8 Channels - Audio from cameras Bi-directional audio streaming support
Audio inputs:
1 pcs CINCH
Audio outputs:
1 pcs CINCH
Image compression method:
Smart H.265+ / H.265 / Smart H.264+ / H.264
Bitrate:
max. 160 Mbps (without AI) max. 80 Mbps (AI)
Supported hard drives:
1 x 20 TB SATA
Recording modes:
Manual, Motion Detection, Schedule
External storage devices backup:
Backup to USB drive (pendrive, external drive)
Searching and playback the records:
Records searching: by time and events type. Records playback: forward, backward, fast, slow Advanced searching (to the one second accuracy) Smart Playback function Records playback from max. 8 channels in the same time
Network interface:
1 x RJ-45 10/100/1000 Base-TX
Network functions:
Full support via network, Remote records copying, Web Server built-in
Network protocols:
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, Alarm Server, P2P, Auto Register, IP Search
ONVIF:
22.12
Default IP address:
192.168.1.108
Default admin user / password:
admin / admin The administrator password should be set at the first start
Mobile phones support:
Port no.: 37777 or access by a cloud (P2P) Android: Free application DMSS iOS (iPhone): Free application DMSS
See how to configure the P2P function in Dahua recorders and how to enable the mobile application
Web browser access ports:
80, 37777
PC client access ports:
37777
Mobile client access ports:
37777
RTSP URL:
rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main stream rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Sub stream
USB:
2 pcs USB 2.0
Serial ports:
Alarm inputs / outputs:
PTZ control:
IP Speed Dome Cameras
Motion Detection:
Intelligent Image Analysis:
Main features:
SMD PLUS - searching for an object classified as: human, motor vehicle Filtering of false alarms based on the recognition of persons and vehicles Privacy zones
Functions implemented in cooperation between the recorder and cameras that support these functions :
Intelligent Image Analysis : perimeter protection, scene changingface detection - supports 6 types of facial attributes extraction Face recognition people countingheat map
NVR equipped with advanced functions of intelligent image analysisThe recorder supports AcuSense technology, allowing to filter false alarms based on the recognition of people and vehicles
