Описание
Supports AMD Ryzen™ 7000 Series Processors 14+2+1 Phase Power Design, SPS 4 x DDR5 DIMMs, supports up to 6600+(OC) 1 PCIe 5.0 x16, 1 PCIe 3.0 x16, 1 PCIe 4.0 x1, 1 M.2 Key-E for WiFi Graphics Output Options: 1 HDMI 7.1 CH HD Audio (Realtek ALC897 Audio Codec), Nahimic Audio 1 Blazing M.2 (PCIe Gen5x4), 1 Hyper M.2 (PCIe Gen4x4), 1 M.2 (PCIe Gen3x2 & SATA3), 4 SATA3 1 USB 3.2 Gen2x2 Type-C (Front), 1 USB 3.2 Gen2 Type-C (Rear), 1 USB 3.2 Gen2 Type-A (Rear), 4 USB 3.2 Gen1 (2 Rear, 2 Front), 9 USB 2.0 (6 Rear, 3 Front) Killer 2.5G LAN 802.11ax Wi-Fi 6E + Bluetooth
Спецификации
Код
B650PGLIGHTNING
Срок доставки 2-5 рабочих дней.
10 шт.
Дополнительная информация
Сайт продавца
https://www.asrock.com/mb/AMD/B650%20PG%20Lightning/index.asp
Гарантия
36
Модель
B650 PG Lightning
Код категории
MBA
Высота блока
0.3
Длина блока
0.075
Ширина блока
0.355
Units per Shipping Box
5
Unit Calculated Volume
0.009768 cubm
Unit Calculated Weight
1.97 kg
CnCode
84733020
Summary
Asrock B650 PG Lightning. Processor manufacturer: AMD, Processor socket: Socket AM5. Supported memory types: DDR5-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA II, Supported storage drive ty
Weight & dimensions (Width)
305 mm
Weight & dimensions (Depth)
244 mm
Packaging content (Cables included)
SATA
Network (Bluetooth)
Yes
Network (Ethernet LAN)
Yes
Network (Wi-Fi)
Yes
Processor (Processor manufacturer)
AMD
Graphics (Graphics card family)
AMD
Network (Top Wi-Fi standard)
Wi-Fi 6E (802.11ax)
Features (Component for)
PC
Graphics (Graphics card)
AMD RDNA 2
Memory (Maximum internal memory)
128 GB
Memory (Memory channels)
Dual-channel
Graphics (On-board graphics card)
Yes
Network (LAN controller)
Dragon RTL8125BG
Expansion slots (PCI Express x16 (Gen 5.x) slots)
1
Processor (Processor socket)
Socket AM5
Memory (Memory slots type)
DIMM
Memory (Number of memory slots)
4
Memory (Supported memory clock speeds)
6400/6600/6666/6800 MHz
Memory (Supported memory types)
DDR5-SDRAM
Memory (Unbuffered memory)
Yes
Storage controllers (Supported storage drive interfaces)
M.2,SATA II
Storage controllers (Supported storage drive types)
HDD & SSD
Internal I/O (ATX Power connector (24-pin))
Yes
Internal I/O (CPU fan connector)
Yes
Internal I/O (EPS power connector (8-pin))
Yes
Internal I/O (Front panel audio connector)
Yes
Internal I/O (Number of SATA III connectors)
4
Internal I/O (RGB LED pin header)
Yes
Internal I/O (TPM connector)
Yes
Internal I/O (USB 2.0 connectors)
2
Internal I/O (USB 3.2 Gen 1 (3.1 Gen 1) connectors)
1
Rear panel I/O ports (Ethernet LAN (RJ-45) ports)
1
Rear panel I/O ports (HDMI ports quantity)
1
Rear panel I/O ports (Line-in)
Yes
Rear panel I/O ports (USB 2.0 ports quantity)
4
Network (Ethernet interface type)
2.5 Gigabit Ethernet
Features (Audio output channels)
7.1 channels
Features (Motherboard chipset)
AMD B650
Features (Motherboard chipset family)
AMD
Features (Motherboard form factor)
ATX
Features (Windows operating systems supported)
Windows 10 x64/Windows 11 x64
Expansion slots (PCI Express x16 (Gen 4.x) slots)
1
BIOS (BIOS memory size)
256 Mbit
BIOS (BIOS type)
UEFI AMI
Storage controllers (RAID levels)
0/1/10
Storage controllers (RAID support)
Yes
Internal I/O (USB 3.2 Gen 2 (3.1 Gen 2) connectors)
1
Rear panel I/O ports (USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity)
7
Memory (ECC сompatibility)
ECC & Non-ECC
Graphics (HDCP)
Yes
Expansion slots (PCI Express x16 (Gen 3.x) slots)
1
Rear panel I/O ports (USB 3.2 Gen 2x2 Type-C ports quantity)
1
Специальные референции
ean13
4710483940910
MPN
1386732
