Type Fixed Dome/HDTV/Megapixel/Outdoor | Resolution 6 Mega Pixel | Focal Length 2.7 mm-13.5 mm | IR Illumination | Sensor size 1/2.7" | Microphone Built-in | Min. Illumination 0.0005 Lux | Effective pixels 3288 (H) 1850 (V) | Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s | Supports card capacities up to 512GB | Power options PoE/12V | Power supply requirements 12 VDC/PoE (802.3af) | Environment Outdoor | Operating temperature range -40 C to +60 C | Dimensions 94.0 mm × Φ122.0 mm
> 6-MP 1/2.7" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 6 MP (3288 × 1850)@25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in multi-core light, the max. IR distance is 50 m and the max. warm light distance is 50 m.
> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection,video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 G Micro SD card; built-in Mic.
> 12 VDC/PoE power supply.
> IP67, IK10 protection.
> SMD 4.0.
> Supports AI SSA.
> SMD area can be set in warm light areas that support triggering alarms.
> Focal Length 2.7 mm-13.5 mm, Field of View 114°–32°
Type HDTV/Megapixel/Outdoor | Resolution 5 Mega Pixel | Focal Length 2.8–8 mm | IR Illumination | Sensor size 1/2.7” | Min. Illumination 0.03 Lux | Electronic Shutter Speed 1/50000 s to 1/5 s | Power options PoE | Power supply requirements Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 3 Typical: 5.8 W, max 12.95 W 10–28 V DC, typical 5.2 W, max...
Type Fixed Dome/HDTV/Megapixel/Outdoor | Resolution 4 Mega Pixel | Focal Length 2.8 mm | Sensor size 1/2.7” | Min. Illumination 0.005 Lux | Electronic Shutter Speed 1/3 to 1/10000 s | Supports card capacities up to 512GB | Power options PoE/12V | Power supply requirements 12V DC ± 5%, Max. 10.54 W, 5.5 mm Coaxial Power Plug, PoE: 802.3af/at, class 0, Max....
Type PTZ | Resolution 4 Mega Pixel | Focal Length 2.8 mm–12 mm | IR Illumination | Sensor size 1/2.8 ” CMOS | Min. Illumination 0.005 Lux | Electronic Shutter Speed 1/1 s–1/30,000 s | Supports card capacities up to 512GB | Power options 12V | Environment Outdoor | Operating temperature range -30°C~+60°C | Dimensions 89 mm × Φ122 mm
Resolution 3 Mega Pixel | Focal Length 4mm | IR Illumination | Sensor size 1/2.8” Progressive Scan CMOS | Microphone Built-in | Lens Mount M12 | Min. Illumination 0.005 Lux | Power options PoE/12V | Power supply requirements 12V DC ± 5%, 5.5mm Coaxial Power Plug; PoE (802.3af/at, class 0) | Operating temperature range -30–60 °C | Included Accessories...
Type Fixed Dome/HDTV/Megapixel/Outdoor | Resolution 6 Mega Pixel | Focal Length 2.7 mm-13.5 mm | IR Illumination | Sensor size 1/2.7" | Microphone Built-in | Min. Illumination 0.0005 Lux | Effective pixels 3288 (H) 1850 (V) | Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s | Supports card capacities up to 512GB | Power options PoE/12V | Power supply requirements 12 VDC/PoE (802.3af) | Environment Outdoor | Operating temperature range -40 C to +60 C | Dimensions 94.0 mm × Φ122.0 mm
