Description
8+4MP 25x TiOC Network Panoramic PTZ Camera
Overview channel: Outputs 180° wide angle splicing image Detail channel: 1/2.8"4Megapixel STARVIS™ CMOS 25x optical zoom Max. 25/30 fps@8M IR distance up to 100 m Auto tracking 3.0 Smart tracking Perimeter protection Active deterrence Smart dual light +
Product Details
Reference
SDT4E425-8P-GB-APV1
In stock
9 Items
Data sheet
Vendor Homepage
https://www.dahuasecurity.com/products/All-Products/PTZ-Cameras/X-Spans-Series/Distribution/SDT4E425-8P-GB-APV1
Garantija
36
Category Code
FNC
Unit Box Height
0.24
Unit Box Length
0.49
Unit Box Width
0.26
Units per Shipping Box
1
Unit Calculated Volume
0.03058 cubm
Unit Calculated Weight
4.73 kg
Summary
Dahua Technology WizSense SDT4E425-8P-GB-APV1. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Dome. Tilt preset speed: 90 /sec, Tilt manual
Weight & dimensions (Width)
194.2 mm
Weight & dimensions (Depth)
160 mm
Weight & dimensions (Height)
311 mm
Weight & dimensions (Weight)
3100 g
Network (Bluetooth)
No
Network (Ethernet LAN)
Yes
Network (Wi-Fi)
No
Design (Product colour)
White
Ports & interfaces (Ethernet LAN (RJ-45) ports)
1
Packaging content (Manual)
Yes
Design (Form factor)
Dome
Camera (Camera shutter speed)
1 - 1/30000 s
Power (Power source type)
DC,PoE
Performance (Wide Dynamic Range (WDR))
Yes
Audio (Built-in microphone)
Yes
Design (International Protection (IP) code)
IP66
Design (Mounting type)
Ceiling/wall
Performance (Connectivity technology)
Wired
Performance (Day/night mode)
Yes
Performance (Placement supported)
Indoor & outdoor
Performance (Type)
IP security camera
Camera (Camera pan control)
Yes
Camera (Camera tilt control)
Yes
Night vision (Night vision)
Yes
Video (Frame rate)
30 fps
Video (Maximum resolution)
4096 x 1860 pixels
Video (Noise reduction)
Yes
Video (Noise reduction technology)
2D noise reduction,3D noise reduction
Video (Total megapixels)
8 MP
Storage (Built-in HDD)
No
Power (DC output voltage)
12
Packaging content (Number of cameras)
1
Image sensor (Sensor type)
CMOS
Security (Alarm input channels)
2
Security (Alarm output channels)
1
Performance (Alarm input/output)
Yes
Video (Back Light Compensation (BLC))
Yes
Video (Highlight Compensation (HLC))
Yes
Video (Gain control type)
Auto/Manual
Camera (Camera shutter type)
Electronic
Video (Region of Interest (ROI) encoding)
Yes
Security (Video motion detection)
Yes
Performance (Built-in light)
Yes
Video (Bit rate control)
Constant Bit Rate (CBR),Variable Bit Rate (VBR)
Audio (Signal-to-Noise Ratio (SNR))
55 dB
Security (Mirror)
Yes
Lens system (Detect distance)
56 m
Lens system (Detect distance (tele))
2500 m
Lens system (Detect distance (wide))
100 m
Lens system (Identify distance (tele))
250 m
Lens system (Identify distance (wide))
10 m
Lens system (Observe distance)
24.4 m
Lens system (Observe distance (tele))
1000 m
Lens system (Observe distance (wide))
40 m
Lens system (Recognize distance)
11.2 m
Lens system (Recognize distance (tele))
500 m
Lens system (Recognize distance (wide))
20 m
Video (Bit rate)
H265: 51 kbps-13,312 kbps
Performance (PTZ control)
Yes
Performance (PTZ modes)
Preset point
Camera (Pan manual speed)
0.1 - 180 /sec
Camera (Pan preset speed)
180 /sec
Camera (Tilt manual speed)
0.1 - 90 /sec
Camera (Tilt preset speed)
90 /sec
Performance (Remote viewing)
Yes
Performance (Preset points)
Yes
Performance (Tour recording)
Yes
Lens system (Digital zoom)
16 x
Specific References
EAN13
6939554910708
MPN
1435618
