Mainboard|ASROCK|AMD A520|SAM4|Micro-ATX|Memory DDR4|Memory slots 2|1xPCI-Express 3.0 1x|1xPCI-Express 3.0 16x|1xM.2|1x15pin D-s

Tootekood A520M-HVS

Kaubamärk ASROCK

52,25 €

KM-ga

Tarneaeg 1-5 tööpäeva.

Kogus

Laos

Tarneaeg 2-5 tööpäeva. : 100 Tooted

Kirjeldus
Üldine informatsioon

Kirjeldus

A520 MOTHERBOARD FOR EVERYONE
All Essentials You Need For Computing

Ultra M.2 32Gb/s (PCIe Gen3 x4 & SATA3)
The PCIe Gen3 x4 Ultra M.2 interface pushes data transfer speeds up to 32Gb/s. In addition, it also supports SATA3 6Gb/s M.2 modules.

HDMI 4k @60Hz
Supports the most recent HDMI 4K 60Hz graphics output specification. With the larger bandwidth and increased frame rate, the motion on your screen becomes more fluid and less blurry.

Dual Graphics Outputs
Complete with two types of most used connectors! Packed with a D-Sub + HDMI combo, you have more graphics output options now.

Full Spike Protection
Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection includes various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes.

Live Update & APP Shop
ASRock Live Update & APP Shop is designed for your convenience. We provide various apps and support software for users to download. You can also easily optimize your system and keep your motherboard up to date with ASRock Live Update & APP Shop.

Supports 3rd Gen AMD AM4 Ryzen™ / Future AMD Ryzen™ Processors(3000 and 4000 Series Processors)
6 Phase Power Design
Supports DDR4 4733+ (OC)
1 x PCIe 3.0 x16, 1 x PCIe 3.0 x1
Graphics Output Options: D-Sub, HDMI
7.1 CH HD Audio (Realtek ALC887 Audio Codec)
4 x SATA3, 1 x Ultra M.2(Gen3 x4 & SATA3)
6 x USB 3.2 Gen1(4 x Rear, 2 x Front)
6 x USB 2.0(2 x Rear, 4 x Front)
Realtek Gigabit LAN

Üldine informatsioon

Kaubamärk ASROCK

Tootekood A520M-HVS

Tarneaeg 2-5 tööpäeva. 100 Tooted

Lisainfo

Müüja koduleht: https://www.asrock.com/mb/AMD/A520M-HVS/index.asp Overview
Garantija: 36
Category Code: MBA
Unit Box Height: 0.51
Unit Box Length: 0.61
Unit Box Width: 0.0145
Units per Shipping Box: 20
Unit Calculated Volume: 0.00465 cubm
Unit Calculated Weight: 0.85 kg
Summary: Asrock A520M-HVS. Processor manufacturer: AMD, Processor socket: Socket AM4, Compatible processor series: AMD Ryzen 3000 Series. Supported memory types: DDR4-SDRAM, Maximum internal memory: 64 GB, Memory slots type: DIMM. Supported storage drive interface
Weight & dimensions (Width): 230 mm
Weight & dimensions (Depth): 201 mm
Packaging content (Cables included): SATA
Logistics data (Harmonized System (HS) code): 84733020
Network (Ethernet LAN): Yes
Network (Wi-Fi): No
Packaging content (Drivers included): Yes
Processor (Processor manufacturer): AMD
Graphics (Graphics card family): AMD
Features (Component for): PC
Graphics (Graphics card): Radeon Vega
Memory (Maximum internal memory): 64 GB
Memory (Memory channels): Dual-channel
Network (LAN controller): Realtek RTL8111H
Processor (Compatible processor series): AMD Ryzen 3000 Series
Processor (Processor socket): Socket AM4
Memory (Memory slots type): DIMM
Memory (Number of memory slots): 2
Memory (Supported memory clock speeds): 2133/2400/2666/2933/3200/3466/3600/3733/3800/3866/4000/4133/4200/4266/4333/4400/4466/4500/4533 MHz
Memory (Supported memory types): DDR4-SDRAM
Memory (Unbuffered memory): Yes
Storage controllers (Number of HDDs supported): 5
Storage controllers (Supported storage drive interfaces): M.2,SATA III
Internal I/O (ATX Power connector (24-pin)): Yes
Internal I/O (CPU fan connector): Yes
Internal I/O (Front panel audio connector): Yes
Internal I/O (Number of chassis fan connectors): 2
Internal I/O (Number of COM connectors): 1
Internal I/O (USB 2.0 connectors): 2
Internal I/O (USB 3.2 Gen 1 (3.1 Gen 1) connectors): 1
Rear panel I/O ports (Ethernet LAN (RJ-45) ports): 1
Rear panel I/O ports (HDMI ports quantity): 1
Rear panel I/O ports (Microphone in): Yes
Rear panel I/O ports (PS/2 ports quantity): 1
Rear panel I/O ports (USB 2.0 ports quantity): 2
Network (Ethernet interface type): Gigabit Ethernet
Features (Audio output channels): 7.1 channels
Features (Motherboard chipset): AMD A520
Features (Motherboard chipset family): AMD
Features (Motherboard form factor): micro ATX
BIOS (BIOS type): UEFI AMI
Rear panel I/O ports (USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity): 4
Memory (ECC сompatibility): Non-ECC
Expansion slots (PCI Express x16 (Gen 3.x) slots): 1
Rear panel I/O ports (VGA (D-Sub) ports quantity): 1
Expansion slots (PCI Express x1 (Gen 3.x) slots): 1
Network (Wake-on-LAN ready): Yes

Eriviited

ean13: 4710483932311
MPN: 1309552
