5903018666167Power Supply|ENDORFY|EY7A007|650 Watts|Efficiency 80 PLUS GOLD|MTBF 100000 hours|EY7A007
  • 5903018666167Power Supply|ENDORFY|EY7A007|650 Watts|Efficiency 80 PLUS GOLD|MTBF 100000 hours|EY7A007

Power Supply|ENDORFY|EY7A007|650 Watts|Efficiency 80 PLUS GOLD|MTBF 100000 hours|EY7A007

EY7A007
ENDORFY
650 W | 115 - 230 V | 80 PLUS certification 80 PLUS Gold | PC | ATX | Fan diameter 120 mm | EY7A007
€96.56
VAT included
Quantity
Laos
5 Items

Description

The Supremo FM5 Gold 650W is an efficient power supply with a 120 mm Fluctus fan that ensures your PC runs stably without unexpected resets interruptions. This bad boy is equipped with Japanese electrolytic and aluminum-polymer capacitors so you can squeeze the last juices out of it without a hitch. No wonder it is 80 PLUS® Gold certified ;)

Supremo FM5 Gold 650W

When you've spent half your life by the computer, you know that stable component operation = trouble-free boss battles (including those in the office). And that's why we created the Supremo FM5 Gold 650W.

It's an efficient and relatively small (14 cm long) power supply with DC-DC topology dedicated to special tasks demanding components. We're serious – we've packed in everything we think you need to fine-tune the voltage and deliver continuous 650W of power without unexpected resets or a blue screen. We also fit a 12 cm 120 mm Fluctus fan, which will stay cool (literally!) and take care of the right temperature inside the PSU. No wonder our Supremo got the 80 PLUS® Gold certification :)

Product Details
ENDORFY
EY7A007
5 Items

Data sheet

Vendor Homepage
https://endorfy.com/en/product/supremo-fm5-gold-650w/
Model name
EY7A007
Garantija
24
Category Code
PSU
Unit Box Height
0.22
Unit Box Length
0.1
Unit Box Width
0.27
Units per Shipping Box
1
Unit Calculated Volume
0.00594 cubm
Unit Calculated Weight
2.42 kg
CnCode
85044095
Summary
ENDORFY Supremo FM5. Total power: 650 W, AC input voltage: 115 - 230 V, AC input frequency: 50/60 Hz. Motherboard power connector: 18+10 pin ATX, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80
Weight & dimensions (Width)
140 mm
Weight & dimensions (Depth)
150 mm
Weight & dimensions (Height)
87 mm
Packaging content (Cables included)
AC
Design (Product colour)
Black
Power (AC input frequency)
50/60 Hz
Power (AC input voltage)
115 - 230 V
Design (Number of fans)
1 fan(s)
Design (Fan diameter)
120 mm
Design (On/off switch)
Yes
Power (Combined power (+12V))
648 W
Power (Combined power (+3.3V))
100 W
Power (Combined power (+5V))
100 W
Power (Combined power (+5Vsb))
15 W
Power (Combined power (-12V))
3.6 W
Power (Max output current (+12V))
54 A
Power (Max output current (+3.3V))
20 A
Power (Max output current (+5V))
20 A
Power (Max output current (+5Vsb))
3 A
Power (Max output current (-12V))
0.3 A
Power (Power protection features)
Over current/Over power/Over voltage/Short circuit/Under voltage
Power (Total power)
650 W
Ports & interfaces (Cabling type)
Fully-Modular
Ports & interfaces (Motherboard power connector)
18+10 pin ATX
Ports & interfaces (Number of SATA power connectors)
3
Ports & interfaces (PCI Express power connectors (8-pin))
6
Performance (80 PLUS certification)
80 PLUS Gold
Performance (Mean time between failures (MTBF))
100000 h
Performance (Power supply unit (PSU) form factor)
ATX
Performance (Purpose)
PC
Performance (Supported motherboard form factors)
ATX

Specific References

EAN13
5903018666167
MPN
1439919
