•32 IP channel max, up to 32MP resolution
• up to 384 Mbps incoming bandwidth
•VGA/HDMI up to 3840 × 2160 output
•2 SATA interface up to 16 TB each
•No front panel controls, 4/2 alarm I/O, RS232, RS485, 2 USB
•1U 19” chassis, mouse included
•Free IP monitoring software available
•Smart capabilities support: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
• Support AcuPick with Max. 16-Channel
Channels 16 | Drives/bays 2 | Power supply requirements 12 VDC, 4 A | Power consumption 10 Watts | Dim. 375 mm × 284.3 mm × 53 mm | Temp. range –10 °C to +55 °C
Channels 8 | Integrated LAN Gigabit | Power supply requirements 53 VDC, 1.812 A | Power consumption 10 Watts | Dim. 270 × 206.2 × 47.5 mm | Temp. range –10 °C to +55 °C | Colour White
Channels 4 | Included Accessories Power Adapter,HDD Screws,Mouse,Quick Installation Guide | Power supply requirements 53.5V DC/1.31A | Power consumption 4.82 Watts | Dim. 200.3 × 200.3 × 43 mm | Temp. range -10–55 °C | Colour White
Channels 4 | CPU Industrial-grade processor | Integrated LAN GbE Marvell 8053/Y | Power supply requirements 53 VDC, 1.22 A | Dim. 260.0 × 232.5 × 47.6 mm | Temp. range –10 °C to +55 °C | Colour Black
Channels 4 | Drives/bays 1 | Power supply requirements 12 VDC, 2 A | Power consumption 10 Watts | Dim. 260 mm × 232.7 mm × 47.6 mm | Temp. range –10 °C to +55 °C
Channels 32 | Drives/bays 2 | CPU Industrial-grade | Power supply requirements 12 VDC, 4 A | Power consumption 10 Watts | Dim. 375.0 × 282.9 × 53.0 mm | Temp. range –10 °C to +55 °C
Channels 32 | Drives/bays 2 | CPU Industrial-grade processor | Power supply requirements 12 VDC, 4 A | Power consumption 10 Watts | Dim. 375 × 284.3 × 53 mm | Temp. range –10 °C to +55 °C
Channels 4 | Drives/bays 1 | Power supply requirements 53 VDC, 1.226 A | Power consumption 36 Watts | Dim. 204.6 mm × 206.4 mm × 45.6 mm | Temp. range –10 °C to +55 °C | Colour White
Channels 8 | CPU Industrial-grade | Integrated LAN Gigabit | Power supply requirements 100–240 VAC, 50/60 Hz | Dim. 375.0 × 327.9 × 53.0 mm | Temp. range –10 °C to +55 °C | Colour Black
Channels 4 | CPU Industrial-grade | Integrated LAN 10/100 | Power supply requirements 12 VDC, 1.5 A | Power consumption 10 Watts | Dim. 204.6 × 206.4 × 45.6 mm | Temp. range –10 °C to +55 °C | Colour White
Channels 4 | Drives/bays 1 | CPU Industrial-grade processor | Integrated LAN 10/100 | Power supply requirements 12 VDC, 1.5 A | Power consumption 10 Watts | Dim. 260.0 × 232.5 × 47.6 mm | Temp. range –10 °C to +55 °C
Drives/bays 1 | CPU Quad-core ARM® Cortex®-A55 at 1.7 GHz | Memory (RAM) 4GB | Power supply requirements AC/DC, Internal, 60W | Dim. 220 x 220 x 47 mm | Colour White
Channels 16 | Drives/bays 2 | Integrated LAN Gigabit | Power supply requirements 12 VDC, 4 A | Power consumption 10 Watts | Dim. 375.0 × 284.4 x 56.0mm | Temp. range –10 °C to +55 °C
