16 IP channel max, up to 32MP resolution
Max 384 Mbps incoming Bandwidth
VGA/HDMI up to 4K output, 16-channel 4 MP@30 fps
2 SATA interface up to 16TB, Gigabit LAN
PoE Port: 16 ports, 10/100 Mbps, IEEE 802.3 af/at, 1-8 ports support ePoE; 130W max total
No front panel controls, 4/2 alarm I/O, 1/1 Audio I/O, RS232, RS485, 2 USB
1U 19” chassis, mouse included
AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, and people counting.
Other brands IP cameras supported. ONVIF 21.12(Profile T; Profile S; Profile G); CGI; SDK
Free IP monitoring software available
Channels 16 | Drives/bays 1 | CPU Industrial-grade processor | Power supply requirements 12 VDC, 2 A | Power consumption 10 Watts | Dim. 260 × 232.7 × 47.6mm | Temp. range –10 °C to +55 °C | Colour Black
Channels 8 | CPU Industrial-grade | Integrated LAN Gigabit | Power supply requirements 12 VDC, 2 A | Power consumption 10 Watts | Dim. 260.0 × 232.5 × 47.6 mm | Temp. range –10 °C to +55 °C | Colour Black
Channels 8 | Drives/bays 2 | CPU Dual-core embedded processor | Integrated LAN 10/100 | Power supply requirements DC 12V/5A | Power consumption 20 Watts | Dim. 375.0 × 329.4 x 53.0 mm | Temp. range –10 °C to +55 °C | Colour Black
Channels 4 | CPU Industrial-grade | Integrated LAN 10/100 | Power supply requirements 12 VDC, 1.5 A | Power consumption 10 Watts | Dim. 204.6 × 206.4 × 45.6 mm | Temp. range –10 °C to +55 °C | Colour White
Channels 8 | CPU Industrial-grade | Integrated LAN Gigabit | Power supply requirements 100–240 VAC, 50/60 Hz | Dim. 375.0 × 327.9 × 53.0 mm | Temp. range –10 °C to +55 °C | Colour Black
Channels 4 | Drives/bays 1 | Power supply requirements 53 VDC, 1.226 A | Power consumption 36 Watts | Dim. 260 mm × 232.7 mm × 47.6 mm | Temp. range –10 °C to +55 °C
Channels 4 | Power supply requirements DC48 V/53 V, 1.5 A/1.36 A | Power consumption 10 Watts | Dim. 375 mm × 282.4 mm × 53 mm | Temp. range –10 °C to +55 °C | Colour Black
Channels 8 | CPU Industrial-grade processor | Power supply requirements 12 VDC, 2A | Power consumption 7.8 Watts | Dim. 260 × 232.7 × 47.6mm | Temp. range –10 °C to +55 °C | Colour Black
Channels 32 | Drives/bays 2 | CPU Industrial-grade processor | Power supply requirements 12 VDC, 4 A | Power consumption 10 Watts | Dim. 375 × 284.3 × 53 mm | Temp. range –10 °C to +55 °C
Channels 16 | CPU Industrial-grade processor | Power supply requirements 100–240 VAC, 50/60 Hz | Dim. 375.0 × 327.9 × 53.0 mm | Temp. range –10 °C to +55 °C
Channels 8 | Integrated LAN Gigabit | Power supply requirements 53 VDC, 1.812 A | Power consumption 10 Watts | Dim. 270 × 206.2 × 47.5 mm | Temp. range –10 °C to +55 °C | Colour White
