LCD Monitor DAHUA LM22-A200Y 21.45" Panel VA 1920x1080 16:9 100Hz 10 ms DHI-LM22-A200Y

Data sheet

Vendor Homepage

https://www.dahuasecurity.com/search/products?keyword DHI-LM22-A200Y

Model name

LM22-A200Y

Garantija

36

Model

DHI-LM22-A200Y

Category Code

LC3

Unit Box Height

0.37

Unit Box Length

0.6

Unit Box Width

0.1

Unit Calculated Volume

0.0222 cubm

Product Net Weight

2.05 kg

Unit Calculated Weight

3.06 kg

Energy Efficiency (Energy efficiency class)

E

Energy Efficiency (EPREL Registration Number)

2139333

Energy Efficiency (EPREL Version Number)

1

Energy Efficiency (Data Sheet (Link))

https://eprel.ec.europa.eu/api/product/2139333/fiches?language EN

Summary

Dahua Technology LM22-A200Y. Display diagonal: 54.5 cm (21.4"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 10 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178 , Viewing angle, vertical: 1

Packaging data (Package width)

598 mm

Packaging data (Package depth)

99 mm

Packaging data (Package height)

366 mm

Packaging data (Package weight)

2860 g

Packaging data (Package type)

Box

Operational conditions (Operating temperature (T-T))

0 - 40 C

Operational conditions (Storage relative humidity (H-H))

5 - 90 %

Operational conditions (Storage temperature (T-T))

-20 - 60 C

Ports & interfaces (Headphone out)

No

Display (Display diagonal)

21.45 "

Display (Display diagonal (metric))

56 cm

Display (Display resolution)

1920 x 1080 pixels

Display (Display technology)

LED

Display (HD type)

Full HD

Display (Native aspect ratio)

16:9

Display (Screen shape)

Flat

Ports & interfaces (HDMI ports quantity)

1

Design (Product colour)

Black

Power (Energy consumption (SDR) per 1000 hours)

15 kWh

Power (Energy efficiency class (HDR))

Not available

Power (Energy efficiency class (SDR))

E

Power (Energy efficiency scale)

A to G

Power (Power consumption (max))

16 W

Power (Power consumption (standby))

0.1 W

Power (Power consumption (typical))

16 W

Weight & dimensions (Depth (without stand))

41.2 mm

Weight & dimensions (Height (without stand))

284 mm

Weight & dimensions (Weight (without stand))

2050 g

Weight & dimensions (Width (without stand))

492.7 mm

Display (LED backlight)

Yes

Design (Frameless design)

Yes

Display (Colour gamut standard)

NTSC

Display (Contrast ratio (typical))

3000:1

Display (Display brightness (typical))

250 cd/m

Display (Maximum refresh rate)

100 Hz

Display (Panel type)

VA

Display (Response time)

10 ms

Display (Touchscreen)

No

Display (Viewing angle, horizontal)

178

Display (Viewing angle, vertical)

178

Multimedia (Built-in camera)

No

Multimedia (Built-in speaker(s))

No

Design (Feet colour)

Black

Ports & interfaces (Built-in USB hub)

No

Ports & interfaces (HDMI)

Yes

Ports & interfaces (HDMI version)

1.4

Ergonomics (Height adjustment)

No

Ergonomics (Panel mounting interface)

75 x 75 mm

Ergonomics (Tilt adjustment)

Yes

Ergonomics (Tilt angle range)

-5 - 15

Ergonomics (VESA mounting)

Yes

Ergonomics (Wall mountable)

Yes

Power (Power consumption (off))

0.1 W

Design (Detachable stand)

Yes

Power (Power supply type)

External

Packaging content (Power adapter included)

Yes

Packaging content (Stand included)

Yes

Ports & interfaces (VGA (D-Sub) ports quantity)

1

Display (Backlight type)

Edge LED

Display (Colour depth)

8 bit

Display (NTSC coverage (typical))

72 %

Design (Front bezel colour)

Black

Ergonomics (Plug and Play)

Yes

Power (AC adapter output voltage)

12 V

Power (Current rating)

2 A

Operational conditions (Operating relative humidity (H-H))

10 - 90 %

Weight & dimensions (Bezel width (bottom))

15.2 mm

Weight & dimensions (Bezel width (side))

3.3 mm

Weight & dimensions (Bezel width (top))

3.3 mm

Other features (Compliance certificates)

CE/Electromagnetic Compatibility (EMC)/Low Voltage Directive (LVD)

Other features (Mean time between failures (MTBF))

30000 h

Specific References

EAN13

6939554907173

MPN

1443730
