8026475179944Power Supply|TECNOWARE|ATX|PC|180 - 264 V|650 W|FAL651FSP12
  • 8026475179944Power Supply|TECNOWARE|ATX|PC|180 - 264 V|650 W|FAL651FSP12

Power Supply|TECNOWARE|ATX|PC|180 - 264 V|650 W|FAL651FSP12

FAL651FSP12
TECNOWARE
650 W | 180 - 264 V | Efficiency 85 % | PC | ATX | Fan diameter 120 mm | Weight 1 kg
32,34 €
Sisältää alv:n
Määrä
Laos
25 Tuotteet

Kuvaus

Internal power supply for personal computer, power 650W, input voltage 230 Vac, 50/60 Hz, conforms to ATX 12V v.2.31 specifications, main switch, surge protection, overload protection, short circuit protection, high MTBF, high reliability, quiet operation, 12 cm silent fan, temperature control of fan speed, Flat type connection cables from 500mm to 800mm, 1 x 20+4-pin connector, 1 x 12V 4+4-pin connector, 1 x 6+2 PCI-E connector, 2 x Molex connectors, 4 x Sata connector, dimensions 150x140x86 mm, weight 1.0 Kg, black color, CE certification, RoHS.

  • Internal Power Supply for Computers
  • High Efficiency (>85%) and High Operation Noise
  • Active PFC >0.9
  • Dimensions: 140x86x150 mm (WxHxD)
  • Input voltage 230 Vac 50Hz
  • Temperature control of the fan speed
  • Flat connection cables from 500mm to 800mm
  • Surge protection
  • Overload protection
  • Short circuit protection
Tuotetiedot
TECNOWARE
FAL651FSP12
25 Tuotteet

Lisätiedot

Vendor Homepage
https://www.tecnoware.com/en-US/Dettaglio/Articolo/849
Garantija
24
Category Code
PSU
Unit Box Height
0.095
Unit Box Length
0.22
Unit Box Width
0.155
Units per Shipping Box
8
Unit Calculated Volume
0.00405 cubm
Unit Calculated Weight
1.25 kg
Summary
Tecnoware FAL651FSP12. Total power: 650 W, AC input voltage: 180 - 264 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 24-pin ATX. Purpose: PC, Power supply unit (PSU) form factor: ATX. Product colour: Black, Cooling type: Active, Fan diam
Weight & dimensions (Width)
150 mm
Weight & dimensions (Depth)
140 mm
Weight & dimensions (Height)
86 mm
Weight & dimensions (Weight)
1000 g
Operational conditions (Operating temperature (T-T))
0 - 40 C
Operational conditions (Storage temperature (T-T))
-15 - 40 C
Design (Product colour)
Black
Power (AC input frequency)
47 - 63 Hz
Power (AC input voltage)
180 - 264 V
Design (Cooling type)
Active
Design (Number of fans)
1 fan(s)
Design (Fan diameter)
120 mm
Design (On/off switch)
Yes
Power (Max output current (+12V))
26 A
Power (Max output current (+3.3V))
25 A
Power (Max output current (+5V))
26 A
Power (Max output current (+5Vsb))
2.5 A
Power (Max output current (-12V))
0.8 A
Power (Power protection features)
Overload/Short circuit/Surge protection
Power (Total power)
650 W
Ports & interfaces (Motherboard power connector)
24-pin ATX
Ports & interfaces (Number of SATA power connectors)
4
Ports & interfaces (Peripheral (Molex) power connectors (4-pin))
2
Performance (80 PLUS certification)
No
Performance (Power supply unit (PSU) form factor)
ATX
Performance (Purpose)
PC
Power (Power Factor Correction (PFC) type)
Active
Performance (ATX version)
2.31
Power (Efficiency)
85 %
Ports & interfaces (CPU power connector (4+4 pin))
Yes
Ports & interfaces (PCI Express power connectors (6+2 pin))
1

Tilausviitteet

EAN13
8026475179944
Valmistajan tuotenumero (MPN)
1451665
