| Standard: |
IP |
| Supported resolutions: |
max. 12 Mpx - 4000 x 3000 px |
| Video outputs: |
1 pcs HDMI 4K 1 pcs VGA |
| Audio support: |
9 Channels - Audio from cameras, Bi-directional audio streaming support |
| Audio inputs: |
1 pcs CINCH |
| Audio outputs: |
1 pcs CINCH |
| Image compression method: |
H.265+ / H.265 / H.264+ / H.264 |
| Bitrate: |
80 Mbps (incoming) |
| Supported hard drives: |
1 x 10 TB SATA |
| Recording modes: |
Manual, Motion Detection, Schedule |
| External storage devices backup: |
Backup to USB drive (pendrive, external drive) |
| Searching and playback the records: |
Records searching: by time and events type. Records playback: forward, backward, fast, slow
Channels played simultaneously :
1 @ 12 Mpx, 30 fps
1 @ 8 Mpx, 30 fps
2 @ 5 Mpx, 30 fps
4 @ 4 Mpx, 30 fps
7 @ 1080p, 30 fps
9 @ 720p, 30 fps |
| Network interface: |
1 x RJ-45 10/100 Base-TX |
| Network functions: |
Network Client Software and IE browser: live view, playback and backup of the records, configuration of the recorder parameters |
| ONVIF: |
 |
| Default IP address: |
DHCP / 192.168.1.88 |
| Default admin user / password: |
admin / 12345 |
| Mobile phones support: |
Access by a cloud (P2P) Android: BitVision free application, Android: iVMS320 free application Android: BitVision free application, iOS: iVMS320 free application |
| Web browser access ports: |
80, 5000, 554 |
| PC client access ports: |
80, 5000, 554 |
| USB: |
2 pcs USB 2.0 |
| Serial ports: |
 |
| Alarm inputs / outputs: |
|
| PTZ control: |
IP Speed Dome Cameras |
| Motion Detection: |
Split the screen into zones : 22 x 18 motion zones |
| Intelligent Image Analysis: |
Support for intelligent image analysis, available in cameras from the APTI-AI series |
| Main features: |
D-ZOOM - Digital Zoom |
| Mouse support: |
|
| IR remote controller in the set: |
|
| Switch POE: |
|
| Power supply: |
12 V DC / 2 A (power adapter included) |
| Power consumption: |
max. 10 W (without HDD) |
| Operation temp: |
-10 °C ... 50 °C |
| Weight: |
0.86 kg |
| Dimensions: |
260 x 230 x 43 mm |
| Supported languages: |
Polish, English, Czech, French, Greek, Spanish, Dutch, German, Portuguese, Russian, Ukrainian, Hungarian, Italian |
| Manufacturer / Brand: |
APTI |
| Guarantee: |
2 years |
