NET CAMERA 4MP IR EYEBALL/HDW5442TM-ASE-0280B-S3-B DAHUA

Name: NET CAMERA 4MP IR EYEBALL/HDW5442TM-ASE-0280B-S3-B DAHUA
Brand: DAHUA
SKU: HDW5442TM-ASE-0280B-S3-B
Price: 172.76 EUR
Availability: InStock

Tootekood HDW5442TM-ASE-0280B-S3-B

Kaubamärk DAHUA

383,90 €

172,76 € SÄÄST 211,14 €

KM-ga

Tarneaeg 1-5 tööpäeva.

Kogus

Laos

Tarneaeg 2-5 tööpäeva. : 30 Tooted

Kirjeldus
Üldine informatsioon

Kirjeldus

Pro AI series contains Face Detection, Perimeter Protection and People
Counting functions.Powered by deep-learning Artificial Intelligence algo-
rithms, significantly improved accuracy. Meanwhile, the series features
starlight and smart IR technology. This series fully protected from dust
and water, certified to IP67 standard.

Face Detection
Face Detection is a software application that automatically captures
faces from within a digital image or a video frame from a video source.
Dahua cameras use advanced deep learning algorithms and are trained
by a large number of face data sources, enabling the camera to locate
faces quickly and accurately from the video source and capture facial
images.

Perimeter Protection
Dahua’s Perimeter Protection functions significantly improved accu-
racy. Perimeter Protection reduces false alarms and decreases pixel
count requirements for object detection. Perimeter Protection features
custom tripwires based on object type for automation in limited access
areas such as pedestrian or vehicle-only zones. This combination of
advanced AI analytics and real-time alerts to a desktop or to a mobile
client reduces system requirements and resources resulting in greater
surveillance system efficiency.

People Counting
People Counting function uses advanced image processing technology
to capture depth information from within images. The camera pairs this
information with deep learning algorithms to analyze and detect human
bodies and track target objects in real time. The camera provides statis-
tics for separate individuals’ entrance and exit with up to 95% counting
accuracy.

Protection(IP67, wide voltage)
The camera allows for ±30% input voltage tolerance, suitable for the
most unstable conditions for outdoor applications. Its 6KV lightning rat-
ing provides effective protection for both the camera and its structure
against lightning. Subjected and certified to rigorous dust and immer-
sion tests (IP67) , the camera is the choice for installation in even the
most unforgiving environmen

· 1/1.8” 4Megapixel progressive scan CMOS
· H.265 & H.264 triple-stream encoding
· 25/30 fps@2688 × 1520, 50/60 fps@1080P (1920 × 1080)
· WDR (140 dB), Day/Night (ICR), 3D DNR, AWB, AGC, BLC
· Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS
· 2.8 mm fixed lens (3.6 mm, 6.0 mm optional)
· Built-in MIC
· Max. IR LEDs Length 50 m
· Micro SD memory, IP67

