Mainboard|GIGABYTE|AMD A620|Socket AM5|micro ATX|RAM DDR5-SDRAM|4xSlots|1xPCI Express x1 slots|1xPCI Express x16 slots|1xNumber

Reference A620M DS3H 2.0

Brand GIGABYTE

€91.11

VAT included

Quantity

Laos

In stock: 30 Items

Description
Product Details

Description

Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge

AMD Socket AM5：Supports AMD Ryzen 7000/ Ryzen 8000/ Ryzen 9000 Series Processors
Unparalleled Performance：5+2+2 Phases Digital VRM Solution
Dual Channel DDR5：4*SMD DIMMs with AMD EXPO & Intel XMP Memory Module Support
SuperSpeed Storage：PCIe 4.0 x4 M.2 Connector
EZ-Latch：PCIe x16 Slot with Quick Release Design
Fast Networks：GbE LAN
Extended Connectivity：DP, HDMI, D-Sub
Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card

Product Details

Brand GIGABYTE

Reference A620M DS3H 2.0

In stock 30 Items

Data sheet

Vendor Homepage: https://www.gigabyte.com
Garantija: 36
Category Code: MBA
Unit Box Height: 0.265
Unit Box Length: 0.27
Unit Box Width: 0.055
Units per Shipping Box: 10
Unit Calculated Volume: 0.00471 cubm
Unit Calculated Weight: 1.02 kg
Summary: GIGABYTE A620M DS3H Motherboard - Supports AMD Ryzen 8000 CPUs, 5+2+2 Phases Digital VRM, up to 7600MHz DDR5 (OC), 1xPCIe 4.0 M.2, GbE LAN, USB 3.2 Gen 1. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen 70
Battery (Battery technology): Lithium-Manganese Dioxide (LiMnO2)
Weight & dimensions (Width): 244 mm
Weight & dimensions (Depth): 244 mm
Weight & dimensions (Height): 35 mm
Packaging data (Package width): 265 mm
Packaging data (Package depth): 265 mm
Packaging data (Package height): 54 mm
Packaging data (Package weight): 1067 g
Packaging content (Cables included): SATA
Battery (Battery type): CR2032
Technical details (Warranty period): 3 year(s)
Network (Ethernet LAN): Yes
Network (Wi-Fi): No
Features (Product colour): Brown
Logistics data (Products per shipping (inner) case): 1 pc(s)
Packaging content (Batteries included): Yes
Logistics data (Country of origin): China
Processor (Processor manufacturer): AMD
Features (Component for): PC
Packaging content (Bundled software): Norton Internet Security (OEM version) LAN bandwidth management software
Memory (Maximum internal memory): 192 GB
Memory (Memory channels): Dual-channel
Battery (Battery weight): 3 g
Processor (Compatible processor series): AMD Ryzen 7000 Series
Processor (Processor socket): Socket AM5
Processor (Supported processor sockets): Socket AM5
Memory (Memory slots type): DIMM
Memory (Number of memory slots): 4
Memory (Supported memory clock speed (max)): 7600 MHz
Memory (Supported memory clock speeds): 4800/5200/5600/6000/6200/6400/6800/7000/7200/7600 MHz
Memory (Supported memory types): DDR5-SDRAM
Memory (Unbuffered memory): Yes
Storage controllers (Number of HDDs supported): 1
Storage controllers (Number of storage drives supported): 4
Storage controllers (Supported storage drive interfaces): M.2,SATA III
Storage controllers (Supported storage drive types): HDD & SSD
Graphics (Parallel processing technology support): Not supported
Internal I/O (12V power connector): Yes
Internal I/O (ATX Power connector (24-pin)): Yes
Internal I/O (CPU fan connector): Yes
Internal I/O (EPS power connector (8-pin)): Yes
Internal I/O (Front panel audio connector): Yes
Internal I/O (Front panel connector): Yes
Internal I/O (Number of SATA III connectors): 4
Internal I/O (RGB LED pin header): Yes
Internal I/O (TPM connector): Yes
Internal I/O (USB 2.0 connectors): 1
Internal I/O (USB 3.2 Gen 1 (3.1 Gen 1) connectors): 1
Rear panel I/O ports (DisplayPorts quantity): 1
Rear panel I/O ports (Ethernet LAN (RJ-45) ports): 1
Rear panel I/O ports (HDMI ports quantity): 1
Rear panel I/O ports (Headphone outputs): 3
Rear panel I/O ports (Microphone in): Yes
Rear panel I/O ports (PS/2 ports quantity): 1
Rear panel I/O ports (USB 2.0 ports quantity): 4
Network (Ethernet interface type): Gigabit Ethernet
Features (Audio output channels): 7.1 channels
Features (Motherboard chipset): AMD A620
Features (Motherboard chipset family): AMD
Features (Motherboard form factor): micro ATX
Features (Windows operating systems supported): Windows 10 x64/Windows 11 x64
Expansion slots (Number of M.2 (M) slots): 1
BIOS (BIOS memory size): 256 Mbit
BIOS (BIOS type): UEFI AMI
Storage controllers (RAID levels): 0/1/10
Storage controllers (RAID support): Yes
Rear panel I/O ports (DisplayPort version): 1.4
Rear panel I/O ports (HDMI version): 2.1
Rear panel I/O ports (USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity): 1
Processor (Maximum internal memory supported by processor): 192 GB
Memory (Supported memory module capacities): 12GB/16GB/1GB/2GB/32GB/48GB/4GB/8GB
Graphics (DirectX version): 12.0
Internal I/O (Total number of SATA connectors): 4
Features (PC health monitoring): Fan/Temperature/Voltage/Water cooling
BIOS (ACPI version): 5.0
BIOS (Clear CMOS jumper): Yes
BIOS (Desktop Management Interface (DMI) version): 2.7
BIOS (System Management BIOS (SMBIOS) version): 2.7
Battery (Lithium weight per battery): 0.07 g
Battery (Number of battery cells): 1
Memory (ECC сompatibility): Non-ECC
Graphics (HDCP): Yes
Graphics (Maximum resolution): 4096 x 2160 pixels
Rear panel I/O ports (USB connector type): USB Type-A/USB Type-C
Expansion slots (PCI Express x1 slots): 1
Expansion slots (PCI Express x16 slots): 1
Rear panel I/O ports (VGA (D-Sub) ports quantity): 1
