Kirjeldus
> 2-MP 1/3" CMOS image sensor, low luminance, and high definition image.
Üldine informatsioon
Tootekood
IPC-HDBW1230DE-SW-0280B
Tarneaeg 2-5 tööpäeva.
5 Tooted
Lisainfo
Müüja koduleht
https://www.dahuasecurity.com/products/All-Products/Network-Cameras/Wireless-Series/Wi-Fi-Series/2MP/IPC-HDBW1230DE-SW
Garantija
36
Mudel
IPC-HDBW1230DE-SW-0280B
Category Code
FNC
Unit Box Height
0.145
Unit Box Length
0.15
Unit Box Width
0.125
Units per Shipping Box
1
Unit Calculated Volume
0.002719 cubm
Unit Calculated Weight
0.646 kg
Summary
Dahua Technology Consumer DH-IPC-HDBW1230DEP-SW-0280B. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired & Wireless. Mounting type: Ceiling, Product colour: White, Form factor: Dome. Minimum illumination: 0.0025 lx, Fi
Weight & dimensions (Height)
88.7 mm
Weight & dimensions (Weight)
414 g
Packaging data (Package weight)
592 g
Operational conditions (Operating temperature (T-T))
-40 - 60 C
Operational conditions (Storage temperature (T-T))
-30 - 60 C
System requirements (Mobile operating systems supported)
Android/iOS
Weight & dimensions (Diameter)
110.7 mm
Network (Bluetooth)
No
Network (Ethernet LAN)
Yes
Network (Wi-Fi)
Yes
Network (Wi-Fi standards)
802.11b/802.11g/Wi-Fi 4 (802.11n)
Design (Product colour)
White
Power (Power consumption (max))
4.9 W
Power (Power consumption (typical))
2 W
Ports & interfaces (Ethernet LAN (RJ-45) ports)
1
Design (Housing material)
Metal
Management features (Firmware upgradeable)
Yes
Operational conditions (Operating relative humidity (H-H))
0 - 95 %
Design (Form factor)
Dome
Camera (Camera shutter speed)
1/3 s-1/100,000 s s
Camera (Field of view (FOV) angle)
120
Storage (Compatible memory cards)
MicroSD (TransFlash)
Storage (Maximum memory card size)
256 GB
Power (Power source type)
DC
Sustainability (Compliance certificates)
CE/Federal Communications Commission (FCC)
Storage (Card reader integrated)
Yes
Performance (Wide Dynamic Range (WDR))
Yes
Network (Ethernet interface type)
Fast Ethernet
Security (Security algorithms)
HTTPS
Design (IK code)
IK10
Design (International Protection (IP) code)
IP67
Design (Mounting type)
Ceiling
Performance (Connectivity technology)
Wired & Wireless
Performance (Placement supported)
Outdoor
Performance (Type)
IP security camera
Camera (Camera pan control)
Yes
Camera (Camera tilt control)
Yes
Camera (Lens viewing angle, diagonal)
120
Camera (Lens viewing angle, horizontal)
100
Camera (Lens viewing angle, vertical)
53
Image sensor (Optical sensor size)
1/2.8 "
Lens system (Number of lenses)
1
Lens system (Zoom capability)
No
Night vision (LED type)
IR
Night vision (Night vision)
Yes
Video (Frame rate)
30 fps
Video (Maximum resolution)
1920 x 1080 pixels
Video (Noise reduction)
Yes
Video (Noise reduction technology)
3D noise reduction
Video (Privacy masking)
Yes
Video (Total megapixels)
2 MP
Storage (Built-in HDD)
No
Power (DC output voltage)
12
Packaging content (Number of cameras)
1
Image sensor (Sensor type)
CMOS
Lens system (Focal length range)
2.8 mm
Camera (Minimum illumination)
0.0025 lx
Video (Back Light Compensation (BLC))
Yes
Camera (Adjustment shutter speed)
Auto/Manual
Image sensor (Progressive scan)
Yes
Lens system (Fixed focus)
Yes
Lens system (Maximum aperture number)
2
Video (Flip & mirror)
Yes
Video (Gain control type)
Auto
Camera (Camera shutter type)
Electronic
Video (Region of Interest (ROI) encoding)
Yes
Security (Video motion detection)
Yes
Video (Video compression formats)
H.264/H.264B/H.264H/H.265
Image sensor (Number of sensors)
1
Video (Digital Wide Dynamic Range (DWDR))
Yes
Camera (Angle of rotation)
355
Camera (Pan range)
0 - 355
Camera (Tilt angle range)
0 - 75
Camera (White balance)
Custom modes/Manual/Natural/Outdoor/Street lamp
Video (Bit rate control)
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Video (Supported graphics resolutions)
1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)
Video (Video formats supported)
H.264/H.264B/H.265
Video (Video streaming)
Yes
Audio (Signal-to-Noise Ratio (SNR))
56 dB
Network (Supported network protocols)
IPv4 HTTP TCP UDP ARP RTP RTSP RTCP DHCP DNS NTP Multicast RTMP
Storage (ROM capacity)
16 MB
Management features (Management software)
Smart PSS DSS DMSS
Management features (Web browser)
Yes
Video (Smart IR)
Yes
Night vision (Number of illumination LEDs)
3
Network (Number of users)
6 user(s)
Security (HTTPS encryption)
Yes
Management features (Web-based management)
Yes
Performance (Dynamic range)
56 dB
Lens system (Detect distance)
46.9 m
Lens system (Identify distance)
4.7 m
Lens system (Observe distance)
18.8 m
Lens system (Recognize distance)
9.4 m
Video (Bit rate)
9 - 4096
Video (Supported video modes)
1080p/720p/960p
Performance (Antenna type)
External
Performance (Antennas quantity)
1
Performance (Luminous flux)
0.0025 lm
Lens system (Lens diameter)
2.8 mm
Video (Video recording)
Yes
Network (Channel bandwidth)
36 MHz
Network (Live view)
Yes
Network (Wi-Fi data rate (max))
2400 Mbit/s
Storage (Flash memory)
64 MB
Security (Motion sensor)
Yes
Management features (Smartphone/tablet remote support)
Yes
Eriviited
ean13
6923172539960
MPN
1391443
