1433075
GIGABYTE
AMD X870 | SAM5 | ATX | DDR5 | 8000/7800/7600/7200/7000/6800/6666/6600/6400/6200/6000/5600/5200/4800/4400 MHz | Memory slots 4 | Video Depending on CPU | Audio | LAN 2.5 Gigabit | RAID SATA 0, 1, 10; NVMe 0, 1, 5, 10 | TPM Header
€233.10
VAT included
Quantity
Laos
2 Items

Description

X870 EAGLE WIFI7

  • AMD Socket AM5：Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Processors
  • Digital twin 14+2+2 phases VRM solution
  • Dual Channel DDR5：4*DIMMs with AMD EXPO™Memory Module Support
  • WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation
  • EZ-Latch Plus：PCIe and M.2 slots with Quick Release & Screwless Design
  • EZ-Latch Click：M.2 heatsinks with screwless design
  • Friendly UI: Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW.
  • Ultra-Fast Storage：3*M.2 slots, including 1* PCIe 5.0 x4
  • Efficient Thermal：VRM Thermal Armor Advanced  & M.2 Thermal Guard
  • Fast Networking：2.5GbE LAN & Wi-Fi 7 with Ultra-high gain antenna
  • Extended Connectivity：Dual USB4 Type-C with DP-Alt, HDMI
Product Details
GIGABYTE
1433075
2 Items

Data sheet

Vendor Homepage
www.gigabyte.com/Motherboard/X870-EAGLE-WIFI7 kf
Form Factor
ATX
Socket
SAM5
Input/Output connectors (USB 2.0)
4
Interface (SATA)
Yes
Memory type
DDR5
Frequency speed
4400/4800/5200/5600/6000/6200/6400/6600/6666/6800/7000/7200/7600/7800/8000 MHz
Interface (USB 2.0)
Yes
Input/Output connectors (RJ45)
1
Input/Output connectors (HDMI)
1
Integrated LAN
2.5 Gigabit
Interface (Bluetooth)
Yes
Interface (WiFi)
Yes
Chipset
AMD X870
Integrated audio
Yes
Integrated video
Depending on CPU
Memory slots
4
RAID
SATA 0, 1, 10 NVMe 0, 1, 5, 10
TPM
Header
Expansion slots (PCI-Express 3.0 1x)
2
Expansion slots (M.2)
3
Input/Output connectors (Audio port)
3
Interface (USB-C)
Yes
Garantija
36
Input/Output connectors (USB 3.2)
4
Interface (USB 3.2)
Yes
Model
X870 EAGLE WIFI7 (1.1)
Category Code
MBA
Expansion slots (PCI-Express 5.0 16x)
1
Unit Box Height
0.08
Unit Box Length
0.34
Unit Box Width
0.27
Input/Output connectors (USB-C)
2
Units per Shipping Box
1
Unit Calculated Volume
0.007344 cubm
Product Net Weight
1.2 kg
Unit Calculated Weight
1.792 kg

Specific References

EAN13
4719331864996
MPN
X870 EAGLE WIFI7 1.1
