| Standard: |
TCP/IP |
| Supported resolutions: |
max. 6 Mpx - 3072 x 2048 px |
| Video outputs: |
1 pcs HDMI
1 pcs VGA |
| Audio support: |
8 Channels - Audio from cameras |
| Audio inputs: |
1 pcs CINCH |
| Audio outputs: |
1 pcs CINCH |
| Image compression method: |
Smart H.265 / H.265 / Smart H.264 / H.264 / MJPEG |
| Bitrate: |
max. 40 Mbps
max. 16 Mbps Wi-Fi |
| Supported hard drives: |
1 x 16 TB SATA |
| Recording modes: |
Manual, Motion Detection, Schedule |
| External storage devices backup: |
Backup to USB drive (pendrive, external drive) |
| Searching and playback the records: |
Records searching: by time and events type. Records playback: forward, backward, fast, slow
Advanced searching (to the one second accuracy)
1, 4 or 8 channels synchronous playback, Smart Playback function |
| Network interface: |
1 x RJ-45 10/100 Base-TX 2.4 GHz Wi-Fi - IEEE 802.11 b/g/n |
| Network functions: |
Built-in Wi-Fi module - Dahua cameras support : Smart, auto-paring, Remote configuration, Remote management Full support via network, Remote records copying, Web Server built-in |
| Network protocols: |
HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, NTP, DHCP, DNS, Alarm Server, P2P |
| ONVIF: |
 |
| Default IP address: |
192.168.1.108 |
| Default admin user / password: |
admin / -
The administrator password should be set at the first start |
| Web browser access ports: |
80, 37777 |
| PC client access ports: |
37777 |
| Mobile client access ports: |
37777 |
| Mobile phones support: |
Port no.: 37777 or access by a cloud (P2P) Android: Free application DMSS iOS (iPhone): Free application DMSS
See how to configure the P2P function in Dahua recorders and how to enable the mobile application |
| RTSP URL: |
rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main stream
rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Sub stream |
| USB: |
2 pcs USB 2.0 |
| Serial ports: |
 |
| Alarm inputs / outputs: |
|
| PTZ control: |
IP Speed Dome Cameras |
| Motion Detection: |
|
| Intelligent Image Analysis: |
|
| Main features: |
Privacy zones VIDEO signal loss alarm |
| Mouse support: |
|
| IR remote controller in the set: |
|
| Power supply: |
12 V DC / 1.5 A (power adapter included) |
| Power consumption: |
≤ 10 W (without HDD) |
| Operation temp: |
-10 °C ... 45 °C |
| Weight: |
0.84 kg |
| Dimensions: |
260 x 248 x 48 mm |
| Supported languages: |
Polish, English, Bulgarian, Czech, Danish, Finnish, French, Greek, Spanish, Dutch, German, Portuguese, Russian, Romanian, Serbian, Slovenian, Swedish, Hungarian, Italian |
| Manufacturer / Brand: |
DAHUA |
| Guarantee: |
3 years |