Üldine informatsioon

Kaubamärk DAHUA

Tootekood HDW5442TM-ASE-0280B-S3-B

Tarneaeg 2-5 tööpäeva. 30 Tooted

Lisainfo

Müüja koduleht: https://www.dahuasecurity.com/products/
Garantija: 36
Mudel: IPC-HDW5442TM-ASE-0280B-S3-B
Category Code: FNC
Unit Box Height: 0.14
Unit Box Length: 0.15
Unit Box Width: 0.145
Units per Shipping Box: 1
Unit Calculated Volume: 0.003045 cubm
Unit Calculated Weight: 0.725 kg
Summary: Dahua Technology Pro IPC-HDW5442TMP-ASE-0280B. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Dome. Minimum illumination: 0.002 lx, Angle of rota
Weight & dimensions (Height): 99.2 mm
Weight & dimensions (Weight): 550 g
Packaging data (Package weight): 710 g
Performance (Certification): CE-LVD: EN60950-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07CE-LVD: EN60950-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part
Operational conditions (Operating temperature (T-T)): -40 - 60 C
Operational conditions (Storage temperature (T-T)): -40 - 60 C
System requirements (Mobile operating systems supported): Android/iOS
Weight & dimensions (Diameter): 106 mm
Network (Ethernet LAN): Yes
Design (Product colour): White
Power (Power consumption (typical)): 7.2 W
Ports & interfaces (Ethernet LAN (RJ-45) ports): 1
Design (Housing material): Metal
Operational conditions (Operating relative humidity (H-H)): 0 - 95 %
Design (Form factor): Dome
Camera (Camera shutter speed): 1/3 -1/100000 s
Storage (Compatible memory cards): MicroSD (TransFlash)
Storage (Maximum memory card size): 256 GB
Power (Power source type): DC,PoE
Performance (Wide Dynamic Range (WDR)): Yes
Audio (Built-in microphone): Yes
Network (Ethernet interface type): Fast Ethernet
Design (International Protection (IP) code): IP67
Design (Mounting type): Ceiling
Performance (Connectivity technology): Wired
Performance (Day/night mode): Yes
Performance (Placement supported): Indoor & outdoor
Performance (Type): IP security camera
Camera (Lens viewing angle, horizontal): 113
Camera (Lens viewing angle, vertical): 60
Image sensor (Optical sensor size): 1/1.8 "
Lens system (Number of lenses): 1
Night vision (LED type): IR
Night vision (Night vision): Yes
Night vision (Night vision distance): 50 m
Video (Frame rate): 30 fps
Video (Maximum resolution): 2688 x 1520 pixels
Video (Noise reduction): Yes
Video (Noise reduction technology): 3D noise reduction
Video (Privacy masking): Yes
Video (Total megapixels): 4 MP
Security (Intelligent Video Surveillance (IVS) system features): Face detection/Heat map/Intrusion/People counting/Tripwire
Power (DC output voltage): 12
Packaging content (Number of cameras): 1
Image sensor (Number of effective pixels (H x V)): 2688 x 1520 pixels
Image sensor (Sensor type): CMOS
Lens system (Focal length range): 2.8 mm
Camera (Minimum illumination): 0.002 lx
Video (Back Light Compensation (BLC)): Yes
Video (Highlight Compensation (HLC)): Yes
Camera (Adjustment shutter speed): Auto/Manual
Image sensor (Progressive scan): Yes
Lens system (Maximum aperture number): 1.6
Video (Flip & mirror): Yes
Video (Gain control type): Auto/Manual
Camera (Camera shutter type): Electronic
Video (Region of Interest (ROI) encoding): Yes
Security (Video motion detection): Yes
Video (Video compression formats): H.264/H.264+/H.265/H.265+
Image sensor (Number of sensors): 1
Camera (Angle of rotation): 360
Camera (Pan range): 0 - 360
Camera (Tilt angle range): 0 - 78
Camera (White balance): Auto/Lamp/Manual/Natural/Outdoor
Video (Bit rate control): Constant Bit Rate (CBR),Variable Bit Rate (VBR)
Video (Supported graphics resolutions): 1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2304 x 1296/2560 x 1440/2688 x 1520/352 x 240/352 x 288/640 x 480 (VGA)/720 x 480/720 x 576
Video (Video streaming): Yes
Network (Quality of Service (QoS) support): Yes
Network (Streaming method): Multicast/Unicast
Network (Supported network protocols): IPv4 IPv6 HTTP HTTPS TCP UDP ARP RTP RTSP RTCP RTMP SMTP FTP SFTP DHCP DNS DDNS QoS UPnP NTP Multicast ICMP IGMP NFS PPPoE 802.1x SNMP
Storage (Internal memory): 512 MB
Storage (ROM capacity): 128 MB
Management features (Management software): Smart PSS, DSS, DMSS
Management features (Web browser): Yes
Video (Smart IR): Yes
Night vision (Number of illumination LEDs): 2
Network (Number of users): 20 user(s)
Security (Mirror): Yes
Performance (Dynamic range): 140 dB
Lens system (Detect distance): 58 m
Lens system (Identify distance): 6 m
Lens system (Observe distance): 23 m
Lens system (Recognize distance): 12 m
Video (Bit rate): 32 Kbps-8192 Kbps
Audio (Voice codecs): AAC/G.711a/G.711Mu/G.723/G.726
Network (Networking standards): IEEE 802.3af
Video (Analog signal format system): PAL
