Drone|DJI|Matrice 3TD|Enterprise|CP.EN.00000516.03

Data sheet

Vendor Homepage

https://enterprise.dji.com/dock-2

Model name

Matrice 3TD

Garantija

24L

Drone product line

Enterprise

Category Code

DRO

Unit Box Height

0.22

Unit Box Length

0.46

Unit Box Width

0.4

Units per Shipping Box

1

Unit Calculated Volume

0.04048 cubm

Unit Calculated Weight

2.05 kg

Summary

DJI Matrice 3D. Number of rotors: 4 rotors. Megapixel (approx.): 48 MP. Maximum speed: 21 m/s, Maximum operating distance: 10000 m. Moving control functions: Backward, Downward, Forward, Upward. Battery technology: Lithium-Ion (Li-Ion), Battery capacity:

Battery (Battery technology)

Lithium-Ion (Li-Ion)

Weight & dimensions (Width)

398 mm

Weight & dimensions (Depth)

335 mm

Weight & dimensions (Height)

153 mm

Weight & dimensions (Weight)

1410 g

Battery (Battery operated)

Yes

Battery (Battery capacity)

7811 mAh

Operational conditions (Operating temperature (T-T))

-10 - 40 C

Design (Product colour)

Grey

Features (GPS (satellite))

Yes

Features (Maximum flight time)

50 min

Features (Maximum speed)

21 m/s

Camera (Camera shutter speed)

8 - 1/8000 s

Camera (Megapixel (approx.))

48 MP

Camera (Optical sensor size)

1/1.32 "

Design (Foldable)

Yes

Design (Suitable for outdoor use)

Yes

Design (Type)

Quadcopter

Features (GLONASS)

Yes

Features (Hovering time (max))

40 min

Features (Maximum ascent speed)

8 m/s

Features (Maximum descent speed)

6 m/s

Features (Maximum flight altitude)

4000 m

Features (Maximum operating distance)

10000 m

Features (Maximum wind resistance)

12 m/s

Features (Maximum yaw angular velocity)

250 /sec

Features (Number of rotors)

4 rotors

Features (Obstacle sensing system)

Yes

Camera (Bitrate at maximum video resolution)

130 Mbit/s

Camera (Digital zoom)

8 x

Camera (Field of view (FOV) angle)

82

Camera (Image formats supported)

DNG/JPEG/RAW

Camera (Maximum aperture number)

1.7

Camera (Maximum image resolution)

8064 x 6048 pixels

Camera (Normal focusing range)

1 - 8 m

Camera (Second camera bitrate at maximum video resolution)

130 Mbit/s

Camera (Second camera camera shutter speed)

8 - 1/8000 s

Camera (Second camera field of view (FOV) angle)

15

Camera (Second camera maximum image resolution)

4000 x 3000 pixels

Camera (Second camera megapixel (approx.))

12 MP

Camera (Second camera sensor type)

CMOS

Camera (Sensor type)

CMOS

Camera (Video formats supported)

AVC/H.264/H.265/HEVC/MPEG4

Camera (Video recording ISO sensitivity (normal))

100 - 25600

Camera (Video resolutions)

1920 x 1080/3840 x 2160 pixels

Memory (Compatible memory cards)

MicroSD (TransFlash)

Memory (Memory card slot(s))

Yes

Management features (Moving control functions)

backward/Downward/forward/Upward

Transmitter (USB ports quantity)

1

Battery (Battery voltage)

14.76 V

Power (AC adapter frequency)

50/60 Hz

Power (AC adapter input voltage)

100/240 V

Power (AC adapter output current)

2.5 A

Power (AC adapter power)

100 W

Weight & dimensions (Takeoff weight (max))

1610 g

Weight & dimensions (Wheelbase diagonal)

463.2 mm

Features (Horizontal hover accuracy)

0.1 m

Power (Output power)

100 W

Specific References

EAN13

6941565974747

MPN

1418832
