Kirjeldus
- 1/2.7" CMOS image sensor, low luminance, and high definition image
- Outputs max. 6 MP (3288×1850) @20 fps, and supports 2688×1520 (2688 × 1520) @25/30 fps
- H.265 codec, high compression rate, ultra-low bit rate
- Built-in warm light and IR LED, the max. IR distance is 30 m and the max. warm light distance is 30 m
- ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
- Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
- Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
- Supports max. 256 G Micro SD card; built in Mic
- 12 VDC/PoE power supply, easy for installation
Üldine informatsioon
IPC-HFW2649S-S-IL-0280B
30 Tooted
Lisainfo
- Müüja koduleht
- https://www.dahuasecurity.com/products/All-Products/Network-Cameras/WizSense-Series/2-Series/Smart-Dual-Light/IPC-HFW2649S-S-IL
- Garantija
- 36
- Category Code
- FNC
- Unit Box Height
- 0.095
- Unit Box Length
- 0.105
- Unit Box Width
- 0.21
- Units per Shipping Box
- 20
- Unit Calculated Volume
- 0.00272 cubm
- Unit Calculated Weight
- 0.65 kg
- Summary
- Dahua Technology WizSense IPC-HFW2649S-S-IL-0280B. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wired. Mounting type: Pole clamp, Product colour: White, Form factor: Bullet. Minimum illumination: 0.0007 lx, Angle of rota
- Weight & dimensions (Width)
- 70 mm
- Weight & dimensions (Height)
- 70 mm
- Weight & dimensions (Weight)
- 470 g
- Packaging data (Package weight)
- 590 g
- Operational conditions (Operating temperature (T-T))
- -40 - 60 C
- Operational conditions (Storage temperature (T-T))
- -40 - 60 C
- System requirements (Mobile operating systems supported)
- Android/iOS
- Network (Bluetooth)
- No
- Network (Ethernet LAN)
- Yes
- Network (Wi-Fi)
- No
- Design (Product colour)
- White
- Power (Power consumption (max))
- 4.4 W
- Power (Power consumption (typical))
- 2.5 W
- Ports & interfaces (Ethernet LAN (RJ-45) ports)
- 1
- Design (Housing material)
- Metal
- Packaging content (Manual)
- Yes
- Ports & interfaces (DC-in jack)
- Yes
- Design (Form factor)
- Bullet
- Weight & dimensions (Length)
- 169.8 mm
- Camera (Camera shutter speed)
- 1/3 - 1/100000 s
- Storage (Compatible memory cards)
- MicroSD (TransFlash)
- Storage (Maximum memory card size)
- 256 GB
- Power (Power source type)
- DC,PoE
- Sustainability (Compliance certificates)
- CE
- Storage (Card reader integrated)
- Yes
- Performance (Wide Dynamic Range (WDR))
- Yes
- Audio (Built-in microphone)
- Yes
- Storage (RAM capacity)
- 256 MB
- Network (Ethernet interface type)
- Fast Ethernet
- Design (International Protection (IP) code)
- IP67
- Design (Mounting type)
- Pole clamp
- Performance (Connectivity technology)
- Wired
- Performance (Day/night mode)
- Yes
- Performance (Placement supported)
- Indoor
- Performance (Type)
- IP security camera
- Camera (Camera pan control)
- Yes
- Camera (Camera tilt control)
- Yes
- Camera (Lens viewing angle, diagonal)
- 132
- Camera (Lens viewing angle, horizontal)
- 112
- Camera (Lens viewing angle, vertical)
- 61
- Image sensor (Optical sensor size)
- 1/2.7 "
- Night vision (LED type)
- IR
- Night vision (Night vision)
- Yes
- Night vision (Night vision distance)
- 30 m
- Video (Frame rate)
- 30 fps
- Video (Maximum resolution)
- 3288 x 1850 pixels
- Video (Noise reduction)
- Yes
- Video (Noise reduction technology)
- 3D noise reduction
- Video (Total megapixels)
- 6 MP
- Storage (Built-in HDD)
- No
- Power (DC output voltage)
- 12
- Packaging content (Number of cameras)
- 1
- Image sensor (Sensor type)
- CMOS
- Lens system (Fixed focal length)
- 2.8 mm
- Camera (Minimum illumination)
- 0.0007 lx
- Video (Back Light Compensation (BLC))
- Yes
- Video (Highlight Compensation (HLC))
- Yes
- Image sensor (Progressive scan)
- Yes
- Lens system (Fixed focus)
- Yes
- Lens system (Maximum aperture number)
- 1.6
- Video (Gain control type)
- Auto/Manual
- Video (Region of Interest (ROI) encoding)
- Yes
- Security (Video motion detection)
- Yes
- Video (Video compression formats)
- H.264/H.264B/H.264H/H.265/M-JPEG
- Image sensor (Number of sensors)
- 1
- Camera (Angle of rotation)
- 360
- Camera (Pan range)
- 0 - 360
- Camera (Tilt angle range)
- 0 - 90
- Camera (White balance)
- Auto/Manual/Natural/Outdoor/Regional custom/Street lamp
- Video (Bit rate control)
- Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Video (Video streaming)
- Yes
- Audio (Audio formats supported)
- G.711 -law/G.711 A-law/G.726/PCM
- Network (Quality of Service (QoS) support)
- Yes
- Network (Streaming method)
- Multicast
- Network (Supported network protocols)
- IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, ICMP, IGMP, NFS, PPPoE, P2P
- Storage (ROM capacity)
- 128 MB
- Lens system (Closest focusing distance)
- 1 m
- Night vision (Number of illumination LEDs)
- 2
- Security (Mirror)
- Yes
- Performance (Dynamic range)
- 120 dB
- Lens system (Detect distance)
- 61.2 m
- Lens system (Identify distance)
- 6.1 m
- Lens system (Observe distance)
- 24.5 m
- Lens system (Recognize distance)
- 12.2 m
- Video (Video recording)
- Yes
- Security (IP address filtering)
- Yes
- Network (Networking standards)
- IEEE 802.1x
- Camera (Number of Privacy masking areas)
- 4
- Security (Network access storage (NAS))
- Yes
- Night vision (Colour night vision distance)
- 30 m
- Security (Human and vehicle targets classification)
- Yes
Eriviited
- ean13
- 6939554905261
- MPN
- 1441455
