NET CAMERA 5MP IR BULLET/UVC-G5-BULLET UBIQUITI

Data sheet

Vendor Homepage

https://store.ui.com/collections/unifi-protect-cameras/products/uvc-g5-bullet

Garantija

12

Model

G5 Bullet

Category Code

FNC

Unit Box Height

0.1

Unit Box Length

0.23

Unit Box Width

0.1

Units per Shipping Box

1

Unit Calculated Volume

0.0023 cubm

Unit Calculated Weight

0.5 kg

Summary

Ubiquiti G5 Bullet. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Wall/Pole, Product colour: Black, White, Form factor: Bullet. Lens viewing angle, horizontal: 84.4 , Lens viewing angle, ve

Weight & dimensions (Weight)

225 g

Operational conditions (Operating temperature (T-T))

-20 - 40 C

Sustainability (Sustainability compliance)

Yes

Weight & dimensions (Diameter)

75.5 mm

Network (Bluetooth)

No

Network (Ethernet LAN)

Yes

Network (Wi-Fi)

No

Design (Product colour)

Black/White

Power (Power consumption (max))

4 W

Ports & interfaces (Ethernet LAN (RJ-45) ports)

1

Design (Housing material)

Aluminium/Polycarbonate (PC)

Operational conditions (Operating relative humidity (H-H))

0 - 90 %

Design (Form factor)

Bullet

Weight & dimensions (Length)

74.4 mm

Power (Power source type)

PoE

Sustainability (Compliance certificates)

CE/Federal Communications Commission (FCC)

Audio (Built-in microphone)

Yes

Network (Ethernet interface type)

Fast Ethernet

Performance (Built-in processor)

Yes

Design (IK code)

IK04

Design (International Protection (IP) code)

IP55

Design (Mounting type)

Wall/Pole

Performance (Connectivity technology)

Wired

Performance (Infrared (IR) cut-off filter)

Yes

Performance (Placement supported)

Indoor & outdoor

Performance (Processor model)

ARM Cortex-A7

Performance (Type)

IP security camera

Camera (Lens viewing angle, diagonal)

99.8

Camera (Lens viewing angle, horizontal)

84.4

Camera (Lens viewing angle, vertical)

45.4

Lens system (Number of lenses)

1

Night vision (LED type)

IR

Night vision (Night vision)

Yes

Video (Frame rate)

30 fps

Video (Image quality adjustment)

Brightness/Contrast/Sharpness

Video (Maximum resolution)

2688 x 1512 pixels

Video (Noise reduction)

Yes

Video (Noise reduction technology)

2D noise reduction,3D noise reduction

Video (Privacy masking)

Yes

Video (Text caption overlay)

Yes

Video (Total megapixels)

4 MP

Management features (Reset button)

Yes

Power (DC output voltage)

37,57

Packaging content (Number of cameras)

1

Image sensor (Sensor type)

CMOS

Video (Video compression formats)

H.264/M-JPEG

Video (Supported graphics resolutions)

2688 x 1512

Management features (Management software)

UniFi Protect

Video (Supported video modes)

1512p

Specific References

EAN13

810084690185

MPN

1392267
