Power Supply|CHIEFTEC|ATX 750W|750 Watts|Efficiency 80 PLUS GOLD|PFC Active|PPG-750-C
  • Power Supply|CHIEFTEC|ATX 750W|750 Watts|Efficiency 80 PLUS GOLD|PFC Active|PPG-750-C

Power Supply|CHIEFTEC|ATX 750W|750 Watts|Efficiency 80 PLUS GOLD|PFC Active|PPG-750-C

PPG-750-C
CHIEFTEC
750 W | 100 - 240 V | 80 PLUS certification 80 PLUS Gold | PC | ATX | Fan diameter 135 mm | Weight 1.96 kg | ATX 750W
74,38 €
KM-ga
Tarneaeg kuni 30 päeva
Kogus
Tellimisel

Kirjeldus
750 W | 100 - 240 V | 80 PLUS certification 80 PLUS Gold | PC | ATX | Fan diameter 135 mm | Weight 1.96 kg | ATX 750W
Üldine informatsioon
CHIEFTEC
PPG-750-C

Lisainfo

Müüja koduleht
www.chieftec.eu/products-detail/626/VEGA_M
Mudeli nimi
ATX 750W
Garantija
24
Category Code
PSU
Unit Box Height
0.21
Unit Box Length
0.28
Unit Box Width
0.105
Units per Shipping Box
5
Unit Calculated Volume
0.00759 cubm
Unit Calculated Weight
2.5 kg
Summary
Chieftec Vega PPG-750-C. Total power: 750 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, SATA power cable length: 400 mm. Purpose: PC, Power supply unit (PS
Weight & dimensions (Width)
150 mm
Weight & dimensions (Depth)
150 mm
Weight & dimensions (Height)
85 mm
Weight & dimensions (Weight)
1960 g
Packaging data (Package weight)
2430 g
Design (Product colour)
Black
Power (AC input frequency)
50/60 Hz
Power (AC input voltage)
100 - 240 V
Design (Cooling type)
Active
Certificates (Certification)
80PLUS Gold
Design (Fan diameter)
135 mm
Design (Illumination)
No
Power (Combined power (+3.3V))
100 W
Power (Combined power (+5V))
100 W
Power (Max output current (+3.3V))
20 A
Power (Max output current (+5V))
20 A
Power (Max output current (-12V))
0.3 A
Power (Total power)
750 W
Ports & interfaces (ATX Power connector (24-pin))
Yes
Ports & interfaces (Cabling type)
Fully-Modular
Ports & interfaces (Motherboard power cable length)
600 mm
Ports & interfaces (Motherboard power connector)
20+4 pin ATX
Ports & interfaces (Number of SATA power connectors)
6
Ports & interfaces (Peripheral (Molex) power cable length)
400 mm
Ports & interfaces (Peripheral (Molex) power connectors (4-pin))
3
Ports & interfaces (SATA power cable length)
400 mm
Performance (80 PLUS certification)
80 PLUS Gold
Performance (Power supply unit (PSU) form factor)
ATX
Performance (Purpose)
PC
Power (Power Factor Correction (PFC) type)
Active
Performance (ATX version)
3.1
Ports & interfaces (CPU power connector (4+4 pin))
Yes
Ports & interfaces (PCI Express power connectors (6+2 pin))
4
Performance (Bearing technology)
FDB
Ports & interfaces (CPU power cable length)
650 mm
Ports & interfaces (EPS power connector (8-pin))
Yes
Ports & interfaces (PCI Express power connectors (12+4 pin))
1
Ports & interfaces (PCI Express power connectors (12+4 pin) cable length)
600 mm
Ports & interfaces (ATX power connector (20+4 pin))
Yes
Ports & interfaces (EPS power connector (4+4 pin))
Yes
Power (Max output current (+12V1))
62.5 A
