NVR NVR5208-XI 8 CHANNELS WizMind DAHUA
1 663,17 €
Sisältää alv:n
- NVR equipped with advanced functions of intelligent image analysis
Security policy (edit with Customer reassurance module)
Delivery policy (edit with Customer reassurance module)
Return policy (edit with Customer reassurance module)
| Standard: | IP |
| Supported resolutions: | max. 32 Mpx |
| Video outputs: | 1 pcs HDMI 4K 1 pcs VGA |
| Audio support: | 8 Channels - Audio from cameras, Bi-directional audio streaming support Audio detection |
| Audio inputs: | 1 pcs CINCH |
| Audio outputs: | 1 pcs CINCH |
| Image compression method: | Smart H.265+ / H.265 / Smart H.264+ / H.264 / MJPEG |
| Bitrate: | max. 384 Mbps |
| Supported hard drives: | 2 x 20 TB SATA |
| Recording modes: | Manual, Sensor, Motion detection, Schedule |
| External storage devices backup: | Backup to USB drive (pendrive, external drive) |
| Searching and playback the records: | Records searching: by time and events type. Records playback: forward, backward, fast, slow Advanced searching (to the one second accuracy) Smart Playback function Records playback from max. 8 channels in the same time @ 8 Mpx (without AI) Records playback from max. 8 channels in the same time @ 5 Mpx (AI) |
| Network interface: | 1 x RJ-45 10/100/1000 Base-TX |
| Network functions: | Full support via network, Remote records copying, Web-Server built-in |
| ONVIF: | 22.12 |
| Default IP address: | 192.168.1.108 |
| Default admin user / password: | admin / - The administrator password should be set at the first start |
| Mobile phones support: | Port no.: 37777 or access by a cloud (P2P) Android: DMSS free application iOS (iPhone): DMSS free application See how to configure the P2P function in Dahua recorders and how to enable the mobile application |
| Web browser access ports: | 80, 37777 |
| PC client access ports: | 37777 |
| Mobile client access ports: | 37777 |
| RTSP URL: | rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main stream rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Sub stream |
| USB: | 1 pcs USB 2.0 1 pcs USB 3.0 |
| Serial ports: | RS-485, RS-232 |
| Alarm inputs / outputs: | 4 / 2 |
| PTZ control: | IP Speed Dome Cameras RS-485 - PELCO-D/P and others |
| Intelligent Image Analysis: |  |
| Motion Detection: | |
| Main features: | Intelligent Image Analysis : IVS analysis - 10 rules, scene changing, face detection, SMD PLUS - searching for an object classified as: human, motor vehicle, non-motor vehicle Filtering of false alarms based on the recognition of persons and vehicles Face recognition - supports 6 types of facial attributes extraction Face recognition and analysis in real time (up to 16 photos per second) Support for up to 20 face databases, including 200 000 face images metadata handling - automatic photo taking and collection of information enabling the subsequent identification of people and vehicles that triggered the alarm (clothing, silhouette, face, features of motor and non-mechanical vehicles) AcuPick support - technology that uses artificial intelligence on both front-end and back-end to search through massive amounts of video data to quickly locate targets with high precision EPTZ - advanced target detection and tracking algorithms that trigger alarms - can simultaneously zoom and track many people and/or vehicles Functions implemented in cooperation between the recorder and cameras that support these functions : ANPR Authorized and unauthorized license plate lists: up to 20 000 records counting people / vehicles crowd gathering estimation heat map |
| Mouse support: | |
| IR remote controller in the set: |  |
| Switch POE: | |
| Power supply: | 12 V DC / 4 A |
| Power consumption: | max. 10 W (without HDD) |
| Operation temp: | -10 °C ... 55 °C |
| Weight: | 1.56 kg |
| Dimensions: | 375 x 283 x 56 mm |
| Supported languages: | Polish, English |
| Manufacturer / Brand: | DAHUA |
| Guarantee: | 5 years |
