Channels 4 | Drives/bays 1 | Power supply requirements 12 VDC, 2 A | Power consumption 10 Watts | Dim. 260 mm × 232.7 mm × 47.6 mm | Temp. range –10 °C to +55 °C
VGA/HDMI up to 4K output, decoding up to 2-channel 16 MP @ 30 fps
1 SATA III port, up to 16 TB for a single HDD
No front panel control, no alarm I/O, 2 USB, Two-way Talk: 1/1
Desktop mounted chassis
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.
Channels 16 | CPU Industrial-grade processor | Power supply requirements 100–240 VAC, 50/60 Hz | Dim. 375.0 × 327.9 × 53.0 mm | Temp. range –10 °C to +55 °C
Channels 16 | Drives/bays 2 | CPU Industrial-grade processor | Power supply requirements 12 VDC, 4 A | Power consumption 10 Watts | Dim. 375.0 × 282.9 × 53.0 mm | Temp. range –10 °C to +55 °C | Colour Black
Channels 4 | CPU Industrial-grade | Integrated LAN 10/100 | Power supply requirements 53 VDC, 1.22 A | Dim. 260.0 × 232.5 × 47.6 mm | Temp. range –10 °C to +55 °C | Colour Black
Channels 4 | Drives/bays 1 | Power supply requirements 53 VDC, 1.226 A | Power consumption 36 Watts | Dim. 260 mm × 232.7 mm × 47.6 mm | Temp. range –10 °C to +55 °C
Channels 4 | Drives/bays 1 | CPU Industrial-grade processor | Integrated LAN 10/100 | Power supply requirements 12 VDC, 2 A | Power consumption 10 Watts | Dim. 260.0 × 232.5 × 47.6 mm | Temp. range –10 °C to +55 °C
Channels 4 | Drives/bays 1 | CPU Industrial-grade processor | Integrated LAN 10/100 | Power supply requirements 12 VDC, 1.5 A | Power consumption 10 Watts | Dim. 260.0 × 232.5 × 47.6 mm | Temp. range –10 °C to +55 °C
Channels 32 | Drives/bays 2 | CPU Industrial-grade | Power supply requirements 12 VDC, 4 A | Power consumption 10 Watts | Dim. 375.0 × 282.9 × 53.0 mm | Temp. range –10 °C to +55 °C
Channels 16 | Drives/bays 2 | Power supply requirements 12 VDC, 4 A | Power consumption 10 Watts | Dim. 375 mm × 284.3 mm × 53 mm | Temp. range –10 °C to +55 °C
Channels 8 | Integrated LAN Gigabit | Power supply requirements 53 VDC, 1.812 A | Power consumption 10 Watts | Dim. 270 × 206.2 × 47.5 mm | Temp. range –10 °C to +55 °C | Colour White
Channels 8 | Drives/bays 1 | CPU Industrial-grade processor | Power supply requirements 12 VDC, 2A | Power consumption 7.8 Watts | Dim. 260 × 232.7 × 47.6mm | Temp. range –10 °C to +55 °C | Colour Black
Channels 4 | Drives/bays 1 | Power supply requirements 12 VDC, 2 A | Power consumption 10 Watts | Dim. 204.6 mm × 206.4 mm × 45.6 mm | Temp. range –10 °C to +55 °C | Colour White
Channels 4 | Drives/bays 1 | Power supply requirements 12 VDC, 2 A | Power consumption 10 Watts | Dim. 260 mm × 232.7 mm × 47.6 mm | Temp. range –10 °C to +55 °C
