Mainboard|GIGABYTE|AMD A520|SAM4|Micro-ATX|Memory DDR4|Memory slots 2|2xPCI-Express 3.0 1x|1xPCI-Express 3.0 16x|1xM.2|1x15pin D

Data sheet

Vendor Homepage

https://www.gigabyte.com/Motherboard/A520M-S2H-rev-10 kf

Garantija

36

Model

A520M S2H 1.3

Category Code

MBA

Unit Box Height

0.235

Unit Box Length

0.265

Unit Box Width

0.05

Units per Shipping Box

10

Unit Calculated Volume

0.00426 cubm

Unit Calculated Weight

0.794 kg

Summary

GIGABYTE A520M S2H Motherboard - Supports AMD Ryzen 5000 Series AM4 CPUs, 4+3 Phases Pure Digital VRM, up to 5100MHz DDR4 (OC), PCIe 3.0 x4 M.2, GbE LAN, USB 3.2 Gen 1. Processor manufacturer: AMD, Processor socket: Socket AM4, Compatible processor series

Battery (Battery technology)

Lithium-Manganese Dioxide (LiMnO2)

Weight & dimensions (Width)

244 mm

Weight & dimensions (Depth)

205 mm

Weight & dimensions (Height)

35 mm

Packaging data (Package width)

265 mm

Packaging data (Package depth)

235 mm

Packaging data (Package height)

52 mm

Packaging data (Package weight)

740 g

Logistics data (Harmonized System (HS) code)

84733020

Battery (Battery type)

CR2032

Technical details (Warranty period)

3 year(s)

Network (Ethernet LAN)

Yes

Network (Wi-Fi)

No

Features (Product colour)

Black

Logistics data (Products per shipping (inner) case)

1 pc(s)

Packaging content (Batteries included)

Yes

Logistics data (Country of origin)

China

Processor (Processor manufacturer)

AMD

Features (Component for)

PC

Memory (Maximum internal memory)

64 GB

Memory (Memory channels)

Dual-channel

Graphics (On-board graphics card)

No

Battery (Battery weight)

3 g

Processor (Compatible processor series)

AMD Ryzen 3000 Series

Processor (Processor socket)

Socket AM4

Processor (Supported processor sockets)

Socket AM4

Memory (Memory slots type)

DIMM

Memory (Number of memory slots)

2

Memory (Supported memory clock speeds)

2133/2400/2667/2933/3200/3333/3600/4000/4400/4600/4866/5000 MHz

Memory (Supported memory types)

DDR4-SDRAM

Storage controllers (Supported storage drive interfaces)

M.2,PCI Express 3.0,SATA

Internal I/O (ATX Power connector (24-pin))

Yes

Internal I/O (CPU fan connector)

Yes

Internal I/O (Number of chassis fan connectors)

2

Internal I/O (Number of SATA III connectors)

4

Internal I/O (RGB LED pin header)

Yes

Internal I/O (USB 2.0 connectors)

2

Internal I/O (USB 3.2 Gen 1 (3.1 Gen 1) connectors)

1

Rear panel I/O ports (Ethernet LAN (RJ-45) ports)

1

Rear panel I/O ports (HDMI ports quantity)

1

Rear panel I/O ports (PS/2 ports quantity)

1

Rear panel I/O ports (USB 2.0 ports quantity)

2

Network (Ethernet interface type)

Gigabit Ethernet

Features (Audio output channels)

7.1 channels

Features (Motherboard chipset)

AMD A520

Features (Motherboard chipset family)

AMD

Features (Motherboard form factor)

micro ATX

Expansion slots (Number of M.2 (M) slots)

1

BIOS (BIOS memory size)

128 Mbit

BIOS (BIOS type)

UEFI AMI

BIOS (Clear CMOS button)

Yes

Storage controllers (RAID levels)

0/1/10

Storage controllers (RAID support)

Yes

Rear panel I/O ports (USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity)

4

Processor (Maximum internal memory supported by processor)

64 GB

BIOS (ACPI version)

5.0

BIOS (Clear CMOS jumper)

Yes

BIOS (Desktop Management Interface (DMI) version)

2.7

BIOS (System Management BIOS (SMBIOS) version)

2.7

Battery (Lithium weight per battery)

0.07 g

Battery (Number of battery cells)

1

Memory (ECC сompatibility)

ECC & Non-ECC

Graphics (HDCP)

Yes

Expansion slots (PCI Express x16 (Gen 3.x) slots)

1

Rear panel I/O ports (VGA (D-Sub) ports quantity)

1

Expansion slots (PCI Express x1 (Gen 3.x) slots)

2

Processor (Maximum number of SMP processors)

1

Rear panel I/O ports (DVI-D ports quantity)

1

Internal I/O (Power fan connector)

Yes

Specific References

EAN13

4719331809720

MPN

1426850
