NET CAMERA 5MP IR BULLET/HFW5541E-ASE-0280B-S3 DAHUA

Lisätiedot

Vendor Homepage

https://www.dahuasecurity.com/es/products/All-Products/Network-Cameras/WizMind-S-Series/5MP/IPC-HFW5541E-ASE S3

Garantija

36

Model

IPC-HFW5541E-ASE-0280B-S3

Category Code

FNC

Unit Box Height

0.1

Unit Box Length

0.22

Unit Box Width

0.115

Units per Shipping Box

1

Unit Calculated Volume

0.00253 cubm

Unit Calculated Weight

0.783 kg

Summary

Dahua Technology WizMind IPC-HFW5541E-ASE-0280B-S3. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: White, Form factor: Bullet. Angle of rotation: 360 , Lens viewing ang

Weight & dimensions (Width)

70.5 mm

Weight & dimensions (Depth)

192.7 mm

Weight & dimensions (Height)

66.4 mm

Weight & dimensions (Weight)

590 g

Packaging data (Package weight)

780 g

Operational conditions (Operating temperature (T-T))

-40 - 60 C

Operational conditions (Storage relative humidity (H-H))

10 - 95 %

Operational conditions (Storage temperature (T-T))

-40 - 60 C

System requirements (Mobile operating systems supported)

Android/iOS

Audio (Audio output channels)

1.0 channels

Network (Bluetooth)

No

Network (Ethernet LAN)

Yes

Network (Wi-Fi)

No

Design (Product colour)

White

Power (Power consumption (typical))

4 W

Ports & interfaces (Ethernet LAN (RJ-45) ports)

1

Design (Housing material)

Metal

Design (Form factor)

Bullet

Camera (Camera shutter speed)

1/3 - 1/100000 s

Storage (Compatible memory cards)

MicroSD (TransFlash)

Storage (Maximum memory card size)

512 GB

Power (Power source type)

DC,PoE

Storage (Card reader integrated)

Yes

Performance (Wide Dynamic Range (WDR))

Yes

Audio (Built-in microphone)

Yes

Network (Ethernet interface type)

Fast Ethernet

Design (International Protection (IP) code)

IP67

Design (Mounting type)

Wall

Performance (Connectivity technology)

Wired

Performance (Day/night mode)

Yes

Performance (Placement supported)

Indoor & outdoor

Performance (Type)

IP security camera

Camera (Lens viewing angle, diagonal)

132

Camera (Lens viewing angle, horizontal)

111

Camera (Lens viewing angle, vertical)

58

Image sensor (Optical sensor size)

1/2.7 "

Night vision (Night vision)

Yes

Night vision (Night vision distance)

50 m

Video (Maximum resolution)

2960 x 1668 pixels

Video (Noise reduction)

Yes

Video (Privacy masking)

Yes

Video (Total megapixels)

5 MP

Storage (Built-in HDD)

No

Power (DC output voltage)

12

Packaging content (Number of cameras)

1

Image sensor (Sensor type)

CMOS

Security (Alarm input channels)

1

Security (Alarm output channels)

1

Lens system (Fixed focal length)

2.8 mm

Audio (Audio input channels)

1.0 channels

Performance (Alarm input/output)

Yes

Camera (Minimum illumination)

0 lx

Video (Back Light Compensation (BLC))

Yes

Video (Highlight Compensation (HLC))

Yes

Image sensor (Progressive scan)

Yes

Video (Gain control type)

Auto

Camera (Camera shutter type)

Electronic

Video (Region of Interest (ROI) encoding)

Yes

Security (Video motion detection)

Yes

Video (Video compression formats)

H.264/H.264B/H.264H/H.265/M-JPEG

Camera (Angle of rotation)

360

Camera (Pan range)

0 - 360

Camera (Tilt angle range)

0 - 90

Camera (White balance)

Auto/Manual/Natural/Outdoor/Regional custom/Street lamp

Video (Bit rate control)

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Video (Supported graphics resolutions)

1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2048 x 1536 (QXGA)/2304 x 1296/2560 x 1440/2688 x 1520/2880 x 1620/352 x 240/352 x 288/640 x 480 (VGA)/704 x 480/704 x 576

Video (Video streaming)

Yes

Audio (Signal-to-Noise Ratio (SNR))

56 dB

Network (Supported network protocols)

IPv4 IPv6 HTTP TCP UDP ARP RTP RTSP RTCP RTMP SMTP FTP SFTP DHCP DNS DDNS QoS UPnP NTP Multicast ICMP IGMP NFS SAMBA PPPoE SNMP P2P

Storage (Internal memory)

1024 MB

Storage (ROM capacity)

4096 MB

Management features (Management software)

SmartPSS Lite DSS DMSS

Management features (Web browser)

Yes

Lens system (Closest focusing distance)

1.1 m

Night vision (Number of illumination LEDs)

1

Network (Number of users)

20 user(s)

Security (Mirror)

Yes

Power (Power consumption (Power over Ethernet (PoE)))

5.8 W

Lens system (Detect distance)

63.6 m

Lens system (Identify distance)

6.4 m

Lens system (Observe distance)

25.4 m

Lens system (Recognize distance)

12.7 m

Lens system (Minimum aperture number)

1.6

Performance (People counting function)

Yes

Tilausviitteet

EAN13

6923172585172

Valmistajan tuotenumero (MPN)

1396731
