4710483932267Mainboard|ASROCK|AMD A520|SAM4|Micro-ATX|Memory DDR4|Memory slots 2|1xPCI-Express 3.0 1x|1xPCI-Express 3.0 16x|1xM.2|1x15pin D-s
  • 4710483932267Mainboard|ASROCK|AMD A520|SAM4|Micro-ATX|Memory DDR4|Memory slots 2|1xPCI-Express 3.0 1x|1xPCI-Express 3.0 16x|1xM.2|1x15pin D-s

Mainboard|ASROCK|AMD A520|SAM4|Micro-ATX|Memory DDR4|Memory slots 2|1xPCI-Express 3.0 1x|1xPCI-Express 3.0 16x|1xM.2|1x15pin D-s

A520M-HDV
ASROCK
micro ATX | Audio 7.1 channels | CPU AMD | Socket Socket AM4 | Series AMD Ryzen 3000 Series | Supported memory types DDR4-SDRAM | 2xNumber of memory slots | Memory slots type DIMM | Supported storage drive interfaces M.2,SATA III | Graphics card Radeon Vega | 2xUSB 2.0 ports quantity | 4xUSB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1xEthernet LAN (RJ-45) ports | 1xVGA (D-Sub) ports quantity | 1xHDMI ports quantity
55,71 €
KM-ga
Tarneaeg 1-5 tööpäeva.
Kogus
Laos
30 Tooted

Kirjeldus

A520 MOTHERBOARD FOR EVERYONE
All Essentials You Need For Computing

Ultra M.2 32Gb/s (PCIe Gen3 x4 & SATA3)
The PCIe Gen3 x4 Ultra M.2 interface pushes data transfer speeds up to 32Gb/s. In addition, it also supports SATA3 6Gb/s M.2 modules.

HDMI 4k @60Hz
Supports the most recent HDMI 4K 60Hz graphics output specification. With the larger bandwidth and increased frame rate, the motion on your screen becomes more fluid and less blurry.

3 Graphics Outputs
Complete with all three types of most used connectors! Packed with a D-Sub + DVI-D + HDMI combo. Plus the HDMI port supports 4K resolution.
*Supported only with processors with integrated graphics. Please check CPU support list from each motherboard webpage.

Premium 50A Power Choke
Compared to traditional chokes, ASRock’s premium 50A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the motherboard.

High Density Glass Fabric PCB
High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the motherboard against electrical shorts caused by humidity.

Sapphire Black PCB
Pure black PCB appearance. The new Sapphire Black PCB represents rock-solid quality and gives the motherboard a more mysterious touch.

Full Spike Protection
Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection includes various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes.

Live Update & APP Shop
ASRock Live Update & APP Shop is designed for your convenience. We provide various apps and support software for users to download. You can also easily optimize your system and keep your motherboard up to date with ASRock Live Update & APP Shop.

Üldine informatsioon
ASROCK
A520M-HDV
30 Tooted

Lisainfo

Müüja koduleht
https://www.asrock.com/MB/AMD/A520M-HDV/index.asp
Garantija
36
Category Code
MBA
Unit Box Height
0.51
Unit Box Length
0.61
Unit Box Width
0.0145
Units per Shipping Box
20
Unit Calculated Volume
0.00465 cubm
Unit Calculated Weight
0.86 kg
Summary
Asrock A520M-HDV. Processor manufacturer: AMD, Processor socket: Socket AM4, Compatible processor series: AMD Ryzen 3000 Series. Supported memory types: DDR4-SDRAM, Maximum internal memory: 64 GB, Memory slots type: DIMM. Supported storage drive interface
Weight & dimensions (Width)
230 mm
Weight & dimensions (Depth)
201 mm
Logistics data (Harmonized System (HS) code)
84733020
Network (Ethernet LAN)
Yes
Network (Wi-Fi)
No
Processor (Processor manufacturer)
AMD
Graphics (Graphics card family)
AMD
Features (Component for)
PC
Graphics (Graphics card)
Radeon Vega
Memory (Maximum internal memory)
64 GB
Memory (Memory channels)
Dual-channel
Network (LAN controller)
Realtek RTL8111H
Processor (Compatible processor series)
AMD Ryzen 3000 Series
Processor (Processor socket)
Socket AM4
Memory (Memory slots type)
DIMM
Memory (Number of memory slots)
2
Memory (Supported memory clock speeds)
2133/2400/2666/2933/3200/3466/3600/3733/3800/3866/4000/4133/4200/4266/4333/4400/4466/4500/4533 MHz
Memory (Supported memory types)
DDR4-SDRAM
Memory (Unbuffered memory)
Yes
Storage controllers (Number of HDDs supported)
5
Storage controllers (Supported storage drive interfaces)
M.2,SATA III
Internal I/O (ATX Power connector (24-pin))
Yes
Internal I/O (CPU fan connector)
Yes
Internal I/O (Front panel audio connector)
Yes
Internal I/O (Number of chassis fan connectors)
2
Internal I/O (Number of COM connectors)
1
Internal I/O (USB 2.0 connectors)
2
Internal I/O (USB 3.2 Gen 1 (3.1 Gen 1) connectors)
1
Rear panel I/O ports (Ethernet LAN (RJ-45) ports)
1
Rear panel I/O ports (HDMI ports quantity)
1
Rear panel I/O ports (Microphone in)
Yes
Rear panel I/O ports (PS/2 ports quantity)
1
Rear panel I/O ports (USB 2.0 ports quantity)
2
Network (Ethernet interface type)
Gigabit Ethernet
Features (Audio output channels)
7.1 channels
Features (Motherboard chipset family)
AMD
Features (Motherboard form factor)
micro ATX
BIOS (BIOS type)
UEFI AMI
Rear panel I/O ports (USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity)
4
Memory (ECC сompatibility)
Non-ECC
Expansion slots (PCI Express x16 (Gen 3.x) slots)
1
Rear panel I/O ports (VGA (D-Sub) ports quantity)
1
Expansion slots (PCI Express x1 (Gen 3.x) slots)
1
Network (Wake-on-LAN ready)
Yes

Eriviited

ean13
4710483932267
MPN
1309243
