Description
- Supports AMD Ryzen™ 7000 Series Processors
- 14+2+1 Phase Power Design, SPS
- 4 x DDR5 DIMMs, supports up to 6600+(OC)
- 1 PCIe 5.0 x16, 1 PCIe 3.0 x16, 1 PCIe 4.0 x1, 1 M.2 Key-E for WiFi
- Graphics Output Options: 1 HDMI
- 7.1 CH HD Audio (Realtek ALC897 Audio Codec), Nahimic Audio
- 1 Blazing M.2 (PCIe Gen5x4), 1 Hyper M.2 (PCIe Gen4x4), 1 M.2 (PCIe Gen3x2 & SATA3), 4 SATA3
- 1 USB 3.2 Gen2x2 Type-C (Front), 1 USB 3.2 Gen2 Type-C (Rear), 1 USB 3.2 Gen2 Type-A (Rear), 4 USB 3.2 Gen1 (2 Rear, 2 Front), 9 USB 2.0 (6 Rear, 3 Front)
- Killer 2.5G LAN
- 802.11ax Wi-Fi 6E + Bluetooth
Product Details
B650PGLIGHTNING
5 Items
Data sheet
- Vendor Homepage
- https://www.asrock.com/mb/AMD/B650%20PG%20Lightning/index.asp
- Garantija
- 36
- Model
- B650 PG Lightning
- Category Code
- MBA
- Unit Box Height
- 0.08
- Unit Box Length
- 0.36
- Unit Box Width
- 0.3
- Units per Shipping Box
- 1
- Unit Calculated Volume
- 0.00864 cubm
- Unit Calculated Weight
- 1.71 kg
- Summary
- Asrock B650 PG Lightning. Processor manufacturer: AMD, Processor socket: Socket AM5. Supported memory types: DDR5-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA II, Supported storage drive ty
- Weight & dimensions (Width)
- 305 mm
- Weight & dimensions (Depth)
- 244 mm
- Packaging content (Cables included)
- SATA
- Network (Bluetooth)
- Yes
- Network (Ethernet LAN)
- Yes
- Network (Wi-Fi)
- Yes
- Processor (Processor manufacturer)
- AMD
- Graphics (Graphics card family)
- AMD
- Network (Top Wi-Fi standard)
- Wi-Fi 6E (802.11ax)
- Features (Component for)
- PC
- Graphics (Graphics card)
- AMD RDNA 2
- Memory (Maximum internal memory)
- 128 GB
- Memory (Memory channels)
- Dual-channel
- Graphics (On-board graphics card)
- Yes
- Network (LAN controller)
- Dragon RTL8125BG
- Expansion slots (PCI Express x16 (Gen 5.x) slots)
- 1
- Processor (Processor socket)
- Socket AM5
- Memory (Memory slots type)
- DIMM
- Memory (Number of memory slots)
- 4
- Memory (Supported memory clock speeds)
- 6400/6600/6666/6800 MHz
- Memory (Supported memory types)
- DDR5-SDRAM
- Memory (Unbuffered memory)
- Yes
- Storage controllers (Supported storage drive interfaces)
- M.2,SATA II
- Storage controllers (Supported storage drive types)
- HDD & SSD
- Internal I/O (ATX Power connector (24-pin))
- Yes
- Internal I/O (CPU fan connector)
- Yes
- Internal I/O (EPS power connector (8-pin))
- Yes
- Internal I/O (Front panel audio connector)
- Yes
- Internal I/O (Number of SATA III connectors)
- 4
- Internal I/O (RGB LED pin header)
- Yes
- Internal I/O (TPM connector)
- Yes
- Internal I/O (USB 2.0 connectors)
- 2
- Internal I/O (USB 3.2 Gen 1 (3.1 Gen 1) connectors)
- 1
- Rear panel I/O ports (Ethernet LAN (RJ-45) ports)
- 1
- Rear panel I/O ports (HDMI ports quantity)
- 1
- Rear panel I/O ports (Line-in)
- Yes
- Rear panel I/O ports (USB 2.0 ports quantity)
- 4
- Network (Ethernet interface type)
- 2.5 Gigabit Ethernet
- Features (Audio output channels)
- 7.1 channels
- Features (Motherboard chipset)
- AMD B650
- Features (Motherboard chipset family)
- AMD
- Features (Motherboard form factor)
- ATX
- Features (Windows operating systems supported)
- Windows 10 x64/Windows 11 x64
- Expansion slots (PCI Express x16 (Gen 4.x) slots)
- 1
- BIOS (BIOS memory size)
- 256 Mbit
- BIOS (BIOS type)
- UEFI AMI
- Storage controllers (RAID levels)
- 0/1/10
- Storage controllers (RAID support)
- Yes
- Internal I/O (USB 3.2 Gen 2 (3.1 Gen 2) connectors)
- 1
- Rear panel I/O ports (USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity)
- 7
- Memory (ECC сompatibility)
- ECC & Non-ECC
- Graphics (HDCP)
- Yes
- Expansion slots (PCI Express x16 (Gen 3.x) slots)
- 1
- Rear panel I/O ports (USB 3.2 Gen 2x2 Type-C ports quantity)
- 1
Specific References
- EAN13
- 4710483940910
- MPN
- 1386732
