| DC voltage measurement: |
200 mV ± (0.7% + 3) @ 0.1 mV ,
2000 mV ± (0.5% + 2) @ 1 mV ,
20 V ± (0.7% + 3) @ 10 mV ,
200 V ± (0.7% + 3) @ 100 mV ,
600 V ± (0.7% + 3) @ 1 V |
| AC voltage measurement: |
200 mV ± (1.0% + 2) @ 0.1 mV ,
2 V ± (0.7% + 3) @ 1 mV ,
20 V ± (1.0% + 2) @ 10 mV ,
200 V ± (1.2% + 3) @ 100 mV ,
600 V ± (1.2% + 3) @ 1 V |
| DC current measurement: |
200 µA ± (1% + 2) @ 0.1 µA ,
2000 µA ± (1% + 2) @ 1 µA ,
20 mA ± (1% + 2) @ 10 µA ,
200 mA ± (1% + 2) @ 100 µA ,
2 A ± (1.2% + 5) @ 1 mA ,
10 A ± (1.2% + 5) @ 10 mA |
| AC current measurement: |
200 µA ± (1.2% + 3) @ 0.1 µA ,
2000 µA ± (1.2% + 3) @ 1 µA ,
20 mA ± (1.2% + 3) @ 0.01 mA ,
200 mA ± (1.2% + 3) @ 0.1 mA ,
2 A ± (1.5% + 5) @ 1 mA ,
10 µA ± (1.5% + 5) @ 10 mA |
| Resistance measurement: |
200 Ω ± (1% + 2) @ 0.1 Ω ,
2 kΩ ± (0.8% + 2) @ 1 Ω ,
20 kΩ ± (0.8% + 2) @ 10 Ω ,
200 kΩ ± (0.8% + 2) @ 100 Ω ,
20 MΩ ± (1.2% + 3) @ 10 kΩ ,
200 MΩ ± (5% + 10) @ 100 kΩ |
| Capacitance measurement: |
2 nF ± (5% + 5) @ 0.001 nF ,
20 nF ± (4% + 8) @ 0.01 nF ,
200 nF ± (4% + 8) @ 0.1 nF ,
2 µF ± (4% + 8) @ 0.001 µF ,
20 µF ± (4% + 8) @ 0.01 µF ,
200 µF ± (4% + 8) @ 0.1 µF ,
2 mF ± (10%) @ 0.001 mF |
| Inductance measurement: |
 |
| Frequency measurement: |
|
| Temperature measurement: |
|
| Automatic change of measuring ranges: |
 |
| hFE: |
|
| Diode test: |
|
| Sound signal of the continuity test: |
|
| Checking TTL logic states: |
|
| RS-232: |
|
| Main features: |
Large, readable LCD display with backlight Freezing the last reading Low battery level alarm Aesthetic and solid construction |
| Power supply: |
2 x 1.5V, type AAA/LR03 battery - included |
| Weight: |
0.26 kg |
| Dimensions: |
134 x 77 x 47 mm |
| Manufacturer / Brand: |
UNI-T |
| Guarantee: |
2 years |
