Launched by Dahua Technology, Dahua WizMind is a full portfolio of solutions composed of project-oriented products including IPC, NVR, PTZ, XVR, Thermal and software platform which adopts industry-leading deep learning algorithms. Focusing on customer’s requirements, WizMind provides precise, reliable and comprehensive AI solutions for verticals.
Series Overview With starlight solution and deep learning algorithm, Dahua WizMind 5 Series network camera has various intelligent functions, including face capture, perimeter protection and people counting, which greatly im-prove the accuracy of video analysis. The series camera supports dust-proof function, waterproof function and vandal-proof function, com-plying with the standards of IP67 and IK10 (Supported by some select models).
Face Attributes With deep learning algorithm, the network camera can recognize face attributes, such as gender, age, expression, glasses, mouth mask, and beard.
Face Detection Dahua Face Detection technology can detect the face in the image. With deep learning algorithm, the technology supports detecting, tracking, capturing and selecting the best face image, and then outputs face snapshot
Perimeter Protection With deep learning algorithm, Dahua Perimeter Protection technology can recognize human and vehicle accurately. In restricted area (such as pedestrian area and vehicle area), the false alarms of intelligent detection based on target type (such as tripwire, intrusion, fast moving, parking detection, loitering detection and gathering detection) are largely reduced.
People Counting With deep learning algorithm, Dahua People Counting technology can track and process moving human body targets to realize the accurate statistics of enter No., leave No., and In Area No. Working with management platform, it outputs yearly/monthly/weekly/daily reports to meet your requirements
ePoE Dahua ePoE technology provides a new way to accomplish long distance transmission between IP camera and network switch. It allows more flexible surveillance system design, improves reliability and saves construction and wiring cost.
Protection (IP67, wide voltage) IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% (for some power supplies) input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage
4MP, 1/1.8" CMOS image sensor, low illuminance, high image definition
ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Intelligent detection: Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human), abandoned object, missing object, loitering detection, people gathering, parking detection, heat map, face detection, face attributes and people counting
Supports max. 256 G Micro SD card, built-in Mic
12V DC/PoE power supply, ePoE network transmission over long distance, easy for installation
Dome | Ceiling/wall | Black/White | IP code IP67 | IP security camera | Wired | Placement Outdoor | Pan range 0 - 355 ° | White balance Auto/Manual/Natural/Outdoor/Regional custom/Street lamp | Camera shutter type Electronic | Optical sensor size 1/2.7 " | Sensor type CMOS | 1xNumber of lenses | Night vision Yes | Night vision distance 40 m | Total...
Eyeball | Black | IP code IP67 | IP security camera | Wired | Wide Dynamic Range (WDR) Yes | Optical sensor size 1/1.8 " | Sensor type CMOS | Night vision Yes | Total megapixels 8 MP | Built-in microphone Yes | Power source type DC,PoE | Weight 800 g
Dome | Wall/Pole | White | IP code IP66 | Weatherproof Yes | IP security camera | Wired | Placement Indoor & outdoor | PTZ control Yes | Optical sensor size 2/7 " | Sensor type CMOS | Night vision Yes | Night vision distance 20 m | Total megapixels 4 MP | Built-in microphone Yes | Ethernet LAN Yes | Power source type DC,PoE | Weight 580 g | 1xNumber...
