| Standard: |
IP |
| Resolution: |
2560 x 1440 - 3.7 Mpx ,
2304 x 1296 - 3 Mpx ,
1920 x 1080 - 1080p ,
1280 x 960 - 1.3 Mpx
1280 x 720 - 720p |
| Sensor: |
1/2.8 " Progressive Scan CMOS |
| Lens: |
2.8 ... 12 mm |
| View angle: |
97 ° ... 31.6 ° |
| Optical zoom: |
x 4 |
| Digital zoom: |
x 16 |
| Range of IR illumination: |
20 m |
| Video output: |
 |
| Rotation speed (manual control): |
0.1 °/s ... 70 °/s (horizontal) 0.1 °/s ... 30 °/s (vertical) |
| Preset rotation speed: |
80 °/s (horizontal) 40 °/s (vertical) |
| Horizontal rotation range: |
0 ° ... 355 ° - Rotation of the head is limited by stops |
| Vertical rotation range: |
5 ° ... 90 ° |
| RS-485 interface: |
|
| Number of presets: |
300 |
| Horizontal scan: |
 |
| Route settings: |
8 |
| Image compression method: |
H.265 / H.265+ / H.264 / H.264+ / MJPEG |
| Alarm inputs / outputs: |
|
| Main stream frame rate: |
25 fps - 4 Mpx |
| Memory card slot: |
Micro SD card support up to 512GB |
| Interface: |
10/100 Base-T (RJ-45) |
| WEB Server: |
Built-in, NVR compliance |
| Max. number of on-line users: |
20 |
| ONVIF: |
|
| Audio: |
Microphone built-in, External microphone input, Audio output, Bi-directional audio streaming support Audio detection |
| Mobile phones support: |
Port no.: 37777 or access by a cloud (P2P) Android: DMSS free application iOS (iPhone): DMSS free application |
| Default admin user / password: |
admin / -
The administrator password should be set at the first start |
| Default IP address: |
192.168.1.108 |
| Web browser access ports: |
80, 37777 |
| PC client access ports: |
37777 |
| Mobile client access ports: |
37777 |
| ONVIF port: |
80 |
| RTSP URL: |
rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main stream
rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Sub stream |
| Intelligent Image Analysis: |
intrusion Target Count face detection scene changing video tampering abandoned/missing object classification of people and vehicles crossing the line (tripwire) |
| Main features: |
WDR - 120 dB - Wide Dynamic Range 2D-DNR, 3D-DNR - Digital Noise Reduction ROI - improve the quality of selected parts of image F-DNR (Defog) - Reduction of image noise caused by precipitation EIS - Electronic Image Stabilization BLC/HLC - Back Light / High Light Compensation ICR - Movable InfraRed filter Day/night mode Configurable Privacy Zones Smart motion detection (with recognizing people and vehicles) SMD 3.0 - searching for an object classified as: human, motor vehicle IVS analysis |
| Power supply: |
PoE (802.3af), 12 V DC / 1.08 A (max) |
| Power consumption: |
≤ 4 W (typical) 13 W (max) |
| Housing: |
Speed Dome
Metal, Plastic |
| Color: |
Black + White |
| "Index of Protection": |
IP66 |
| Mechanical protection class: |
IK08 |
| Operation temp: |
-30 °C ... 60 °C |
| Weight: |
0.51 kg |
| Dimensions: |
Ø 128 x 65 mm |
| Supported languages: |
Polish, English, Czech, French, Spanish, Dutch, German, Portuguese, Russian, Italian |
| Manufacturer / Brand: |
DAHUA |
| Guarantee: |
5 years |
