Power Supply|BE QUIET|Pure Power 13|1000 Watts|Peak Power 1050 Watts|Efficiency 80 PLUS GOLD|PFC Active|MTBF 100000 hours|BP028E
  • Power Supply|BE QUIET|Pure Power 13|1000 Watts|Peak Power 1050 Watts|Efficiency 80 PLUS GOLD|PFC Active|MTBF 100000 hours|BP028E

Power Supply|BE QUIET|Pure Power 13|1000 Watts|Peak Power 1050 Watts|Efficiency 80 PLUS GOLD|PFC Active|MTBF 100000 hours|BP028E

BP028EU
BE QUIET
1000 W | 100 - 240 V | Efficiency 92.5 % | 80 PLUS certification 80 PLUS Gold | PC | ATX | Noise level 30.3 dB | Fan diameter 120 mm | Weight 2.64 kg | Pure Power 13
€174.53
VAT included
Quantity
Laos
16 Items

Description

Exceptional quiet, superior features
Pure Power 13 M 1000W is an ATX 3.1 compliant and PCIe 5.1 compatible power supply with semi-passive cooling. It offers peerless dependability with best-in-class features. Having both a PCIe 5.1 cable and PCIe 6+2 cables in the scope of delivery, this PSU offers outstanding compatibility with current-gen and next-gen graphics cards. Pure Power 13 M 1000W offers the best combination of features with outstanding compatibility.

  • 80 PLUS® Gold efficiency (up to 94.4%)
  • ATX 3.1 PSU with full support for PCIe 5.1 GPUs and GPUs with 6+2 pin connectors
  • Handles massive power excursions
  • Exceptionally silent semi-passive 120mm be quiet! fan
  • Semi-passive construction for quiet and energy-saving operation
  • LLC technology for advanced stability and voltage regulation
  • One massive high-performance 12V-rail
  • One PCIe 5.1 12V-2x6 600W and 4 PCIe 6+2 connectors for overclocked high-end GPUs
  • Full suite of safety features
  • Meets latest requirements for modern standby
Product Details
BE QUIET
BP028EU
16 Items

Data sheet

Vendor Homepage
https://www.bequiet.com/en/download/powersupply/5931?utm_source newsletter
Model name
Pure Power 13
Garantija
24
Category Code
PSU
Unit Box Height
0.2
Unit Box Length
0.29
Unit Box Width
0.1
Units per Shipping Box
6
Unit Calculated Volume
0.008081 cubm
Unit Calculated Weight
3.29 kg
Summary
be quiet! Pure Power 13 M | 1000W. Total power: 1000 W, AC input voltage: 100 - 240 V, Peak power: 1050 W. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 55 cm, SATA power cable length: 500,650,800,950 mm. Purpose: PC, Power su
Weight & dimensions (Width)
150 mm
Weight & dimensions (Depth)
160 mm
Weight & dimensions (Height)
86 mm
Weight & dimensions (Weight)
2640 g
Packaging data (Package width)
210 mm
Packaging data (Package depth)
320 mm
Packaging data (Package height)
133 mm
Packaging data (Package weight)
3400 g
Packaging content (Cables included)
AC,CPU,PCIe,Peripheral (Molex),SATA
Certificates (Compliance certificates)
BSMI/CB/CCC/CE/cTUVus/Federal Communications Commission (FCC)/IRAM/RCM/RoHS/T V mark/UKCA/WEEE
Operational conditions (Operating temperature (T-T))
0 - 40 C
Logistics data (Shipping (inner) case gross weight)
22700 g
Logistics data (Shipping (inner) case height)
233 mm
Logistics data (Shipping (inner) case length)
580 mm
Logistics data (Shipping (inner) case width)
325 mm
Design (Product colour)
Black
Power (AC input frequency)
50/60 Hz
Power (AC input voltage)
100 - 240 V
Design (Cooling type)
Active
Design (Number of fans)
1 fan(s)
Performance (Noise level)
30.3 dB
Design (Fan diameter)
120 mm
Logistics data (Products per shipping (inner) case)
6 pc(s)
Design (On/off switch)
Yes
Power (Combined power (+12V))
1000 W
Power (Combined power (+3.3V))
120 W
Power (Combined power (+5V))
120 W
Power (Combined power (+5Vsb))
15 W
Power (Combined power (-12V))
3.6 W
Power (Max output current (+3.3V))
22 A
Power (Max output current (+5V))
22 A
Power (Max output current (+5Vsb))
3 A
Power (Max output current (-12V))
0.3 A
Power (Power protection features)
Over current/Over power/Over voltage/Overheating/Short circuit/Surge & inrush protection (SIP)/Under voltage
Power (Total power)
1000 W
Ports & interfaces (Cabling type)
Fully-Modular
Ports & interfaces (Motherboard power cable length)
550 mm
Ports & interfaces (Motherboard power connector)
20+4 pin ATX
Ports & interfaces (Number of SATA power connectors)
6
Ports & interfaces (Peripheral (Molex) power cable length)
800/950 mm
Ports & interfaces (Peripheral (Molex) power connectors (4-pin))
2
Ports & interfaces (SATA power cable length)
500/650/800/950 mm
Performance (80 PLUS certification)
80 PLUS Gold
Performance (Mean time between failures (MTBF))
100000 h
Performance (Power supply unit (PSU) form factor)
ATX
Performance (Purpose)
PC
Power (Peak power)
1050 W
Power (Power Factor Correction (PFC) type)
Active
Ports & interfaces (CPU P4 connector (4-pin))
2
Performance (ATX version)
3.1
Power (Efficiency)
92.5 %
Ports & interfaces (CPU power connector (4+4 pin))
Yes
Ports & interfaces (PCI Express power connectors (6+2 pin))
4
Performance (Bearing technology)
Rifle
Technical details (Sustainability certificates)
ENERGY STAR/ErP
Performance (EPS version)
2.92
Design (Fan speed)
0 - 2000 RPM
Power (Maximum input current (@110V))
12 A
Power (Maximum input current (@220V))
6 A
Ports & interfaces (CPU power cable length)
650 mm
Ports & interfaces (EPS power connector (8-pin))
Yes
Power (Hold time)
21.09 ms
Power (Power factor)
0.98
Power (Max output current (+12V1))
83.4 A
Other features (Screws included)
Yes
Ports & interfaces (PCI Express power connectors (12-pin))
1
Power (Number of +12V rail(s))
1
Other features (Cable ties included)
Yes

Specific References

EAN13
4260052192207
MPN
1442607
