0753263078674Case CHIEFTEC Pro mini MidiTower MicroATX MiniITX Colour Black AZ-01B-OP
  • 0753263078674Case CHIEFTEC Pro mini MidiTower MicroATX MiniITX Colour Black AZ-01B-OP

Case CHIEFTEC Pro mini MidiTower MicroATX MiniITX Colour Black AZ-01B-OP

AZ-01B-OP
CHIEFTEC
Pro mini, PC, Mini Tower, Black, Supported mainboards micro ATX/Mini-ITX/uATX, 4xNumber of expansion slots, Anti-dust filter Yes, Supported HDD sizes 2.5/3.5 ", Weight 5.15 kg
€39.38
VAT included
Monthly payment from 6.69€
Quantity
Laos
100 Items

Description

The CHIEFTEC Pro Mini presents a modern m-ATX mini tower PC case with a timelessly elegant, brushed front panel, complemented by an interior designed with a modern layout for optimal hardware and cooling compatibility. The CHIEFTEC Pro Mini features added sound-absorbing material on the side and front panels to provide an optimized noise level, while a total of 8 possible fan mounts provides flexible cooling configurations. The Pro Mini is ready to deliver customers an ideal combination of performance, noise and quality design.

  • Elegant & modern design
  • Sound-absorbing material
  • 1x 120mm PWM fan pre-installed
Product Details
CHIEFTEC
AZ-01B-OP
100 Items

Data sheet

Vendor Homepage
https://www.chieftec.eu/products-detail/587/AZ-01B-OP
Model name
Pro mini
Garantija
24
Model
AZ-01B-OP
Category Code
CAS
Unit Box Height
0.48
Unit Box Length
0.48
Unit Box Width
0.275
Units per Shipping Box
1
Unit Calculated Volume
0.06336 cubm
Unit Calculated Weight
5.9 kg
Summary
Chieftec AZ-01B-OP. Form factor: Mini Tower, Type: PC, Product colour: Black. Front fans diameters supported: 120,140 mm, Rear fans installed: 1x 120 mm, Rear fans diameters supported: 120 mm. Supported HDD sizes: 2.5,3.5". Width: 212 mm, Depth: 360 mm, H
Weight & dimensions (Width)
212 mm
Weight & dimensions (Depth)
360 mm
Weight & dimensions (Height)
420 mm
Weight & dimensions (Weight)
5150 g
Packaging data (Package weight)
6000 g
Ports & interfaces (USB 2.0 ports quantity)
1
Design (Product colour)
Black
Ports & interfaces (Audio input)
Yes
Ports & interfaces (USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity)
1
Ports & interfaces (Audio output)
Yes
Design (Form factor)
Mini Tower
Design (Illumination)
No
Design (Type)
PC
Ports & interfaces (USB Type-C ports quantity)
1
Design (Anti-dust filter)
Yes
Design (Maximum CPU cooler height)
165 mm
Design (Maximum graphics card length)
330 mm
Design (Maximum PSU length)
180 mm
Design (Number of 2.5" bays)
2
Design (Number of 3.5" bays)
1
Design (Number of expansion slots)
4
Design (On/off button)
Yes
Design (Reset button)
Yes
Design (Side window)
No
Design (Supported motherboard form factors)
micro ATX/Mini-ITX/uATX
Power supply (Power supply included)
No
Cooling (Liquid cooling capability)
Yes
Cooling (Number of rear fans supported (max))
1
Cooling (Number of top fans supported (max))
2
Cooling (Rear fans diameters supported)
120 mm
Cooling (Rear fans installed)
1x 120 mm
Cooling (Top fans diameters supported)
120/140 mm
Storage (Supported HDD sizes)
2.5/3.5 "
Ports & interfaces (USB 3.0)
1
Cooling (Top radiator sizes supported)
240/280 mm
Cooling (Front fans diameters supported)
120/140 mm
Design (Tempered glass panel(s))
No
Cooling (Front radiator sizes supported)
240/280/360 mm
Cooling (Number of front fans supported (max))
3
Design (Number of internal 3.5" bays)
1
Design (Number of storage drives supported)
3
Weight & dimensions (Material thickness)
0.6 mm
Design (Full-Height expansion slots)
4

Specific References

EAN13
0753263078674
MPN
1433946
