Kirjeldus
Outputs max. 4MP (2688×1520) @25/30 fps Built-in IR LED, and the max. illumination distance is 60 m ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC 12 VDC/PoE power supply; ePoE IP67 and IK10 protection SMD 3.0
Üldine informatsioon
Tootekood
IPC-HFW5442E-ZE-2712-S3
Tarneaeg 2-5 tööpäeva.
1 Ühik
Lisainfo
Müüja koduleht
https://www.dahuasecurity.com/products/All-Products/Network-Cameras/WizMind-S-Series/4MP/IPC-HFW5442E-ZE S3
Garantija
36
Mudel
IPC-HFW5442E-ZE-2712-S3
Category Code
FNC
Unit Box Height
0.14
Unit Box Length
0.37
Unit Box Width
0.15
Units per Shipping Box
1
Unit Calculated Volume
0.00777 cubm
Unit Calculated Weight
1.59 kg
Summary
Dahua Technology Pro DH-IPC-HFW5442EP-ZE-2712-S3. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Bullet. Angle of rotation: 360 , Lens viewi
Weight & dimensions (Width)
95 mm
Weight & dimensions (Depth)
95 mm
Weight & dimensions (Weight)
1120 g
Packaging data (Package weight)
1660 g
Operational conditions (Operating temperature (T-T))
-30 - 60 C
Operational conditions (Storage relative humidity (H-H))
10 - 95 %
Operational conditions (Storage temperature (T-T))
5 - 40 C
System requirements (Mobile operating systems supported)
Android/iOS
Audio (Audio output channels)
1.0 channels
Network (Bluetooth)
No
Network (Ethernet LAN)
Yes
Network (Wi-Fi)
No
Design (Product colour)
White
Power (Power consumption (max))
9.9 W
Ports & interfaces (Ethernet LAN (RJ-45) ports)
1
Design (Housing material)
Metal/Plastic
Operational conditions (Operating relative humidity (H-H))
10 - 95 %
Design (Form factor)
Bullet
Weight & dimensions (Length)
273.2 mm
Camera (Camera shutter speed)
1/3 - 1/100000 s
Storage (Compatible memory cards)
MicroSD (TransFlash)
Storage (Maximum memory card size)
256 GB
Power (Power source type)
DC,PoE
Storage (Card reader integrated)
Yes
Performance (Wide Dynamic Range (WDR))
Yes
Audio (Built-in microphone)
Yes
Network (Ethernet interface type)
Fast Ethernet
Design (IK code)
IK10
Design (International Protection (IP) code)
IP67
Design (Mounting type)
Ceiling/wall
Performance (Connectivity technology)
Wired
Performance (Day/night mode)
Yes
Performance (Placement supported)
Indoor & outdoor
Performance (Type)
IP security camera
Camera (Lens viewing angle, diagonal)
137 - 54
Camera (Lens viewing angle, horizontal)
115 - 47
Camera (Lens viewing angle, vertical)
62 - 27
Image sensor (Optical sensor size)
1/1.8 "
Night vision (LED type)
IR
Night vision (Night vision)
Yes
Night vision (Night vision distance)
60 m
Video (Frame rate)
30 fps
Video (Maximum resolution)
2688 x 1520 pixels
Video (Noise reduction)
Yes
Video (Noise reduction technology)
3D noise reduction
Video (Privacy masking)
Yes
Video (Total megapixels)
4 MP
Storage (Built-in HDD)
No
Power (DC output voltage)
12
Packaging content (Number of cameras)
1
Image sensor (Number of effective pixels (H x V))
2688 x 1520 pixels
Image sensor (Sensor type)
CMOS
Lens system (Focal length range)
2.7 - 12 mm
Security (Alarm input channels)
2
Security (Alarm output channels)
1
Audio (Audio input channels)
1.0 channels
Performance (Alarm input/output)
Yes
Camera (Minimum illumination)
0 lx
Video (Back Light Compensation (BLC))
Yes
Video (Highlight Compensation (HLC))
Yes
Camera (Adjustment shutter speed)
Auto/Manual
Image sensor (Progressive scan)
Yes
Lens system (Maximum aperture number)
1.8
Video (Gain control type)
Auto/Manual
Camera (Camera shutter type)
Electronic
Video (Region of Interest (ROI) encoding)
Yes
Security (Video motion detection)
Yes
Video (Image stabilizer)
Yes
Video (Video compression formats)
H.264/H.264+/H.265/H.265+/M-JPEG
Image sensor (Number of sensors)
1
Camera (Angle of rotation)
360
Camera (Pan range)
0 - 360
Camera (Tilt angle range)
0 - 90
Camera (White balance)
Auto/Manual/Natural/Outdoor
Video (Bit rate control)
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Video (Supported graphics resolutions)
1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2304 x 1296/2688 x 1520/352 x 240/352 x 288/640 x 480 (VGA)/704 x 480/704 x 576
Video (Video streaming)
Yes
Audio (Audio formats supported)
AAC
Network (Quality of Service (QoS) support)
Yes
Network (Streaming method)
Multicast/Unicast
Network (Supported network protocols)
HTTP TCP ARP RTSP RTP UDP RTCP SMTP FTP DHCP DNS DDNS PPPoE IPv4/v6 SNMP QoS UPnP NTP
Storage (Internal memory)
1024 MB
Storage (ROM capacity)
4000 MB
Lens system (Closest focusing distance)
1.5 m
Night vision (Number of illumination LEDs)
4
Network (Number of users)
20 user(s)
Security (Mirror)
Yes
Management features (Web-based management)
Yes
Power (Power consumption (Power over Ethernet (PoE)))
10.9 W
Performance (Dynamic range)
140 dB
Lens system (Detect distance (tele))
130.8 m
Lens system (Detect distance (wide))
57.5 m
Lens system (Identify distance (tele))
13.1 m
Lens system (Identify distance (wide))
5.8 m
Lens system (Observe distance (tele))
52.3 m
Lens system (Observe distance (wide))
23 m
Lens system (Recognize distance (tele))
26.2 m
Lens system (Recognize distance (wide))
52.3 m
Video (Bit rate)
32- 8192Kbps, 19- 8192Kbps
Network (Networking standards)
IEEE 802.3af
Camera (Number of Privacy masking areas)
8
Eriviited
ean13
6923172587251
MPN
1398067
