port no.: 80 or access by a cloud (P2P) Android: Free application BitVision iOS (iPhone): Free application BitVision |
| Default IP address: |
192.168.1.168 |
| Default admin user / password: |
admin / admin |
| Web browser access ports: |
80 |
| PC client access ports: |
80 |
| Web browser access ports: |
80 |
| Mobile client access ports: |
80 |
| Port ONVIF: |
80 |
| RTSP URL: |
rtsp://user:password@ip_address:80/0 - Main stream
rtsp://user:password@ip_address:80/1 - Sub stream
rtsp://user:password@ip_address:80/2 - Sub stream 2 |
| Memory card slot: |
|
| Main features: |
Wi-Fi module - IEEE 802.11 b/g/n, Range : 50 m (open area) D-WDR - Wide Dynamic Range 3D-DNR - Digital Noise Reduction ROI - improve the quality of selected parts of image F-DNR (Defog) - Reduction of image noise caused by precipitation Flicker Control - The technology eliminates the tiring eyes flickering image effect BLC - Back Light Compensation HLC - High Light Compensation (spot) Built-in Infra-Red illuminator enables night monitoring ICR - Movable InfraRed filter Motion Detection Configurable Privacy Zones Possibility to change the resolution, quality and bit rate Sharpness - sharper image outlines |
| Power supply: |
12 V DC / 350 mA |
| Power consumption: |
≤ 4.2 W |
| Housing: |
Plastic + Metal - Compact |
| "Index of Protection": |
IP67 |
| Vandal-proof: |
|
| Weight: |
0.27 kg |
| Dimensions: |
72 x 78 x 180 mm |
| Operation temp: |
-20 ... 60 °C |
| Supported languages: |
Polish, English, Bulgarian, Czech, French, Spanish, Dutch, German, Portuguese, Russian, Turkish, Italian |
| Manufacturer / Brand: |
APTI |
| Guarantee: |
2 years |
