NET CAMERA P1468-LE 8MP/02342-001 AXIS

Lisätiedot

Vendor Homepage

https://www.axis.com/products/axis-p1468-le

Garantija

60

Model

P1468-LE

Category Code

FNC

Unit Box Height

0.06

Unit Box Length

0.26

Unit Box Width

0.18

Units per Shipping Box

1

Unit Calculated Volume

0.002808 cubm

Unit Calculated Weight

1.5 kg

Summary

Axis 02342-001. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Bullet. Minimum illumination: 0.07 lx, Camera shutter speed: 1/66500 - 2 s. S

Weight & dimensions (Width)

280 mm

Weight & dimensions (Depth)

280 mm

Weight & dimensions (Weight)

1200 g

Performance (Certification)

EN 55032 Class A, EN 50121-4, IEC 62236-4, EN 55035, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A

Operational conditions (Operating temperature (T-T))

-40 - 60 C

Operational conditions (Storage relative humidity (H-H))

5 - 95 %

Operational conditions (Storage temperature (T-T))

-40 - 65 C

Weight & dimensions (Diameter)

132 mm

Network (Bluetooth)

No

Network (Ethernet LAN)

Yes

Network (Wi-Fi)

No

Design (Product colour)

White

Power (Power consumption (max))

12.95 W

Power (Power consumption (typical))

7.7 W

Ports & interfaces (Ethernet LAN (RJ-45) ports)

1

Design (Housing material)

Aluminium/Polycarbonate (PC)

Packaging content (Manual)

Yes

Other features (Doesn't contain)

BFR/PVC

Operational conditions (Operating relative humidity (H-H))

10 - 100 %

Design (Form factor)

Bullet

Camera (Camera shutter speed)

1/66500 - 2 s

Audio (Audio system)

2-way

Storage (Compatible memory cards)

MicroSD (TransFlash)/MicroSDHC/MicroSDXC

Power (Power source type)

PoE

Storage (Card reader integrated)

Yes

Performance (Languages support)

English/French/German/Italian/Japanese/Korean/Portuguese/Russian/Simplified Chinese/Spanish/Traditional Chinese

Performance (Wide Dynamic Range (WDR))

Yes

Security (Password protection)

Yes

Security (Security algorithms)

256-bit AES-XTS/EAP-TLS

Design (IK code)

IK10

Design (International Protection (IP) code)

IP66, IP67

Design (Mounting type)

Ceiling/wall

Performance (Connectivity technology)

Wired

Performance (Day/night mode)

Yes

Performance (Infrared (IR) cut-off filter)

Yes

Performance (Placement supported)

Indoor & outdoor

Performance (Type)

IP security camera

Image sensor (Optical sensor size)

1/1.2 "

Lens system (Number of lenses)

1

Lens system (Zoom capability)

Yes

Night vision (LED type)

IR

Night vision (Night vision)

Yes

Night vision (Night vision distance)

40 m

Video (Frame rate)

60 fps

Video (Maximum resolution)

3840 x 2160 pixels

Video (Privacy masking)

Yes

Video (Text caption overlay)

Yes

Storage (Built-in HDD)

No

Packaging content (Number of cameras)

1

Image sensor (Sensor type)

CMOS

Lens system (Focal length range)

6.2-12.9 mm

Camera (Minimum illumination)

0.07 lx

Image sensor (Progressive scan)

Yes

Video (Flip & mirror)

Yes

Security (Video motion detection)

Yes

Video (Video compression formats)

H.264/H.265/M-JPEG

Image sensor (Number of sensors)

1

Video (Bit rate control)

Variable Bit Rate (VBR)

Video (Supported graphics resolutions)

1280 x 720 (HD 720)

Video (Video streaming)

Yes

Audio (Audio formats supported)

AAC-LC/ADPCM/G.711/G.726/LPCM/OPUS/PCM

Network (Quality of Service (QoS) support)

Yes

Network (Supported network protocols)

IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa , HTTP/2, TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTCP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SSH, LLDP

Storage (Internal memory)

2048 MB

Security (Active tampering alarm)

Yes

Security (HTTPS encryption)

Yes

Video (Bit rate)

Configurable bit rate

Video (Video recording)

Yes

Storage (Flash memory)

8192 MB

Night vision (Infra-red wavelength)

850 nm

Security (IP address filtering)

Yes

Network (Networking standards)

IEEE 802.1x/IEEE 802.3af/IEEE 802.3at

Security (Digest authentication)

Yes

Performance (PTZ modes)

Digital PTZ

Video (Video intelligence analytic)

Yes

Performance (Number of languages)

11

Lens system (Optical zoom)

2.08 x

Security (Alert notification type)

E-mail

Audio (Audio detection)

Yes

Packaging content (Drilling template included)

Yes

Security (Pixel counter)

Yes

Ports & interfaces (Terminal block port)

Yes

Packaging content (Mounting brackets included)

Yes

Tilausviitteet

EAN13

7331021076129

Valmistajan tuotenumero (MPN)

1378337
