NET CAMERA 4MP IR DOME/VIGI INSIGHT S245ZI TP-LINK

Data sheet

Vendor Homepage

https://www.tp-link.com/en/business-networking/vigi-network-camera/insight-s245zi/

Garantija

36

Model

InSight S245ZI

Category Code

FNC

Unit Box Height

0.175

Unit Box Length

0.17

Unit Box Width

0.17

Units per Shipping Box

1

Unit Calculated Volume

0.005058 cubm

Unit Calculated Weight

1.11 kg

Summary

TP-Link VIGI InSight S245ZI. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Dome. Lens viewing angle, horizontal: 29.6 - 102 , Lens viewing angle, vertica

Weight & dimensions (Width)

129.9 mm

Weight & dimensions (Depth)

129.9 mm

Weight & dimensions (Height)

102.5 mm

Weight & dimensions (Weight)

775 g

Packaging data (Package type)

Box

Operational conditions (Operating temperature (T-T))

-30 - 60 C

Operational conditions (Storage relative humidity (H-H))

0 - 95 %

Operational conditions (Storage temperature (T-T))

-40 - 60 C

Audio (Audio output channels)

1.0 channels

Network (Bluetooth)

No

Network (Ethernet LAN)

Yes

Network (Wi-Fi)

No

Design (Product colour)

White

Power (Power consumption (max))

10.8 W

Ports & interfaces (Ethernet LAN (RJ-45) ports)

1

Design (Housing material)

Metal

Packaging content (Manual)

Yes

Operational conditions (Operating relative humidity (H-H))

0 - 95 %

Ports & interfaces (DC-in jack)

Yes

Design (Form factor)

Dome

Camera (Camera shutter speed)

1/3 to 1/10000 s

Audio (Audio system)

2-way

Storage (Compatible memory cards)

MicroSD (TransFlash)

Storage (Maximum memory card size)

512 GB

Power (Power source type)

DC,PoE

Performance (Wide Dynamic Range (WDR))

Yes

Audio (Built-in speaker(s))

Yes

Audio (Built-in microphone)

Yes

Design (Protection features)

Waterproof

Security (Password protection)

Yes

Audio (Number of microphones)

1

Design (IK code)

IK10

Design (International Protection (IP) code)

IP67

Design (Mounting type)

Ceiling

Design (Weatherproof)

Yes

Performance (Connectivity technology)

Wired

Performance (Day/night mode)

Yes

Performance (Infrared (IR) cut-off filter)

Yes

Performance (Placement supported)

Outdoor

Performance (Type)

IP security camera

Camera (Camera pan control)

Yes

Camera (Camera tilt control)

Yes

Camera (Lens viewing angle, diagonal)

34.1 - 122.8

Camera (Lens viewing angle, horizontal)

29.6 - 102

Camera (Lens viewing angle, vertical)

16.8 - 53.8

Image sensor (Optical sensor size)

1/2.9 "

Night vision (LED type)

IR/White

Night vision (Night vision)

Yes

Video (Image quality adjustment)

Brightness/Contrast/Mirror/Saturation/Sharpness

Video (Maximum resolution)

2688 x 1520 pixels

Video (Total megapixels)

4 MP

Security (Intelligent Video Surveillance (IVS) system features)

Abnormal sound detection/Crossing line/Human detection/Intrusion/Line crossing detection/Moving object/Region entrance detection/Region exiting detection/Scene change/Vehicle detection

Management features (Reset button)

Yes

Power (DC output voltage)

12

Packaging content (Number of cameras)

1

Image sensor (Sensor type)

CMOS

Audio (Audio input channels)

1.0 channels

Camera (Minimum illumination)

0 lx

Video (Back Light Compensation (BLC))

Yes

Video (Highlight Compensation (HLC))

Yes

Image sensor (Progressive scan)

Yes

Lens system (Maximum aperture number)

1.6

Security (Built-in siren)

Yes

Security (Video motion detection)

Yes

Video (Video compression formats)

H.264/H.264+/H.265/H.265+

Video (Digital Wide Dynamic Range (DWDR))

Yes

Camera (Tilt angle range)

0 - 75

Video (Bit rate control)

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Video (Supported graphics resolutions)

1280 x 720 (HD 720)/1920 x 1080 (HD 1080)/2048 x 1280/2304 x 1296/2560 x 1440/2688 x 1520

Audio (Audio formats supported)

G.711 A-law

Network (Supported network protocols)

TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP

Management features (Web browser)

Yes

Security (HTTPS encryption)

Yes

Security (Mirror)

Yes

Management features (Web-based management)

Yes

Power (Power consumption (Power over Ethernet (PoE)))

12 W

Performance (Dynamic range)

120 dB

Lens system (Detect distance)

200 m

Lens system (Identify distance)

21 m

Lens system (Observe distance)

84 m

Lens system (Recognize distance)

40 m

Video (Bit rate)

Main Stream: H.265+/H.265/H.264+/H.264, Sub-Stream: H.265/H.264

Audio (Bit rate range)

0 - 64 Kbit/s

Video (Video recording)

Yes

Network (Live view)

Yes

Security (Motion sensor)

Yes

Security (IP address filtering)

Yes

Network (Networking standards)

IEEE 802.3af/IEEE 802.3at

Security (Digest authentication)

Yes

Audio (Sample rate)

8 kHz

Management features (Cloud-managed)

Yes

Security (Human and vehicle targets classification)

Yes

Performance (Remote viewing)

Yes

Lens system (Auto focus)

Yes

Security (Detection distance)

200 m

Performance (Maximum operating distance)

200 m

Lens system (Focus)

Motorized

Lens system (Optical zoom)

5 x

Security (Alert notification type)

Push notification

Specific References

EAN13

8885020623598

MPN

1445896
