Switch|TP-LINK|SX3032F|32xSFP+|1xConsole|1xRJ45|SX3032F

Reference SX3032F

Brand TP-LINK

€908.38

VAT included

Quantity

Laos

In stock: 2 Items

Description
Product Details

Description

Omada 32-Port 10GE SFP+ L2+ Managed Switch

Easily Build a Whole 10G Multi-gigabit Network

Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.

32× 10 Gbps SFP+ slots
640 Gbps switching capacity
Two internal fixed power supply modules back each other up
Centralized cloud management via the web or the Omada app†
Standalone management via web, CLI, SNMP, and RMON
Static Routing helps route internal traffic for higher efficiency
VLAN, ACL, QoS, IGMP Snooping, OAM, and DDM
ERPS supports rapid protection and recovery in a ring topology
Durable metal casing and rack-mountable design

Product Details

Brand TP-LINK

Reference SX3032F

In stock 2 Items

Data sheet

Vendor Homepage: https://www.tp-link.com/au/business-networking/omada-switch-easy-managed/es205g/
Garantija: 60
Series: SX3032F
Model: Omada
Category Code: SWI
Unit Box Height: 0.1
Unit Box Length: 0.47
Unit Box Width: 0.53
Units per Shipping Box: 3
Unit Calculated Volume: 0.030576 cubm
Unit Calculated Weight: 6.65 kg
Summary: TP-Link Omada 32-Port 10GE SFP+ L2+ Managed Switch. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports quantity: 1, Installed SFP+ modules quantity: 32, Console port: RJ-45/Micro-USB. MAC address table: 32000 entries, Switching
Weight & dimensions (Width): 440 mm
Weight & dimensions (Depth): 330 mm
Weight & dimensions (Height): 44 mm
Packaging content (Quick start guide): Yes
Packaging content (Cables included): Power
Power (Power source): AC
Certificates (Compliance certificates): CE/Federal Communications Commission (FCC)/RoHS
Operational conditions (Operating temperature (T-T)): -5 - 45 C
Operational conditions (Storage relative humidity (H-H)): 5 - 90 %
Operational conditions (Storage temperature (T-T)): 40 - 70 C
Design (Product colour): Black
Power (AC input frequency): 50/60 Hz
Power (AC input voltage): 100 - 240 V
Power (Power consumption (max)): 49.4 W
Design (Number of fans): 2 fan(s)
Operational conditions (Operating relative humidity (H-H)): 10 - 90 %
Security (Password protection): Yes
Network (Networking standards): IEEE 802.1ab/IEEE 802.1p/IEEE 802.1Q/IEEE 802.1x/IEEE 802.3ah/IEEE 802.3x
Management features (Cloud-managed): Yes
Management features (Switch layer): L2+
Management features (Switch type): Managed
Ports & interfaces (Basic switching RJ-45 Ethernet ports quantity): 1
Data transmission (Forwarding rate): 240 Mpps
Data transmission (Switching capacity): 640 Gbit/s
Design (Rack mounting): Yes
Power (Power supply included): Yes
Network (Broadcast storm control): Yes
Network (Flow control support): Yes
Network (Link aggregation): Yes
Network (Port mirroring): Yes
Network (Spanning tree protocol): Yes
Network (VLAN support): Yes
Security (Authentication type): AAA,TACACS+
Data transmission (Static route): Yes
Security (DHCP features): DHCP relay/DHCP server/DHCPv6 snooping
Data transmission (MAC address table): 32000 entries
Data transmission (Packet buffer memory): 24 MB
Ports & interfaces (Console port): RJ-45/micro-USB
Data transmission (Jumbo frames): 9
Data transmission (Jumbo frames support): Yes
Management features (Quality of Service (QoS) support): Yes
Network (Number of VLANs): 30
Network (Virtual LAN features): Protocol-based VLAN/SSID-based VLAN assignment/Tagged VLAN/VLAN mapping/Voice VLAN
Security (Loop protection): Yes
Network (Rate limiting): Yes
Security (IGMP snooping): Yes
Management features (ARP inspection): Yes
Management features (Configuring Location Settings (CLI)): Yes
Management features (MIB support): MIB II (RFC1213) Interface MIB (RFC2233) Ethernet Interface MIB (RFC1643) Bridge MIB (RFC1493) P/Q-Bridge MIB (RFC2674) RMON MIB (RFC2819) RMON2 MIB (RFC2021) Radius Accounting Client MIB (RFC2620) Radius Authentication Client MIB (RFC26
Data transmission (Number of queues): 8
Security (Access Control List (ACL)): Yes
Security (Authentication): MAC-based authentication,Port-based authentication
Security (IP-MAC-Port binding): Yes
Security (Queue scheduling algorithms): Priority queuing (PQ)/SP/Weighted Round Robin (WRR)
Security (SSH/SSL support): Yes
Security (Static port security): Yes
Multicast features (Multicast Listener Discovery (MLD) snooping): Yes
Multicast features (Multicast support): Yes
Protocols (IPv4 & IPv6 features): Dual stack IPv4/IPv6/ICMPv6/IPv6 TFTP
Network (IPv4 routes): 48
Network (IPv6 routes): 48
Data transmission (Number of static routes): 128
Protocols (GARP VLAN Registration Protocol (GVRP)): Yes
Data transmission (Number of IP interfaces): 128
Ports & interfaces (Installed SFP+ modules quantity): 32
Design (Redundant fans support): Yes
Multicast features (Number of multicast groups filtered): 4000
Protocols (IP Source Guard (IPSG)): Yes
