IP-kamera 5MP IR FISHEYE VIGI INSIGHT S655I TP-LINK

Lisätiedot

Vendor Homepage

https://www.tp-link.com/in/business-networking/vigi-network-camera/insight-s655i/

Garantija

36

Model

InSight S655I

Category Code

FNC

Unit Box Height

0.09

Unit Box Length

0.2

Unit Box Width

0.17

Units per Shipping Box

1

Unit Calculated Volume

0.00306 cubm

Unit Calculated Weight

0.755 kg

Summary

TP-Link InSight S655I. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Housing material: Metal. Lens viewing angle, horizontal: 180 , Lens viewing angle, vertical:

Weight & dimensions (Height)

56 mm

Weight & dimensions (Weight)

440 g

Performance (Certification)

CE NTRA KC FCC VCCI BSMI ONVIF

Operational conditions (Operating temperature (T-T))

-30 - 60 C

Operational conditions (Storage relative humidity (H-H))

0 - 95 %

Operational conditions (Storage temperature (T-T))

-40 - 60 C

Weight & dimensions (Diameter)

132 mm

Network (Bluetooth)

No

Network (Ethernet LAN)

Yes

Network (Wi-Fi)

No

Design (Product colour)

White

Power (Power consumption (max))

11.76 W

Ports & interfaces (Ethernet LAN (RJ-45) ports)

1

Design (Housing material)

Metal

Operational conditions (Operating relative humidity (H-H))

0 - 95 %

Camera (Camera shutter speed)

1/3 - 1/10000 s

Audio (Audio system)

2-way

Storage (Compatible memory cards)

MicroSD (TransFlash)

Storage (Maximum memory card size)

512 GB

Power (Power source type)

DC,PoE

Storage (Card reader integrated)

Yes

Performance (Wide Dynamic Range (WDR))

Yes

Audio (Built-in speaker(s))

Yes

Audio (Built-in microphone)

Yes

Design (Protection features)

Weatherproof

Security (Password protection)

Yes

Audio (Number of microphones)

1

Network (Ethernet interface type)

Fast Ethernet

Design (IK code)

IK10

Design (International Protection (IP) code)

IP67

Design (Mounting type)

Ceiling/wall

Design (Weatherproof)

Yes

Performance (Connectivity technology)

Wired

Performance (Day/night mode)

Yes

Performance (Infrared (IR) cut-off filter)

Yes

Performance (Placement supported)

Indoor

Performance (Type)

IP security camera

Camera (Lens viewing angle, diagonal)

180

Camera (Lens viewing angle, horizontal)

180

Camera (Lens viewing angle, vertical)

180

Image sensor (Optical sensor size)

1/2.7 "

Night vision (LED type)

IR

Night vision (Night vision)

Yes

Night vision (Night vision distance)

10 m

Video (Frame rate)

30 fps

Video (Image quality adjustment)

Brightness/Contrast/Saturation/Sharpness

Video (Maximum resolution)

2560 x 1920 pixels

Video (Noise reduction technology)

3D noise reduction

Video (Total megapixels)

5 MP

Storage (Built-in HDD)

No

Management features (Reset button)

Yes

Power (DC output voltage)

12

Packaging content (Number of cameras)

1

Image sensor (Sensor type)

CMOS

Lens system (Fixed focal length)

1.44 mm

Technical details (Lens mount interface)

M12

Camera (Minimum illumination)

0 lx

Video (Back Light Compensation (BLC))

Yes

Video (Highlight Compensation (HLC))

Yes

Image sensor (Progressive scan)

Yes

Lens system (Maximum aperture number)

2

Video (Region of Interest (ROI) encoding)

Yes

Security (Video motion detection)

Yes

Video (Video compression formats)

H.264/H.264+/H.265/H.265+

Video (Digital Wide Dynamic Range (DWDR))

Yes

Video (Bit rate control)

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Video (Supported graphics resolutions)

1280 x 960/2048 x 1536 (QXGA)/2560 x 1920/320 x 240/640 x 480 (VGA)

Video (Video streaming)

Yes

Audio (Signal-to-Noise Ratio (SNR))

52 dB

Network (Supported network protocols)

TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP

Management features (Web browser)

Yes

Video (Smart IR)

Yes

Night vision (Number of illumination LEDs)

4

Security (HTTPS encryption)

Yes

Security (Privacy protection)

Yes

Power (Power consumption (Power over Ethernet (PoE)))

12.14 W

Performance (Dynamic range)

120 dB

Lens system (Detect distance)

28.8 m

Lens system (Identify distance)

2.8 m

Lens system (Observe distance)

12 m

Lens system (Recognize distance)

5.7 m

Video (Bit rate)

64 Kbps to 6 Mbps

Audio (Bit rate range)

0 - 64 Kbit/s

Security (Motion sensor)

Yes

Night vision (Infra-red wavelength)

850 nm

Security (IP address filtering)

Yes

Panoramic camera (Digital Wide Dynamic Range (DWDR) (panoramic camera))

Yes

Network (Networking standards)

IEEE 802.3/IEEE 802.3af/IEEE 802.3at/IEEE 802.3u

Security (Digest authentication)

Yes

Camera (Number of Privacy masking areas)

4

Audio (Sample rate)

8 kHz

Network (Number of simultaneous live view channels)

6 channels

Management features (Cloud-managed)

Yes

Network (Client interoperability)

Utility, VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS

Panoramic camera (Signal-to-Noise Ratio (SNR) (panoramic camera))

52 dB

Security (Alert notification type)

E-mail,Push notification

Panoramic camera (Sensor type (panoramic camera))

CMOS

Tilausviitteet

EAN13

8885020627848

Valmistajan tuotenumero (MPN)

1445894
