| Standard: |
TCP/IP |
| Supported resolutions: |
max. 6 Mpx |
| Video outputs: |
1 pcs HDMI
1 pcs VGA |
| Audio support: |
8 Channels - Audio from cameras |
| Audio inputs: |
 |
| Audio outputs: |
|
| Image compression method: |
H.265+ / H.265 / H.264+ / H.264 |
| Bitrate: |
max. 60 Mbps |
| Supported hard drives: |
1 x 6 TB SATA |
| Recording modes: |
Manual, Motion Detection, Schedule |
| External storage devices backup: |
Backup to USB drive (pendrive, external drive) |
| Searching and playback the records: |
Records searching: by time and events type. Records playback: forward, backward, fast, slow
Records playback from max. 4 channels in the same time @ 1080p
1 or 4 channels synchronous playback, Smart Search function |
| Network interface: |
1 x RJ-45 10/100 Base-TX |
| Network functions: |
Live image view, Playback the records, Backup the records - iVMS-4200 application
The device has the ability to work with the Hik-Connect application for mobile devices |
| Network protocols: |
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP |
| ONVIF: |
 |
| Default IP address: |
192.168.1.64 |
| Default admin user / password: |
admin / -
The administrator password should be set at the first start |
| Mobile phones support: |
Port no.: 8000 or access by a cloud (P2P) Android: Free application Hik-Connect iOS: Free application Hik-Connect |
| Web browser access ports: |
80 |
| PC client access ports: |
Port no.: 8000 or access by a cloud (P2P) - iVMS-4200 application |
| Mobile client access ports: |
8000 |
| RTSP URL: |
Main stream : rtsp://user:password@192.168.1.64:554/Streaming/Channels/channel_no01/ Sub stream : rtsp://user:password@192.168.1.64:554/Streaming/Channels/channel_no02/ |
| USB: |
2 pcs USB 2.0 |
| Alarm inputs / outputs: |
|
| Intelligent Image Analysis: |
|
| Main features: |
Functions implemented in cooperation between the recorder and cameras that support these functions
IVS analysis : crossing the line (tripwire), intrusion Motion Detection |
| PTZ control: |
IP Speed Dome Cameras |
| Motion Detection: |
|
| Mouse support: |
|
| IR remote controller in the set: |
|
| Power supply: |
12 V DC / 1.5 A (power adapter included) |
| Power consumption: |
≤ 10 W (without HDD) |
| Operation temp: |
-10 °C ... 55 °C |
| Weight: |
0.78 kg |
| Dimensions: |
265 x 223 x 48 mm |
| Supported languages: |
Polish, English |
| Manufacturer / Brand: |
Hikvision |
| SAP Code: |
303618109 |
| Guarantee: |
3 years |
