CPU INTEL Desktop Core i7 i7-14700K Raptor Lake 3400 MHz Cores 20 33MB Socket LGA1700 125 Watts GPU UHD 770 BOX BX8071514700KSRN

Дополнительная информация

Сайт продавца

https://ark.intel.com/content/www/us/en/ark/products/236783.html

Номер модели

i7-14700K

Фамилия CPU

Intel Core i7

Гарантия

24

Код категории

CPU

Высота блока

0.103

Длина блока

0.045

Ширина блока

0.118

Units per Shipping Box

5

Unit Calculated Volume

0.000738 cubm

Unit Calculated Weight

0.112 kg

Summary

Intel Core i7-14700K. Processor family: Intel Core i7, Processor socket: LGA 1700, Package type: Box. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. On-bo

Logistics data (Harmonized System (HS) code)

8542310001

Memory (Memory bandwidth (max))

89.6 GB/s

Processor (Processor family)

Intel Core i7

Processor (Processor manufacturer)

Intel

Processor (Processor model)

i7-14700K

Processor (Processor cores)

20

Processor (Processor boost frequency)

5.6 GHz

Processor (Maximum turbo power)

253 W

Processor (Performance cores)

8

Processor (Performance-core base frequency)

3.4 GHz

Processor (Processor base power)

125 W

Processor (Processor cache)

33 MB

Processor (Processor cache type)

Smart Cache

Processor (Processor generation)

Intel Core i7 (14th gen)

Processor (Processor threads)

28

Memory (Memory channels)

Dual-channel

Graphics (Discrete graphics card)

No

Graphics (Discrete graphics card model)

Not available

Graphics (On-board graphics card)

Yes

Graphics (On-board graphics card model)

Intel UHD Graphics 770

Processor (Efficient cores)

12

Processor (Efficient-core base frequency)

2.5 GHz

Memory (Non-ECC)

Yes

Processor (Processor socket)

LGA 1700

Processor (Efficient-core boost frequency)

4.3 GHz

Processor (Performance-core boost frequency)

5.5 GHz

Features (Use conditions)

PC/Client/Tablet/Workstation

Features (Market segment)

Desktop

Memory (ECC)

Yes

Graphics (Number of execution units)

32

Graphics (On-board graphics card DirectX version)

12.0

Graphics (On-board graphics card OpenGL version)

4.5

Processor special features (Intel Virtualization Technology (VT-x))

Yes

Processor special features (Intel Virtualization Technology for Directed I/O (VT-d))

Yes

Processor special features (Intel VT-x with Extended Page Tables (EPT))

Yes

Processor special features (Intel Turbo Boost Technology)

2.0

Processor (Processor operating modes)

64-bit

Memory (Memory types supported by processor)

DDR4-SDRAM/DDR5-SDRAM

Memory (Maximum internal memory supported by processor)

192 GB

Features (Maximum number of PCI Express lanes)

20

Features (PCI Express slots version)

4.0/5.0

Features (Supported instruction sets)

AVX 2.0/SSE4.1/SSE4.2

Processor (Cooler included)

No

Processor (Package type)

Box

Processor special features (Intel Hyper Threading Technology (Intel HT Technology))

Yes

Graphics (On-board graphics card base frequency)

300 MHz

Processor (Processor codename)

Raptor Lake

Processor (Maximum number of DMI lanes)

8

Processor (Processor ARK ID)

236783

Processor (Stepping)

B0

Graphics (Number of displays supported (on-board graphics))

4

Graphics (On-board graphics card dynamic frequency (max))

1600 MHz

Graphics (On-board graphics card ID)

0xA780

Graphics (On-board graphics card outputs supported)

DisplayPort 1.4a/Embedded DisplayPort (eDP) 1.4b/HDMI 2.1

Graphics (On-board graphics card refresh rate at maximum resolution (DisplayPort))

60 Hz

Graphics (On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel))

120 Hz

Graphics (On-board graphics card refresh rate at maximum resolution (HDMI))

60 Hz

Features (Commodity Classification Automated Tracking System (CCATS))

740.17B1

Features (Direct Media Interface (DMI) Revision)

4.0

Features (Embedded options available)

No

Features (Execute Disable Bit)

Yes

Features (Export Control Classification Number (ECCN))

5A992C

Features (Idle States)

Yes

Features (Scalability)

1S

Features (Thermal Monitoring Technologies)

Yes

Features (Thermal solution specification)

PCG 2020A

Processor special features (Enhanced Intel SpeedStep Technology)

Yes

Processor special features (Intel 64)

Yes

Processor special features (Intel Turbo Boost Max Technology 3.0)

Yes

Processor special features (Intel AES New Instructions (Intel AES-NI))

Yes

Processor special features (Intel Boot Guard)

Yes

Processor special features (Intel Control-flow Enforcement Technology (CET))

Yes

Processor special features (Intel Deep Learning Boost (Intel DL Boost) on CPU)

Yes

Processor special features (Intel OS Guard)

Yes

Processor special features (Intel Quick Sync Video Technology)

Yes

Processor special features (Intel Secure Key)

Yes

Processor special features (Intel Speed Shift Technology)

Yes

Processor special features (Intel Standard Manageability (ISM))

Yes

Processor special features (Intel Thread Director)

Yes

Processor special features (Intel Turbo Boost Max Technology 3.0 frequency)

5.6 GHz

Processor special features (Intel Volume Management Device (VMD))

Yes

Processor special features (Mode-based Execute Control (MBE))

Yes

Technical details (Launch date)

Q4'23

Technical details (OpenCL version)

3.0

Technical details (Status)

Launched

Other features (Graphics output)

eDP 1.4b, DP 1.4a, HDMI 2.1

Other features (L2 cache)

28672 KB

Other features (Maximum internal memory)

192 GB

Processor (Memory bandwidth supported by processor (max))

89.6 GB/s

Graphics (Multi-Format Codec Engines)

2

Graphics (On-board graphics card maximum resolution (DisplayPort))

7680 x 4320 pixels

Graphics (On-board graphics card maximum resolution (eDP - Integrated Flat Panel))

5120 x 3200 pixels

Graphics (On-board graphics card maximum resolution (HDMI))

4096 x 2160 pixels

Features (CPU configuration (max))

1

Features (PCI Express configurations)

1x16+1x4/2x8+1x4

Processor special features (Intel Clear Video HD Technology (Intel CVT HD))

Yes

Processor special features (Intel Gaussian & Neural Accelerator (Intel GNA) 3.0)

Yes

Operational conditions (Tjunction)

100 C

Weight & dimensions (Processor package size)

45 x 37.5 mm

Специальные референции

ean13

5032037278492

MPN

1428194
