Launched by Dahua Technology, Dahua WizMind is a full portfolio of solutions composed of project-oriented products including IPC, IVSS,NVR, PTZ, XVR, Thermal and software platform which adopts industry-leading deep learning algorithms. Focusing on customer's requirements, WizMind provides precise, reliable and comprehensive AI solutions for verticals.
Series Overview
With its deep learning algorithms, the WizMind 5 Series camera offers advanced analytical capabilities for both audio and video. It integrates intelligent features such as video metadata, AcuPick, face detection, perimeter protection, and people counting. Powered by the Xinghan Large-Scale AI Models-Vision, the camera outstandingly delivers on its object detection, recognition, and scene adaptation functions. Equipped with AI-ISP imaging technology, it offers excellent night vision performance. The series is designed for durability, being dust-proof, waterproof, and vandal-proof, in compliance with IP67 and IK10 standards, though support for these certifications may vary across models.
Xinghan Large-Scale AI Models-Vision
Xinghan Large-Scale AI Models-Vision seamlessly expands the storage and operational capacity of algorithmic models through the powerful integration of edge AI model algorithms and NPU computing power. Engineered with a lightweight transformer architecture and enhanced by model distillation and quantization techniques, it optimizes the computing power consumption of ViT operators. This enables the system to collaborate on multiple tasks simultaneously through joint inference between small and large models optimized for edge devices.
Self-Learning
Empowered by deep learning technology, the device recognizes different types of targets and their statuses through learning and analyzing target features to detect targets and filter out false alarms.
WizColor Technology
Dahua WizColor Technology seamlessly combines with the powerful AI-ISP, large pixel size sensor and large aperture in cameras. This unique integration enables cameras to effortlessly capture high-quality images with vibrant colors during nighttime scenarios, ensuring fine details are preserved and minimizing motion blur. Unlike traditional self-illuminating cameras, Dahua WizColor Technology maximizes the utilization of weak light sources, such as moonlight and city lights reflected in the sky, delivering captivating full-color images of the entire scene. It also ensures that monitoring distances are not compromised at night due to limited illumination ranges, facilitating full-color image capture even over long distances.
AcuPick
This industry-leading search technology effectively utilizes both front-end and back-end intelligence to help with searching through massive video data to quickly and conveniently locate targets with greater precision.
Protection (IP67, IK10, Wide Voltage)
IP67: The camera passes a series of strict test on dust and soak. It has dustproof function, and the enclosure can work normally after soaking in 1 m deep water for 30 minutes. IK10: The enclosure can stand the punch more than 5 times from a 5 kg hammer falling from a height of 40 cm (Impact energy is 20J). Wide voltage: The camera allows ±30% (for some power supplies) input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.
1/1.8" CMOS image sensor, low luminance, and high definition image
Outputs max. 6 MP (3072 × 2048) @25/30 fps
Built-in multi-core light, the max. IR distance is 80 m and the max. warm light distance is 60 m
ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Features AI Rule Assist, which automatically creates highly accurate IVS rules based on the Xinghan Vision Models
With deep learning algorithm, it supports: AcuPick, video metadata, IVS, face detection, and people counting, etc
Alarm: 1 in, 1 out; audio: 1 in, 1 out; RS-485; supports max. 1 TB Micro SD card; built-in dual Mic; 1-ch speaker; support two-way talk
12 VDC/PoE power supply; ePoE; 12 VDC power output, and max. current 165mA, easy for installation
Bullet, Ceiling, Black/White, IP code IP67, IP security camera, Wired, Placement Outdoor, Day/night mode Yes, Built-in light Yes, Minimum illumination 0.005 lx, Pan range 0 - 360 °, Optical sensor size 1/2.7 ", Sensor type CMOS, 1xNumber of lenses, Identify distance 12 m, Night vision Yes, Night vision distance 30 m, Total megapixels 5...
Bullet, Ceiling/wall, White, IP code IP67, IP security camera, Wired, Placement Outdoor, Wide Dynamic Range (WDR) Yes, Day/night mode Yes, Pan range 0 - 360 °, White balance Auto/Manual/Natural/Outdoor/Custom modes, Camera shutter type Electronic, Optical sensor size 1/2.7 ", Sensor type CMOS, 1xNumber of lenses, Night vision Yes, Night...
Bullet, Wall, White, IP code IP67, IP security camera, Wired, Placement Indoor & outdoor, People counting function Yes, Wide Dynamic Range (WDR) Yes, Day/night mode Yes, Alarm input/output Yes, Pan range 0 - 360 °, White balance Auto/Manual/Natural/Outdoor/Regional custom/Street lamp, Camera shutter type Electronic, Optical sensor size...
