The Supremo FM5 Gold 650W is an efficient power supply with a 120 mm Fluctus fan that ensures your PC runs stably without unexpected resets interruptions. This bad boy is equipped with Japanese electrolytic and aluminum-polymer capacitors so you can squeeze the last juices out of it without a hitch. No wonder it is 80 PLUS® Gold certified ;)
Supremo FM5 Gold 650W
When you've spent half your life by the computer, you know that stable component operation = trouble-free boss battles (including those in the office). And that's why we created the Supremo FM5 Gold 650W.
It's an efficient and relatively small (14 cm long) power supply with DC-DC topology dedicated to special tasks demanding components. We're serious – we've packed in everything we think you need to fine-tune the voltage and deliver continuous 650W of power without unexpected resets or a blue screen. We also fit a 12 cm 120 mm Fluctus fan, which will stay cool (literally!) and take care of the right temperature inside the PSU. No wonder our Supremo got the 80 PLUS® Gold certification :)
ENDORFY Supremo FM5. Total power: 650 W, AC input voltage: 115 - 230 V, AC input frequency: 50/60 Hz. Motherboard power connector: 18+10 pin ATX, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80
Weight & dimensions (Width)
140 mm
Weight & dimensions (Depth)
150 mm
Weight & dimensions (Height)
87 mm
Packaging content (Cables included)
AC
Design (Product colour)
Black
Power (AC input frequency)
50/60 Hz
Power (AC input voltage)
115 - 230 V
Design (Number of fans)
1 fan(s)
Design (Fan diameter)
120 mm
Design (On/off switch)
Yes
Power (Combined power (+12V))
648 W
Power (Combined power (+3.3V))
100 W
Power (Combined power (+5V))
100 W
Power (Combined power (+5Vsb))
15 W
Power (Combined power (-12V))
3.6 W
Power (Max output current (+12V))
54 A
Power (Max output current (+3.3V))
20 A
Power (Max output current (+5V))
20 A
Power (Max output current (+5Vsb))
3 A
Power (Max output current (-12V))
0.3 A
Power (Power protection features)
Over current/Over power/Over voltage/Short circuit/Under voltage
Power (Total power)
650 W
Ports & interfaces (Cabling type)
Fully-Modular
Ports & interfaces (Motherboard power connector)
18+10 pin ATX
Ports & interfaces (Number of SATA power connectors)
3
Ports & interfaces (PCI Express power connectors (8-pin))
