NET CAMERA 4MP BULLET/HFW5459T1ASEPV0280BPROB DAHUA

Data sheet

Vendor Homepage

https://www.dahuasecurity.com/ceen/products/All-Products/Network-Cameras/WizMind-5-Series/Pro/4MP/IPC-HFW5459T1-ASE-PV-PRO

Garantija

36

Category Code

FNC

Unit Calculated Volume

0.003657 cubm

Unit Calculated Weight

1.2 kg

Summary

Dahua Technology WizMind IPC-HFW5459T1-ASE-PV-0280B-PRO-Black. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/Wall/Pole, Product colour: Black, Form factor: Bullet. Minimum illumination: 0.00

Weight & dimensions (Width)

94.4 mm

Weight & dimensions (Height)

84.7 mm

Weight & dimensions (Weight)

1090 g

Packaging data (Package weight)

1390 g

Operational conditions (Operating temperature (T-T))

-40 - 60 C

Operational conditions (Storage temperature (T-T))

-40 - 60 C

System requirements (Mobile operating systems supported)

Android/iOS

Network (Bluetooth)

No

Network (Ethernet LAN)

Yes

Network (Wi-Fi)

No

Design (Product colour)

Black

Power (Power consumption (max))

21.6 W

Power (Power consumption (typical))

4.1 W

Ports & interfaces (Ethernet LAN (RJ-45) ports)

1

Design (Housing material)

Metal/Plastic

Packaging content (Manual)

Yes

Ports & interfaces (DC-in jack)

Yes

Design (Form factor)

Bullet

Weight & dimensions (Length)

288.4 mm

Camera (Camera shutter speed)

1/3 - 1/100000 s

Storage (Compatible memory cards)

MicroSD (TransFlash)

Storage (Maximum memory card size)

1000 GB

Power (Power source type)

DC,PoE

Sustainability (Compliance certificates)

CE

Storage (Card reader integrated)

Yes

Performance (Wide Dynamic Range (WDR))

Yes

Audio (Built-in speaker(s))

Yes

Audio (Built-in microphone)

Yes

Storage (RAM capacity)

2048 MB

Audio (Number of microphones)

2

Network (Ethernet interface type)

Fast Ethernet

Design (IK code)

IK10

Design (International Protection (IP) code)

IP67

Design (Mounting type)

Ceiling/Wall/Pole

Performance (Connectivity technology)

Wired

Performance (Day/night mode)

Yes

Performance (Placement supported)

Outdoor

Performance (Type)

IP security camera

Camera (Camera pan control)

Yes

Camera (Camera tilt control)

Yes

Camera (Lens viewing angle, diagonal)

135

Camera (Lens viewing angle, horizontal)

111

Camera (Lens viewing angle, vertical)

60

Image sensor (Optical sensor size)

1/1.8 "

Night vision (LED type)

IR

Night vision (Night vision)

Yes

Night vision (Night vision distance)

80 m

Video (Frame rate)

30 fps

Video (Maximum resolution)

2688 x 1520 pixels

Video (Noise reduction)

Yes

Video (Noise reduction technology)

3D noise reduction

Video (Total megapixels)

4 MP

Storage (Built-in HDD)

No

Security (Intelligent Video Surveillance (IVS) system features)

Intrusion/People counting/Tripwire

Power (DC output voltage)

12

Packaging content (Number of cameras)

1

Image sensor (Sensor type)

CMOS

Security (Alarm input channels)

1

Security (Alarm output channels)

1

Lens system (Fixed focal length)

2.8 mm

Performance (Alarm input/output)

Yes

Camera (Minimum illumination)

0.0001 lx

Video (Back Light Compensation (BLC))

Yes

Video (Highlight Compensation (HLC))

Yes

Image sensor (Progressive scan)

Yes

Lens system (Maximum aperture number)

1

Video (Gain control type)

Auto/Manual

Ports & interfaces (RS-485 ports)

1

Video (Region of Interest (ROI) encoding)

Yes

Security (Video motion detection)

Yes

Video (Video compression formats)

H.264/H.264B/H.264H/H.265/M-JPEG

Camera (Angle of rotation)

360

Camera (Pan range)

0 - 360

Camera (Tilt angle range)

0 - 90

Camera (White balance)

Auto/Manual/Natural/Outdoor/Regional custom/Street lamp

Video (Bit rate control)

Constant Bit Rate (CBR),Variable Bit Rate (VBR)

Video (Video streaming)

Yes

Audio (Audio formats supported)

G.711 -law/G.711 A-law/G.723/G.726/PCM

Audio (Signal-to-Noise Ratio (SNR))

56 dB

Network (Quality of Service (QoS) support)

Yes

Network (Streaming method)

Multicast

Network (Supported network protocols)

IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, P2P

Storage (ROM capacity)

4096 MB

Video (Smart IR)

Yes

Lens system (Closest focusing distance)

2 m

Night vision (Number of illumination LEDs)

4

Network (Number of users)

20 user(s)

Security (HTTPS encryption)

Yes

Security (Mirror)

Yes

Performance (Dynamic range)

140 dB

Lens system (Detect distance)

56.6 m

Lens system (Identify distance)

5.7 m

Lens system (Observe distance)

22.6 m

Lens system (Recognize distance)

11.3 m

Video (Video recording)

Yes

Network (Networking standards)

IEEE 802.1x/IEEE 802.3at

Security (Network access storage (NAS))

Yes

Security (Human and vehicle targets classification)

Yes

Security (Digital watermark)

Yes

Performance (People counting function)

Yes

Specific References

MPN

1459791
