VIGI NVR2016H-16P
VIGI 16 Channel PoE+ Network Video Recorder
4K HDMI Video Output & 16MP Decoding Capacity: Sharp image definition up to 8MP, and 8-ch@2MP† decoding capacity allows you to enjoy more-channels live view and playback at the same time.
90 W PoE Budget: 16× 802.3af/at-compliant PoE+ ports with a total power supply of 90 W.‡
16-Channel Simultaneous Playback*: Replay the feed from up to 16 cameras at the same time, increase replay speed, and find events in the video schedule to easily review footage.
H.265+: Compresses the video size without sacrificing video quality, easing the network load and saving disk space.
ONVIF Ensures Compatibility△: Easily add IPCs from VIGI and other brands to establish a powerful and varied network thanks to barrier-free compatibility.
Auto Initialize for Quick Configuration: Just click "Auto Initialize" to set up basic IPC and hard disk parameters, significantly reducing your configuration time.
24/7 Continuous Recording: Stores up to 20 TB of footage (1048 storage days***) from connected cameras to secure your data for quick, convenient access.
Two-Way Audio: With voice intercom support, scare off any potential thieves or intruders from wherever you are.
Remote Monitoring: The dedicated VIGI app and client enable remote monitoring, providing ease and convenience.
Channels 16 | Drives/bays 2 | Power supply requirements 100–240 VAC, 50/60Hz | Power consumption 25.5 Watts | Dim. 375.0 mm × 327.4 mm × 53.0 mm | Colour Black
Drives/bays 12 | CPU Intel Xeon Silver | Memory (RAM) 16GB | Power supply requirements 2 x 800 W hot-plug redundant power supplies (included) (100–240 V AC, 9.2–4.7 A, 50/60 Hz) | Dim. 721.62 x 482 x 87 mm | Temp. range 10°C to 35 °C
Drives/bays 12 | CPU Intel Xeon Silver | Memory (RAM) 32GB | Power supply requirements 2 x 800 W hot-plug redundant power supplies (included) (100–240 V AC, 9.2–4.7 A, 50/60 Hz) | Dim. 721.62 x 482 x 87 mm | Temp. range 10°C to 35 °C
Channels 8 | Drives/bays 1 | CPU Industrial-grade processor | Power supply requirements 12 VDC, 2A | Power consumption 7.8 Watts | Dim. 260 × 232.7 × 47.6mm | Temp. range –10 °C to +55 °C | Colour Black
Channels 8 | Integrated LAN Gigabit | Power supply requirements 53 VDC, 1.812 A | Power consumption 10 Watts | Dim. 270 × 206.2 × 47.5 mm | Temp. range –10 °C to +55 °C | Colour White
Channels 4 | Drives/bays 1 | Power supply requirements 53 VDC, 1.226 A | Power consumption 36 Watts | Dim. 204.6 mm × 206.4 mm × 45.6 mm | Temp. range –10 °C to +55 °C | Colour White
Channels 8 | Drives/bays 2 | CPU Quad-core embedded processor | Power supply requirements DC12V/4A | Power consumption 9.5 Watts | Dim. 375 x 329.5 x 53 mm | Temp. range -10°C~+55°C
Channels 8 | CPU Industrial-grade | Integrated LAN Gigabit | Power supply requirements 100–240 VAC, 50/60 Hz | Dim. 375.0 × 327.9 × 53.0 mm | Temp. range –10 °C to +55 °C | Colour Black
